Coxreels EZ-E-HP-350 Spring Rewind Enclosed Cabinet Hose Reel | EZ-E Series | 3/8" Hose Diameter | 50' Hose Length | 4000 Max PSI

Built for controlled high-pressure hose handling in longer-reach enclosed cabinet installations, the Coxreels EZ-E-HP-350 is an EZ-Coil spring rewind hose reel from the EZ-E Series. This model is supplied with 3/8" I.D. hose, a 50 ft hose length, and a 4000 PSI maximum pressure rating, making it a practical choice for compatible grease and hydraulic oil service where a larger high-pressure hose size, extended reach, and controlled rewind are all required.

The EZ-E Series combines Coxreels enclosed cabinet-style reel layout with EZ-Coil controlled retraction, which slows hose return compared with conventional spring rewind reels. That controlled rewind helps reduce sudden hose snap-back after the latch is released, while the cabinet format keeps the installation cleaner and more organized. With 50 ft of 3/8" high-pressure hose, the EZ-E-HP-350 is suited to fleet service bays, lubrication stations, hydraulic service points, and maintenance areas where the reel must reach farther across the work zone.

Type: Spring Rewind Enclosed Cabinet Hose Reel | Series: EZ-E Series | Model: EZ-E-HP-350 | Hose I.D.: 3/8" | Hose O.D.: 11/16" | Hose Length: 50 ft | Max Pressure: 4000 PSI | Service: Grease, Hydraulic Oil | Hose Included: Yes | Hose Type: S.A.E. 100R16 #1 or #2 Wire Braid | Max Temperature: 250°F | Rewind Type: EZ-Coil Controlled Spring Rewind | Reel Inlet: 3/8" FNPT | Hose Outlet: 3/8" MNPT | Swivel Material: Zinc Plated Steel | Seal Type: Nitrile | Overall Dimensions: 9.25" W x 21" H x 19.63" L | Mounting Pattern: 4" M x 5" N | Base: 5" X x 6" Y | Approx. Ship Weight: 61 lbs

Features:

• EZ-Coil controlled retraction slows hose return up to 80% compared with conventional spring driven reels for more controlled rewind operation.
• 4000 PSI high-pressure rating supports compatible grease and hydraulic oil service when pressure, fluid type, temperature, fittings, and hose requirements match the reel.
• 3/8" I.D. x 50 ft hose configuration provides extended reach and a larger hose diameter than 1/4" high-pressure models.
• S.A.E. 100R16 #1 or #2 wire braid hose supports high-pressure grease and hydraulic oil applications.
• Enclosed cabinet design supports clean single-reel mounting or organized multiple-reel bank installations in service and maintenance areas.
• Multi-position lock ratchet mechanism lets the user secure the hose at selected working lengths during operation.
• External fluid path with zinc plated steel 90° full-flow NPT swivel supports high-pressure hose connection and seal maintenance.
• Nitrile seals support compatible grease and hydraulic oil applications when chemical and temperature compatibility are confirmed.
• Solid one-piece steel base and support post, 1" solid steel axle, rolled edges, ribbed discs, lubricated precision bearings, and CPC powder coat finish support everyday shop and maintenance use.

Made in USA:

2 Year Warranty

Applications:

• Fleet maintenance and vehicle service shops where controlled rewind helps manage 50 ft of 3/8" high-pressure grease or hydraulic oil hose around lifts, lube bays, and service lanes.
• Industrial maintenance and MRO departments that need enclosed 4000 PSI hose storage near machinery, benches, and hydraulic service points.
• Lubrication stations where retractable hose access helps keep grease delivery lines organized and ready between service tasks.
• Manufacturing and production facilities using cabinet-mounted reel banks for controlled point-of-use fluid delivery.
• Equipment maintenance areas where longer high-pressure hose reach supports hydraulic oil service within the reel’s rated limits.

FAQs:

• Q: Does the Coxreels EZ-E-HP-350 include hose?
  A: Yes. The EZ-E-HP-350 is supplied with 3/8" I.D. x 50 ft high-pressure hose. Coxreels uses related HPL model designations for less-hose versions.
• Q: What is the difference between EZ-E-HP-350 and E-HP-350?
  A: Both models share the same 3/8" x 50 ft high-pressure configuration and 4000 PSI rating. The EZ-E-HP-350 adds Coxreels EZ-Coil controlled retraction system, which slows hose return compared with the standard E-HP model.
• Q: How is this different from the 1/4" EZ-E-HP models?
  A: The EZ-E-HP-350 uses a larger 3/8" I.D. hose and is rated to 4000 PSI. The 1/4" EZ-E-HP models are rated to 5000 PSI, so the right choice depends on the required hose size, pressure rating, and service equipment.
• Q: Can this reel be used for shop air or water?
  A: This HP configuration is intended for grease and hydraulic oil service. For air or water service, select a compatible Coxreels low-pressure or medium-pressure model with the correct hose, seals, and pressure rating.
• Q: When should I choose the 50 ft version instead of a 30 ft reel?
  A: Choose the 50 ft version when the reel must reach across larger bays, around vehicles, or between nearby service points. A 30 ft model may be better when the reel is mounted directly beside the lubrication or hydraulic service area.

Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.

For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
