Coxreels EZ-P-LP-330 Low Pressure Spring Rewind Hose Reel | EZ-P Series | 3/8" Hose Diameter | 30' Hose Length | 300 Max PSI

Stepping up from a 1/4-inch reel to a 3/8-inch ID hose nearly doubles the air volume reaching the tool, and the Coxreels EZ-P-LP-330 Low Pressure Spring Rewind Hose Reel is built around that bigger flow path. Thirty feet of 3/8-inch hose carry enough air to feed thirsty pneumatic tools — impact wrenches, ratchets, die grinders, and DA sanders — without the pressure drop that chokes performance on a 1/4-inch line. The reel is rated to 300 max PSI for air, water, and oil service up to 150°F, and the EZ-Coil controlled retraction system (a patented safety mechanism that slows hose rewind across the final few feet) prevents the brass nozzle end from whipping back against the drum, the wall, or the operator. A spring rewind motor pulls the hose back automatically when the job is done, and the heavy-gauge steel frame with powder-coat finish stands up to shop traffic. The EZ-P-LP-330 is suited to automotive service shops, fleet maintenance bays, light industrial workstations, and well-equipped home garages where the air supply needs to keep up with serious tools.

Type: Spring Rewind Hose Reel | Series: EZ-Coil P Series (Low Pressure) | Hose ID (in.): 3/8 | Hose OD (in.): 5/8 | Hose Length (ft): 30 | Max Pressure (PSI): 300 | Max Temperature (°F): 150 | Service: Air, Water, Oil | Retraction: Spring Rewind with EZ-Coil Controlled Return | Approx. Weight (lbs): 37

Features:

• EZ-Coil controlled retraction system slows hose rewind speed to prevent uncontrolled snap-back, protecting operators, hose ends, and surrounding equipment
• All-steel frame and base with durable powder-coat finish for long service in shop and light industrial environments
• Pre-mounted 30-foot, 3/8-inch ID hose delivers higher CFM throughput than 1/4-inch reels, supporting larger pneumatic tools without starving them for air
• 300 max PSI rating with service compatibility for air, water, and oil up to 150°F
• Multi-position adjustable guide arm directs hose payout at floor, bench, or overhead angles to match installation
• Sturdy spring motor delivers consistent rewind tension and is rebuildable in the field for extended service life
• CNC-machined brass swivel inlet provides a leak-resistant connection rated for the full pressure of the reel
• Versatile 37 lb body mounts to wall, ceiling, bench, floor, or vehicle with standard hardware

Made in USA:

2 Year Warranty

Applications:

• Automotive service & repair shops — feeding 3/8-inch air to impact wrenches, ratchets, and DA sanders at busy service bays where 1/4-inch hose would starve the tool
• Fleet & truck maintenance — high-volume air for tire work, brake servicing, and pneumatic tools across deep bays
• Light industrial & MRO — workbench air drops, parts cleaning stations, washdown points, and lubrication delivery in production areas
• Body shops & paint prep — air supply for sanders, polishers, and blow-offs that need steady CFM to maintain finish quality
• DIY garage & serious home workshop — powering air-hungry tools in two-car garages and hobby shops where 1/4-inch reels run out of breath

FAQs:

• Q: Why pick a 3/8-inch reel over a 1/4-inch reel?
  A: Air volume. A 3/8-inch ID hose passes meaningfully more CFM at the same pressure than a 1/4-inch hose, so the tool at the end of the line gets the air it needs. If you run impact wrenches, ratchets, die grinders, sanders, or any tool rated above roughly 4 CFM, a 3/8-inch reel keeps the tool at full performance. For blow guns and light tools, a 1/4-inch reel is fine.
• Q: What does the "EZ-Coil" feature actually do?
  A: EZ-Coil is Coxreels' patented controlled retraction system. As the hose rewinds, an internal dampener slows the return speed across the last few feet so the brass nozzle end doesn't whip back and strike the operator, the wall, or the reel housing. Standard spring rewind reels can retract at high speed; EZ-Coil reels are the safer choice in service bays and shared workspaces.
• Q: Can this reel be used for diesel or gasoline?
  A: No. The EZ-P-LP-330 is rated for air, water, and oil service only. For fuel delivery (gasoline, diesel, E85, kerosene) you need a reel with Viton or fuel-rated seals — Coxreels offers dedicated fuel reels for that service.
• Q: How is the reel mounted, and can it go on a ceiling?
  A: The EZ-P-LP-330 has a multi-position guide arm and a mounting base designed for wall, ceiling, bench, floor, or vehicle mounting. At 37 lbs the reel mounts cleanly to overhead structure in most shop bays. Confirm your fasteners and mounting surface are rated for the loaded reel.
• Q: What's the difference between the EZ-P-LP-330 and the standard P-LP-330?
  A: Both reels share the same hose, pressure, and service ratings. The EZ-P-LP-330 adds the EZ-Coil controlled retraction system, which is recommended anywhere operators are nearby during rewind. The standard P-LP-330 is a conventional spring rewind without the dampener.
