When you need a compact, dependable hose reel for shop air, water, or oil service — and you want to supply your own hose — the Coxreels P-LPL-130 delivers a 30-foot hose capacity for 1/4-inch I.D. line in one of the smallest footprints in the P Series. This is the "less hose" version of the popular P-LP-130, meaning the reel ships bare without hose installed (handy when you already stock specific hose grades or need a custom length cut for your bay layout). The spring rewind mechanism (an internal coiled spring that retracts the hose automatically when released) returns the hose smoothly to the reel, while the 300 PSI pressure rating covers the full range of low-pressure shop air, water, and light oil service up to a maximum temperature of 150°F. The compact 24-pound body is built for permanent wall, ceiling, bench, truck-bed, or vehicle mounting in workshops, service trucks, agricultural buildings, and small fleet maintenance bays.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
Type: Spring Rewind Hose Reel | Series: P "Performance" Series | Pressure Class: Low Pressure | Configuration: Less Hose (bare reel) | Hose Capacity I.D. (in.): 1/4 | Hose Capacity O.D. (in.): 1/2 | Hose Capacity Length (ft.): 30 | Max Pressure (PSI): 300 | Max Temperature (°F): 150 | Service: Air, Water, Oil | Approx. Weight (lbs.): 24 | Size Index: 1 | Drive Mechanism: Spring Rewind | Mounting: Multi-position (wall, ceiling, floor, vehicle)
|
Features:
Made in USA: |
Applications:
- Automotive & fleet service — overhead air drops at lift bays, tire inflation stations, and parts washing setups in independent shops and dealership service lanes
- Industrial maintenance & MRO — point-of-use shop air for hand tools, blow guns, and pneumatic accessories on plant floors and tool cribs
- Agricultural & equipment service — water and air supply in barns, equipment sheds, and mobile service trucks for farm and ranch operations
- Mobile service trucks & work vans — vehicle-mounted air or water reel for field service technicians, mobile mechanics, and utility crews
- DIY garage & home workshop — clean overhead air supply for impact wrenches, blow guns, and tire inflation in the home shop, replacing tangled coiled hose
FAQs:
Q: What does "less hose" mean, and what hose do I need to buy separately? A: "Less hose" means the reel is shipped bare — no hose pre-installed. You'll need to supply your own 1/4-inch I.D. hose with a 1/2-inch O.D. and a maximum length of 30 feet. Choose the hose material based on your service: rubber or PVC for shop air, food-grade for potable water, or oil-resistant rubber for lubricant lines. Make sure your fittings match your shop's quick-disconnects.
Q: How is the P-LPL-130 different from the P-LP-130? A: They're the same reel — the P-LP-130 ships with hose included, and the P-LPL-130 is the "less hose" version (the L stands for "less hose"). Choose less-hose when you already stock hose, need a specialty hose grade, or want to install fittings yourself.
Q: Can I mount this reel overhead on a ceiling or under a workbench? A: Yes — the P Series is designed for multi-position mounting. Wall, ceiling, floor, bench-top, and vehicle mounting are all supported. The mounting bracket lets the reel feed in any direction; just confirm hose routing and the spring tension setting after installation.
Q: Is 300 PSI enough for shop air tools? A: Yes — typical shop air systems run 90–125 PSI, well below the reel's 300 PSI rating. The 300 PSI ceiling gives plenty of safety margin for spike pressures and lets the reel handle water service and light oil delivery in the same range.
Q: Will this hold up for daily commercial shop use? A: The P "Performance" Series is the workhorse line in Coxreels' compact lineup, used in commercial garages, fleet shops, and industrial plants worldwide. For continuous-duty heavy industrial use, step up to the medium-pressure P-MP series or the larger 1125 / 1175 series; for occasional shop and DIY use, the P-LPL-130 is built well above the demand.
