High-volume hydraulic work and heavy grease delivery push more fluid than a 1/4-inch reel can keep up with. The Coxreels EZ-P-HP-325 High Pressure Spring Rewind Hose Reel steps up to 25 feet of 3/8-inch ID hose furnished to SAE 100R1 or R2 specifications (steel-reinforced hydraulic hose constructions used industry-wide for high-pressure fluid service). Rated to 4,000 max PSI for grease and hydraulic oil service up to 212°F — or 135°F with water and synthetic fluids — the reel delivers meaningfully higher flow than 1/4-inch HP reels at the cost of trading 1,000 PSI off the top end, which still leaves headroom for nearly every chassis grease and equipment hydraulic application. EZ-Coil controlled retraction (a patented safety mechanism that slows hose rewind across the final few feet) is essential at this hose stiffness — a 3/8-inch high-pressure braided hose carries serious snap-back energy without it. The heavy-duty spring motor handles the larger hose, the all-steel frame stands up to fleet and shop abuse, and the brass swivel inlet is rated to match the reel's full 4,000 PSI capacity. The EZ-P-HP-325 fits fleet grease bays running high-volume chassis lube, heavy equipment service shops, hydraulic test facilities, and industrial plants where centralized lubrication routes need more flow than the smaller HP reels can supply.
Type: Spring Rewind Hose Reel | Series: EZ-Coil P Series (High Pressure) | Hose ID (in.): 3/8 | Hose OD (in.): 11/16 | Hose Length (ft): 25 | Hose Construction: SAE 100R1 or R2 Steel Wire Braid | Max Pressure (PSI): 4,000 | Max Temperature (°F): 212 (135 with water or synthetic fluids) | Service: Grease, Hydraulic Oil | Retraction: Spring Rewind with EZ-Coil Controlled Return | Approx. Weight (lbs): 49
Features
- EZ-Coil controlled retraction system slows hose rewind speed to prevent uncontrolled snap-back, critical with stiff high-pressure braided hose where rebound energy is highest
- All-steel frame and base with durable powder-coat finish for long service in industrial, fleet, and equipment-service environments
- Pre-mounted 25-foot, 3/8-inch ID hose furnished with SAE 100R1 or R2 steel wire braid construction — higher flow capacity than 1/4-inch HP reels while maintaining hydraulic-grade pressure rating
- 4,000 max PSI rating for grease and hydraulic oil delivery up to 212°F (135°F with water or synthetic fluids)
- Multi-position adjustable guide arm directs hose payout at floor, bench, or overhead angles to match installation
- Heavy-duty spring motor delivers consistent rewind tension on the larger braided hose and is rebuildable in the field for extended service life
- CNC-machined brass swivel inlet provides a leak-resistant connection rated to the full 4,000 PSI of the reel
- 49 lb body mounts to wall, ceiling, bench, floor, or vehicle with standard hardware
Made in USA: ![]()
Applications
- Fleet & truck lubrication bays — high-volume chassis grease delivery on Class 7 and Class 8 trucks, trailers, and tractors where 1/4-inch hose slows down the route
- Heavy equipment & construction service — greasing excavators, dozers, loaders, and haul trucks with high-flow grease guns and meter delivery systems
- Hydraulic shop & transfer work — bench and rolling hydraulic stands, jack and ram charging, oil transfer between reservoirs within the 4,000 PSI rating
- Centralized lubrication systems — distribution reels in industrial plants running high-volume automated or scheduled grease routes
- Agricultural & equipment dealer service — lubrication of combines, tractors, balers, and large implements where service time per machine matters
FAQs:
- Q: Why does the 3/8-inch HP reel have a lower PSI rating (4,000) than the 1/4-inch HP reel (5,000)?
A: Same hose construction class, larger inner diameter. For a given SAE 100R1 or R2 hose wall thickness and braid reinforcement, increasing the inner diameter reduces the maximum working pressure — there's more cross-section pushing outward on the braid. It's not a defect or a downgrade; it's physics. The EZ-P-HP-325 trades 1,000 PSI of top-end pressure for substantially higher flow capacity, which is the right trade for grease and hydraulic work that needs volume. - Q: When should I choose the 3/8-inch EZ-P-HP-325 over the 1/4-inch EZ-P-HP-125?
A: Pick the 3/8-inch reel when flow rate matters more than the last 1,000 PSI of working pressure. High-volume chassis grease bays, hydraulic fluid transfer, and any application moving meaningful volume through the hose benefit from the larger ID. Pick the 1/4-inch reel when working pressure is the constraint — high-pressure hydraulic test stands above 4,000 PSI, or any service routinely pressurized into the 4,000–5,000 PSI range. - Q: What does "SAE 100R1 or R2" mean?
A: SAE 100R1 and 100R2 are Society of Automotive Engineers specifications for hydraulic hose. R1 uses one layer of steel wire braid reinforcement; R2 uses two layers, giving a higher pressure rating and thicker construction. Coxreels furnishes the EZ-P-HP-325 with R1 or R2 hose depending on production lot and supplier; both meet or exceed the 4,000 PSI working pressure of the reel. - Q: Can I use this reel for water or pressure washing?
A: Not as a primary application. The EZ-P-HP-325 is rated specifically for grease and hydraulic oil. Water and synthetic fluids are permitted only up to 135°F, and the hose construction is optimized for petroleum fluids rather than continuous water service. For pressure washing and wash-bay work, use a medium-pressure or wash-bay-specific reel. - Q: What's the difference between the EZ-P-HP-325 and the standard P-HP-325?
