Designed to protect hose assemblies while maintaining a clean, organized work area, the Coxreels E-LP-330 spring rewind enclosed cabinet hose reel combines automatic hose retrieval with the added protection of a fully enclosed cabinet. Featuring the E Series, a 3/8" hose diameter, 30 ft hose length, and a 300 PSI maximum operating pressure, this reel is well suited for automotive service facilities, maintenance shops, manufacturing plants, and commercial work environments where enclosed hose storage helps shield the hose from dirt, debris, and accidental damage. Its spring rewind mechanism automatically retracts the hose after use, improving efficiency while helping reduce manual handling.
Supplied with a factory-installed hose, the E-LP-330 is ready for installation and immediate use. The enclosed cabinet design helps protect the hose and internal reel components while maintaining a neat appearance, making it an excellent choice for professional workspaces where both durability and presentation are important.
Type: Spring Rewind Enclosed Cabinet Hose Reel | Series: E Series | Hose I.D.: 3/8" | Hose Length: 30 ft | Max Pressure: 300 PSI | Rewind: Spring Rewind
Features:
- Spring rewind mechanism automatically retracts the hose for quick, controlled storage after use.
- Fully enclosed cabinet helps protect the hose and reel components from dirt, debris, and accidental damage.
- Supplied with a factory-installed 30-foot, 3/8-inch hose for immediate installation.
- Rated for operating pressures up to 300 PSI for compressed air and other compatible low-pressure applications.
- Compact enclosed design promotes a cleaner appearance while helping reduce hose wear.
- E Series construction provides dependable hose management for commercial and industrial environments.
Made in USA:
Applications:
- Compressed air distribution in automotive repair shops and service bays.
- Manufacturing facilities requiring protected hose storage.
- Maintenance departments using compressed air throughout production areas.
- Commercial workshops where enclosed hose storage improves organization and appearance.
- General industrial facilities utilizing compatible low-pressure air and fluid systems.
FAQs:
- Q: Does this reel include a hose?
A: Yes. The E-LP-330 is supplied with a factory-installed 30-foot, 3/8-inch hose for immediate installation and use. - Q: What are the advantages of an enclosed cabinet reel?
A: The enclosed cabinet helps protect the hose and reel components from dirt, debris, and incidental damage while maintaining a clean, professional appearance. - Q: How does the spring rewind system operate?
A: The internal spring mechanism automatically retracts the hose after use, reducing manual effort and helping keep the hose neatly stored. - Q: What is the maximum operating pressure?
A: The reel is rated for applications up to 300 PSI when used with the supplied hose and compatible system components.
| HOSE | LESS HOSE | SIZE INDEX |
|||||||
|---|---|---|---|---|---|---|---|---|---|
| SKU | I.D. | O.D. | FT. | PSI | APRX. LBS. |
EZ-COIL SKU | LESS HOSE SKU | APRX. LBS. |
|
|
LOW PRESSUREModels with hose are for air water service with a maximum temperature 150°F.
Models less hose can be used for air, water or oil. |
|||||||||
| E-LP-330 | 3/8" | 5/8" | 30 | 300 | 33 | EZ-E-LP-330 | E-LPL-330 | 29 | 1 |
| E-LP-350 | 3/8" | 5/8" | 50 | 300 | 46 | EZ-E-LP-350 | E-LPL-350 | 40 | 2 |
| E-LP-430 | 1/2" | 3/4" | 30 | 300 | 41 | EZ-E-LP-430 | E-LPL-430 | 36 | 1 |
| E-LP-450 | 1/2" | 3/4" | 50 | 300 | 50 | EZ-E-LP-450 | E-LPL-450 | 42 | 2 |
|
MEDIUM PRESSUREReels are furnished with standard one wire braid hose suitable for air, water or oil applications.
Hose exceeds SAE R1 specifications. Maximum Temperature 250°F. |
|||||||||
| E-MP-330 | 3/8" | 5/8" | 30 | 3,000 | 47 | EZ-E-MP-330 | E-MPL-330 | 39 | 1 |
| E-MP-350 | 3/8" | 5/8" | 50 | 3,000 | 61 | EZ-E-MP-350 | E-MPL-350 | 49 | 2 |
| E-MP-430 | 1/2" | 3/4" | 30 | 2,500 | 47 | EZ-E-MP-430 | E-MPL-430 | 39 | 1 |
| E-MP-450 | 1/2" | 3/4" | 50 | 2,500 | 63 | EZ-E-MP-450 | E-MPL-450 | 49 | 2 |
|
HIGH PRESSUREReels are furnished standard with S.A.E. 100R16 #1 or #2 wire braid hose suitable for grease and
hydraulic oil applications. Maximum Temperature 250°F. |
|||||||||
| E-HP-130 | 1/4" | 9/16" | 30 | 5,000 | 46 | EZ-E-HP-130 | E-HPL-130 | 39 | 3 |
| E-HP-150 | 1/4" | 9/16" | 50 | 5,000 | 60 | EZ-E-HP-150 | E-HPL-150 | 49 | 4 |
| E-HP-330 | 3/8" | 11/16" | 30 | 4,000 | 47 | EZ-E-HP-330 | E-HPL-330 | 39 | 3 |
| E-HP-350 | 3/8" | 11/16" | 50 | 4,000 | 61 | EZ-E-HP-350 | E-HPL-350 | 49 | 4 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
