Coxreels E-LPL-350 Spring Rewind Enclosed Cabinet Hose Reel | E Series | 3/8" Hose Diameter | 50' Hose Length | 300 Max PSI | Less Hose

Built for low-pressure hose storage where a longer reach is needed and the buyer wants to install a specific hose, the Coxreels E-LPL-350 is a spring rewind enclosed cabinet hose reel from the E Series. This less-hose model is configured for 3/8" I.D. hose, supports a 50 ft hose capacity, and is rated for 300 PSI maximum pressure, making it a practical reel body for compatible air, water, or oil service when the selected hose, fittings, and media match the application.

The E Series cabinet format helps create a cleaner installation than an open-frame reel, especially in visible service bays, maintenance departments, production workstations, and organized point-of-use areas. Because this model is supplied less hose, buyers can choose a compatible 3/8" hose for the service media, pressure rating, and temperature requirements of the job. The spring rewind mechanism retracts the hose after use, while the lock ratchet holds the hose at the selected working length during operation.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind Enclosed Cabinet Hose Reel | Series: E Series | Model: E-LPL-350 | Configuration: Less Hose | Hose I.D.: 3/8" | Max Hose O.D.: 5/8" | Hose Capacity: 50 ft | Max Pressure: 300 PSI | Service: Air, Water, Oil | Swivel Material: Brass | Housing Material: Steel | Overall Dimensions: 8.75" W x 21" H x 19.63" L | Mounting Pattern: 4" x 5" | Base Size: 5" x 6" | Hose Included: No

Features:

• Less-hose configuration allows the buyer to install a compatible 3/8" hose selected for the application, service media, pressure rating, and temperature requirements.
• 50 ft hose capacity provides longer reach than 30 ft versions for larger bays, service lanes, benches, and nearby equipment areas.
• 300 PSI low-pressure rating supports compatible air, water, or oil service when the installed hose and fittings are rated accordingly.
• Spring rewind operation retracts hose after use, helping reduce loose hose around workstations, walkways, equipment, and service areas.
• Multi-position lock ratchet mechanism lets the user secure the hose at selected working lengths during operation.
• Expandable enclosed cabinet format supports clean single-reel mounting or organized multiple-reel bank installations.
• Brass swivel supports low-pressure fluid connection when the hose, fittings, seals, and media are compatible.
• Steel cabinet construction helps present a cleaner finished appearance than exposed hose storage or open-frame reel placement.

Made in USA:

2 Year Warranty

Applications:

• Automotive service bays where a 50 ft low-pressure hose reach is needed and the shop wants to select its own compatible air, water, or oil hose.
• Industrial maintenance and MRO stations that need enclosed hose storage for longer point-of-use pulls across benches, machines, or repair zones.
• Fleet service and equipment maintenance areas where retractable hose management helps keep service lanes and walkways clearer.
• Manufacturing and production cells using cabinet-style reel banks to organize multiple low-pressure service lines.
• Garage and workshop installations where a less-hose reel gives the user flexibility to choose the hose type before putting the reel into service.

FAQs:

• Q: Does the Coxreels E-LPL-350 include hose?
  A: No. This is a less-hose model, meaning the reel is supplied without hose installed. The 3/8" diameter and 50 ft listing refers to the compatible hose size and capacity.
• Q: What does less hose mean?
  A: It means the buyer must provide and install a compatible hose separately. The hose must match the reel capacity, pressure rating, fitting size, temperature range, and intended service media.
• Q: Can this reel be used for shop air?
  A: Yes, when the selected 3/8" hose, fittings, and air system stay within the reel's 300 PSI maximum pressure rating. Always verify the installed hose and connection ratings before use.
• Q: Can this reel be used for oil or water?
  A: Yes, this less-hose configuration can be used for compatible air, water, or oil service when the hose, fittings, and seals selected for installation are suitable for the media.
• Q: When should I choose the 50 ft capacity instead of the 30 ft reel?
  A: Choose the 50 ft capacity when the reel must reach across larger bays, around vehicles, or between nearby service points. A 30 ft reel may be better when the mounting point is close to the work and less hose on the floor is preferred.

Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.

For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