Available Variations and Specifications
| SKU | I.D. | O.D. | FT. | PSI | APRX. LBS. | EZ-COIL SKU | LESS HOSE SKU | APRX. LBS. | SIZE INDEX |
|---|---|---|---|---|---|---|---|---|---|
| LOW PRESSURE — Models with hose are for air water service with a maximum temperature 150°F. Models less hose can be used for air, water or oil. | |||||||||
| P-LP-125 | 1/4" | 1/2" | 25 | 300 | 26 | EZ-P-LP-125 | P-LPL-125 | 24 | 1 |
| P-LP-130 | 1/4" | 1/2" | 30 | 300 | 27 | - | P-LPL-130 | 24 | 1 |
| P-LP-135 | 1/4" | 1/2" | 35 | 300 | 28 | EZ-P-LP-135 | P-LPL-135 | 25 | 1 |
| P-LP-140 | 1/4" | 1/2" | 40 | 300 | 38 | - | P-LPL-140 | 34 | 3 |
| P-LP-150 | 1/4" | 1/2" | 50 | 300 | 40 | EZ-P-LP-150 | P-LPL-150 | 35 | 3 |
| P-LP-325 | 3/8" | 5/8" | 25 | 300 | 28 | EZ-P-LP-325 | P-LPL-325 | 25 | 2 |
| P-LP-330 | 3/8" | 5/8" | 30 | 300 | 37 | EZ-P-LP-330 | P-LPL-330 | 33 | 3 |
| P-LP-335 | 3/8" | 5/8" | 35 | 300 | 39 | EZ-P-LP-335 | P-LPL-335 | 35 | 3 |
| P-LP-340 | 3/8" | 5/8" | 40 | 300 | 39 | - | P-LPL-340 | 35 | 3 |
| P-LP-350 | 3/8" | 5/8" | 50 | 300 | 43 | EZ-P-LP-350 | P-LPL-350 | 36 | 3 |
| P-LP-415 | 1/2" | 3/4" | 15 | 300 | 41 | - | P-LPL-415 | 35 | 3 |
| P-LP-425 | 1/2" | 3/4" | 25 | 300 | 44 | - | P-LPL-425 | 35 | 3 |
| P-LP-430 | 1/2" | 3/4" | 30 | 300 | 45 | EZ-P-LP-430 | P-LPL-430 | 40 | 4 |
| P-LP-450 | 1/2" | 3/4" | 50 | 300 | 50 | EZ-P-LP-450 | P-LPL-450 | 45 | 4 |
| MEDIUM PRESSURE — Reels are furnished with standard one wire braid hose suitable for air, water or oil applications. Hose exceeds SAE R1 specifications. Maximum Temperature 212°F. (If used with water, synthetic fluids 135°F max.) | |||||||||
| P-MP-320 | 3/8" | 11/16" | 25 | 3,000 | 49 | - | P-MPL-320 | 42 | 4 |
| P-MP-325 | 3/8" | 11/16" | 25 | 3,000 | 49 | - | P-MPL-325 | 42 | 4 |
| P-MP-330 | 3/8" | 11/16" | 30 | 3,000 | 50 | - | P-MPL-330 | 42 | 4 |
| P-MP-335 | 3/8" | 11/16" | 35 | 3,000 | 52 | - | P-MPL-335 | 43 | 4 |
| P-MP-420 | 1/2" | 13/16" | 20 | 2,500 | 47 | - | P-MPL-420 | 41 | 4 |
| P-MP-425 | 1/2" | 13/16" | 25 | 2,500 | 49 | EZ-P-MP-425 | P-MPL-425 | 42 | 4 |
| P-MP-430 | 1/2" | 13/16" | 30 | 2,500 | 51 | EZ-P-MP-430 | P-MPL-430 | 43 | 4 |
| HIGH PRESSURE — Reels are furnished standard with S.A.E. 100R16 #1 or #2 wire braid hose suitable for grease and hydraulic oil applications. Maximum Temperature 212°F. (If used with water, synthetic fluids 135°F max.) | |||||||||
| P-HP-120 | 1/4" | 9/16" | 20 | 5,000 | 46 | - | P-HPL-120 | 41 | 4 |
| P-HP-125 | 1/4" | 9/16" | 25 | 5,000 | 48 | EZ-P-HP-125 | P-HPL-125 | 41 | 4 |
| P-HP-130 | 1/4" | 9/16" | 30 | 5,000 | 50 | - | P-HPL-130 | 43 | 4 |
| P-HP-135 | 1/4" | 9/16" | 35 | 5,000 | 49 | - | P-HPL-135 | 43 | 4 |
| P-HP-320 | 3/8" | 11/16" | 20 | 4,000 | 47 | - | P-HPL-320 | 41 | 4 |
| P-HP-325 | 3/8" | 11/16" | 25 | 4,000 | 49 | EZ-P-HP-325 | P-HPL-325 | 43 | 4 |
| P-HP-330 | 3/8" | 11/16" | 30 | 4,000 | 51 | - | P-HPL-330 | 43 | 4 |
Looking for more information about the Coxreels Hose Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Hose Reels, please call (800) 608-5210 or email info@intlairtool.com
