Coxreels PC13L-5016-4 Spring Rewind Power Cord Reel | PC Series | 50' Hose Length | 25 Amps | 115 Volts | Less Cord

When a work area needs organized electrical cord management without a fixed factory-installed cord, the Coxreels PC13L-5016-4 provides a spring rewind power cord reel platform for custom cord installation. This PC Series reel is listed as Less Cord, Less Accessory and is built around a 50 ft cord capacity for 16/4 SJO cord, giving maintenance teams, contractors, and shop personnel a retractable reel body that can be matched to the appropriate cord and end configuration for the job.

Rated for 25 amps at 115 volts, the PC13L-5016-4 is intended for indoor power cord reel applications where cord gauge, insulation type, conductor count, and local electrical code requirements must be reviewed before installation. Its spring rewind design helps reduce loose cord on floors, while the adjustable guide arm supports wall, floor, or overhead mounting layouts in shops, maintenance bays, production areas, and service facilities.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind Power Cord Reel | Series: PC Series | Model: PC13L-5016-4 | Configuration: Less Cord, Less Accessory | Cord Capacity: 50 ft | Cord Size: 16/4 AWG | Cord Type: SJO | Voltage: 115 V | Amperage: 25 A | Approx. Weight: 31 lbs | Size Index: 1 | Use: Indoor Use Only

Features:

• Spring driven power cord reel helps keep loose electrical cord off the floor and supports a cleaner, more organized work area.
• Less cord, less accessory configuration allows the installer to supply compatible cord and end fittings based on the electrical requirements of the application.
• External heavy gauge CPC™ powder coated steel components cover provides access for routine slip ring maintenance.
• Electrical current runs through a 25 amp / 300 volt rated slip ring, which transfers power through the rotating reel assembly.
• Single pedestal cord reel layout uses a space-saving design for wall, floor, or overhead mounting positions.
• Guide arm adjusts to wall, floor, and overhead positions to match the preferred cord payout direction.
• Solid one-piece heavy gauge 1/4" steel base and support post provide stable mounting support.
• 1" solid steel axle and lubricated precision bearings support smooth reel rotation during pullout and rewind.
• Enclosed factory tuned and matched cartridge-style spring motor powers automatic rewind.
• Multi-position lock ratchet mechanism secures the cord at the desired working length during use.

Made in USA:

2 Year Warranty

Applications:

• Power tool workstations where a retractable indoor cord reel helps reduce loose cord across benches, bays, or production cells.
• Maintenance shops and MRO areas that need organized access to electrical power for service tasks and general repair work.
• Manufacturing plants where wall, floor, or overhead mounting can place power closer to the operator while keeping the work area more orderly.
• Automotive and fleet service centers using cord reels around lifts, service bays, tire areas, or diagnostic stations.
• Construction and contractor shops that require controlled cord storage for indoor tool rooms, service areas, or equipment prep spaces.
• Workshops and garage environments where a spring rewind reel helps keep extension cords stored between jobs.

FAQs:

• Q: What does “less cord” mean on the Coxreels PC13L-5016-4?
  A: It means the reel is supplied without cord installed. The installer or buyer must provide compatible cord and accessories separately.
• Q: Is this reel supplied with a receptacle or plug end?
  A: No. This model is listed as less cord and less accessory, so cord ends, plugs, receptacles, and related electrical accessories are not included.
• Q: Can the PC13L-5016-4 be mounted overhead?
  A: Yes. The PC Series guide arm adjusts for wall, floor, and overhead mounting positions, allowing the payout direction to be set for the installation location.
• Q: What should be checked before installing cord on this reel?
  A: Cord AWG, cord length, insulation rating, conductor count, electrical service, and the rating of the lowest-rated component must be considered. The end user is responsible for verifying code compliance and application suitability.
• Q: Is this reel for indoor or outdoor use?
  A: Coxreels lists the PC Series power cord reels on this catalog page for indoor use only.
