Designed for demanding high-pressure fluid transfer applications, the Coxreels E-MP-350 spring rewind enclosed cabinet hose reel combines automatic hose retrieval with the added protection of a fully enclosed cabinet. Featuring the E Series, a 3/8" hose diameter, 50 ft hose length, and a 3000 PSI maximum operating pressure, this reel is ideal for hydraulic service, pressure washing, lubrication systems, industrial maintenance, and manufacturing environments where protecting high-pressure hose assemblies is essential. Its spring rewind mechanism automatically retracts the hose after use, helping improve productivity while reducing hose handling and wear.
Supplied with a factory-installed hose, the E-MP-350 is ready for installation and immediate operation. The enclosed cabinet helps shield both the hose and internal reel components from dirt, debris, moisture, and incidental damage while maintaining a clean, professional appearance and extending hose service life in demanding industrial environments.
Type: Spring Rewind Enclosed Cabinet Hose Reel | Series: E Series | Hose I.D.: 3/8" | Hose Length: 50 ft | Max Pressure: 3000 PSI | Rewind: Spring Rewind
Features:
- Spring rewind mechanism automatically retracts the hose for quick, controlled storage after use.
- Fully enclosed cabinet protects the hose and reel components from dirt, debris, moisture, and accidental damage.
- Supplied with a factory-installed 50-foot, 3/8-inch high-pressure hose for immediate installation.
- Rated for operating pressures up to 3000 PSI for compatible high-pressure fluid transfer applications.
- Compact enclosed design helps protect hose assemblies while maintaining a clean and organized workspace.
- E Series construction provides dependable hose management for demanding commercial and industrial environments.
Made in USA:
Applications:
- Hydraulic service and maintenance operations.
- Industrial pressure washing and equipment cleaning.
- Lubrication and fluid transfer systems in manufacturing facilities.
- Maintenance departments servicing production equipment and machinery.
- Commercial and industrial applications requiring protected storage of high-pressure hose assemblies.
FAQs:
- Q: Does this reel include a hose?
A: Yes. The E-MP-350 is supplied with a factory-installed 50-foot, 3/8-inch hose for immediate installation and operation. - Q: What are the benefits of the enclosed cabinet?
A: The enclosed cabinet helps protect the hose and reel components from dirt, debris, moisture, and incidental damage while maintaining a clean, professional appearance. - Q: How does the spring rewind mechanism operate?
A: The internal spring automatically retracts the hose after use, reducing manual effort while keeping the hose neatly stored inside the cabinet. - Q: Is this reel suitable for high-pressure applications?
A: Yes. The reel is rated for applications up to 3000 PSI when used with the supplied hose and compatible system components.
| HOSE | LESS HOSE | SIZE INDEX |
|||||||
|---|---|---|---|---|---|---|---|---|---|
| SKU | I.D. | O.D. | FT. | PSI | APRX. LBS. |
EZ-COIL SKU | LESS HOSE SKU | APRX. LBS. |
|
|
LOW PRESSUREModels with hose are for air water service with a maximum temperature 150°F.
Models less hose can be used for air, water or oil. |
|||||||||
| E-LP-330 | 3/8" | 5/8" | 30 | 300 | 33 | EZ-E-LP-330 | E-LPL-330 | 29 | 1 |
| E-LP-350 | 3/8" | 5/8" | 50 | 300 | 46 | EZ-E-LP-350 | E-LPL-350 | 40 | 2 |
| E-LP-430 | 1/2" | 3/4" | 30 | 300 | 41 | EZ-E-LP-430 | E-LPL-430 | 36 | 1 |
| E-LP-450 | 1/2" | 3/4" | 50 | 300 | 50 | EZ-E-LP-450 | E-LPL-450 | 42 | 2 |
|
MEDIUM PRESSUREReels are furnished with standard one wire braid hose suitable for air, water or oil applications.
Hose exceeds SAE R1 specifications. Maximum Temperature 250°F. |
|||||||||
| E-MP-330 | 3/8" | 5/8" | 30 | 3,000 | 47 | EZ-E-MP-330 | E-MPL-330 | 39 | 1 |
| E-MP-350 | 3/8" | 5/8" | 50 | 3,000 | 61 | EZ-E-MP-350 | E-MPL-350 | 49 | 2 |
| E-MP-430 | 1/2" | 3/4" | 30 | 2,500 | 47 | EZ-E-MP-430 | E-MPL-430 | 39 | 1 |
| E-MP-450 | 1/2" | 3/4" | 50 | 2,500 | 63 | EZ-E-MP-450 | E-MPL-450 | 49 | 2 |
|
HIGH PRESSUREReels are furnished standard with S.A.E. 100R16 #1 or #2 wire braid hose suitable for grease and
hydraulic oil applications. Maximum Temperature 250°F. |
|||||||||
| E-HP-130 | 1/4" | 9/16" | 30 | 5,000 | 46 | EZ-E-HP-130 | E-HPL-130 | 39 | 3 |
| E-HP-150 | 1/4" | 9/16" | 50 | 5,000 | 60 | EZ-E-HP-150 | E-HPL-150 | 49 | 4 |
| E-HP-330 | 3/8" | 11/16" | 30 | 4,000 | 47 | EZ-E-HP-330 | E-HPL-330 | 39 | 3 |
| E-HP-350 | 3/8" | 11/16" | 50 | 4,000 | 61 | EZ-E-HP-350 | E-HPL-350 | 49 | 4 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
- Type
- Spring Rewind Enclosed Cabinet Hose Reel
- Series
- E Series
- Hose Inside Diameter (in.)
- 3/8
- Hose Outside Diameter (in.)
- 5/8
- Hose Length (ft.)
- 50
- Hose Included
- Yes
- Maximum Working Pressure (PSI)
- 3000
- Width (in.)
- 8.75
- Height (in.)
- 21
- Length (in.)
- 19.63
- Mounting Pattern (in.)
- 4M
- Mounting Pattern (in.)
- 5N
- Base (in.)
- 6X
- Base (in.)
- 6Y