A: Both reels share the same hose, pressure, temperature, and service ratings. The EZ-P-HP-325 adds the EZ-Coil controlled retraction system — on a 4,000 PSI braided 3/8-inch hose, that controlled rewind matters even more than on smaller HP reels. The hose is stiffer and heavier, the rebound force is higher, and an uncontrolled snap-back can do real damage. The standard P-HP-325 is a conventional spring rewind without the dampener.
| HOSE | LESS HOSE | SIZE INDEX |
|||||||
|---|---|---|---|---|---|---|---|---|---|
| SKU | I.D. | O.D. | FT. | PSI | APRX. LBS. |
EZ-COIL SKU | LESS HOSE SKU | APRX. LBS. |
|
|
LOW PRESSUREModels with hose are for air water service with a maximum temperature 150°F. Models less hose can be used for air, water or oil.
|
|||||||||
| P-LP-125 | 1/4" | 1/2" | 25 | 300 | 27 | EZ-P-LP-125 | P-LPL-125 | 24 | 1 |
| P-LP-130 | 1/4" | 1/2" | 30 | 300 | 27 | - | P-LPL-130 | 24 | 1 |
| P-LP-135 | 1/4" | 1/2" | 35 | 300 | 28 | EZ-P-LP-135 | P-LPL-135 | 25 | 1 |
| P-LP-140 | 1/4" | 1/2" | 40 | 300 | 38 | - | P-LPL-140 | 34 | 3 |
| P-LP-150 | 1/4" | 1/2" | 50 | 300 | 40 | EZ-P-LP-150 | P-LPL-150 | 35 | 3 |
| P-LP-325 | 3/8" | 5/8" | 25 | 300 | 28 | EZ-P-LP-325 | P-LPL-325 | 25 | 2 |
| P-LP-330 | 3/8" | 5/8" | 30 | 300 | 37 | EZ-P-LP-330 | P-LPL-330 | 33 | 3 |
| P-LP-335 | 3/8" | 5/8" | 35 | 300 | 38 | EZ-P-LP-335 | P-LPL-335 | 34 | 3 |
| P-LP-340 | 3/8" | 5/8" | 40 | 300 | 39 | - | P-LPL-340 | 34 | 3 |
| P-LP-350 | 3/8" | 5/8" | 50 | 300 | 43 | EZ-P-LP-350 | P-LPL-350 | 36 | 3 |
| P-LP-415 | 1/2" | 3/4" | 15 | 300 | 41 | - | P-LPL-415 | 38 | 4 |
| P-LP-425 | 1/2" | 3/4" | 25 | 300 | 44 | - | P-LPL-425 | 39 | 4 |
| P-LP-430 | 1/2" | 3/4" | 30 | 300 | 45 | EZ-P-LP-430 | P-LPL-430 | 40 | 4 |
| P-LP-450 | 1/2" | 3/4" | 50 | 300 | 48 | EZ-P-LP-450 | P-LPL-450 | 43 | 4 |
|
MEDIUM PRESSUREReels are furnished with standard one wire braid hose suitable for air, water or oil applications. Hose exceeds SAE R1 specifications. Maximum Temperature 212°F (If used with water, synthetic fluids 135°F max.)
|
|||||||||
| P-MP-320 | 3/8" | 1-1/16" | 20 | 3,000 | 46 | - | P-MPL-320 | 41 | 4 |
| P-MP-325 | 3/8" | 1-1/16" | 25 | 3,000 | 49 | - | P-MPL-325 | 42 | 4 |
| P-MP-330 | 3/8" | 1-1/16" | 30 | 3,000 | 51 | - | P-MPL-330 | 43 | 4 |
| P-MP-335 | 3/8" | 1-1/16" | 35 | 3,000 | 52 | - | P-MPL-335 | 43 | 4 |
| P-MP-420 | 1/2" | 13/16" | 20 | 2,500 | 47 | - | P-MPL-420 | 41 | 4 |
| P-MP-425 | 1/2" | 13/16" | 25 | 2,500 | 49 | EZ-P-MP-425 | P-MPL-425 | 42 | 4 |
| P-MP-430 | 1/2" | 13/16" | 30 | 2,500 | 51 | EZ-P-MP-430 | P-MPL-430 | 43 | 4 |
|
HIGH PRESSUREReels are furnished standard with S.A.E. 100R16 #1 or #2 wire braid hose suitable for grease and hydraulic oil applications. Maximum Temperature 212°F. (If used with water, synthetic fluids 135°F max.)
|
|||||||||
| P-HP-120 | 1/4" | 9/16" | 20 | 5,000 | 46 | - | P-HPL-120 | 41 | 4 |
| P-HP-125 | 1/4" | 9/16" | 25 | 5,000 | 48 | EZ-P-HP-125 | P-HPL-125 | 42 | 4 |
| P-HP-130 | 1/4" | 9/16" | 30 | 5,000 | 50 | - | P-HPL-130 | 43 | 4 |
| P-HP-135 | 1/4" | 9/16" | 35 | 5,000 | 51 | - | P-HPL-135 | 43 | 4 |
| P-HP-320 | 3/8" | 1-1/16" | 20 | 4,000 | 47 | - | P-HPL-320 | 41 | 4 |
| P-HP-325 | 3/8" | 1-1/16" | 25 | 4,000 | 49 | EZ-P-HP-325 | P-HPL-325 | 42 | 4 |
| P-HP-330 | 3/8" | 1-1/16" | 30 | 4,000 | 51 | - | P-HPL-330 | 43 | 4 |
Looking for more information about the Coxreels Hose Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Hose Reels, please call (800) 608-5210 or email info@intlairtool.com
- Type
- High Pressure Spring Rewind Hose Reel
- Series
- EZ-P Series
- Hose Inside Diameter (in.)
- 3/8
- Hose Outside Diameter (in.)
- 11/16
- Hose Length (ft.)
- 25
- Hose Included
- Yes
- Maximum Working Pressure (PSI)
- 4000
