Coxreels EZ-E-LP-450 Spring Rewind Enclosed Cabinet Hose Reel | EZ-E Series | 1/2" Hose Diameter | 50' Hose Length | 300 Max PSI

Built for longer-reach hose access in clean, cabinet-style shop installations, the Coxreels EZ-E-LP-450 is a spring rewind enclosed cabinet hose reel from the EZ-E Series. This low-pressure model is configured with 1/2" I.D. hose, a 50 ft hose length, and a 300 PSI maximum pressure rating, making it a practical choice for compatible air and water service where a larger hose diameter and extended reach are both needed.

The EZ-E Series uses an expandable metal cabinet system for organized single-reel or multiple-reel bank installations. Its EZ-Coil controlled retraction system slows hose return compared with conventional spring rewind reels, helping reduce uncontrolled snap-back during rewind. The enclosed cabinet helps create a cleaner, more professional-looking setup in service bays, maintenance departments, and workstation areas where open-frame reels may not be preferred.

Type: Spring Rewind Enclosed Cabinet Hose Reel | Series: EZ-E Series | Model: EZ-E-LP-450 | Hose I.D.: 1/2" | Hose O.D.: 3/4" | Hose Length: 50 ft | Max Pressure: 300 PSI | Service: Air, Water | Max Temperature: 150°F | Rewind Type: EZ-Coil Controlled Spring Rewind | Overall Dimensions: 8.75" W x 21" H x 19.63" L | Mounting Pattern: 4" M x 5" N | Base: 5" X x 6" Y | Approx. Ship Weight: 50 lbs

Features:

• Expandable enclosed metal cabinet design supports clean, organized single-reel or multiple-reel bank installations.
• EZ-Coil controlled retraction slows hose return up to 80% compared with conventional spring driven reels for more controlled rewind operation.
• 1/2" I.D. hose configuration supports higher flow than smaller 3/8" hose models when the air or water system is sized accordingly.
• 50 ft hose length provides extended reach across service bays, workstations, benches, and maintenance areas.
• External fluid path with machined solid brass 90° full-flow NPT swivel inlet supports easier seal maintenance and hose installation.
• Enclosed, factory-tuned cartridge-style spring motor is matched to the reel for dependable rewind performance.
• Non-corrosive stainless steel spring, pawl, and zinc-plated ratchet help maintain consistent latch and retract operation.
• Rolled edges, ribbed discs, lubricated precision bearings, and CPC powder coat finish support everyday use in shop and service environments.

Made in USA:

2 Year Warranty

Applications:

• Automotive service bays where 50 ft of 1/2" hose reach helps mechanics cover lifts, benches, and vehicle work areas from one mounted reel location.
• Industrial maintenance and MRO stations that need organized air or water hose delivery close to machinery, benches, or repair zones.
• Fleet service and utility shops where controlled hose rewind helps reduce loose hose around service lanes and equipment bays.
• Manufacturing cells and assembly areas where enclosed reel banks create a cleaner point-of-use hose management system.
• Garage and workshop installations where automatic rewind, larger hose diameter, and enclosed cabinet storage improve daily hose handling.

FAQs:

• Q: Does the Coxreels EZ-E-LP-450 include hose?
  A: Yes. The EZ-E-LP-450 is the hose-included low-pressure model configured for 1/2" I.D. x 50 ft hose. Coxreels uses the related LPL model designation for less-hose versions.
• Q: What is the advantage of choosing 1/2" hose instead of 3/8" hose?
  A: A 1/2" hose can support greater flow than a 3/8" hose when the supply line, fittings, and connected equipment are sized properly. This is useful when air or water volume matters more than using the smallest possible hose.
• Q: What does EZ-Coil® controlled retraction do?
  A: EZ-Coil is Coxreels controlled rewind system that slows the hose return compared with a standard spring rewind reel. This helps make retraction more controlled after the hose latch is released.
• Q: Can this reel be used for oil service?
  A: The low-pressure hose-included EZ-E-LP models are listed for air and water service. For oil service, confirm the correct Coxreels model, hose, seals, and fluid compatibility before ordering.
• Q: Is the 50 ft hose length necessary for every workstation?
  A: Not always. The 50 ft version is helpful for larger bays or when the reel must reach around vehicles, equipment, or multiple work positions. A shorter 30 ft reel may be better when the mounting point is close to the job and less hose on the floor is preferred.

Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.

For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
