Cleco 70EAN1500TA8MT NeoTek Corded Electric Nutrunner | 60 RPM | 277 - 1106 (ft-lbs) Torque Range | 1" Square Drive

When a large bolted joint needs high torque with controller-based tightening control, the Cleco 70EAN1500TA8MT NeoTek 70 Series right-angle corded electric nutrunner delivers a 375 - 1500 Nm / 277 - 1106 ft-lbs torque range for heavy assembly work. It's a 1" square drive that accepts compatible industrial sockets, while the right-angle head helps reach fasteners positioned near frames, flanges, housings, and other obstructions.

This NeoTek high torque nutrunner runs at 60 RPM, giving operators controlled rundown speed for large fasteners where repeatability matters more than fast, impact-style removal. The 70 Series platform supports digital communication, configurable LED light rings, repeatable transducer control, and controller-based fastening programs for production lines that need consistent results and traceable assembly data.

Type: Right Angle Corded Electric Nutrunner | Series: NeoTek 70 Series High Torque | Model: 70EAN1500TA8MT | Torque Range: 375 - 1500 Nm / 277 - 1106 ft-lbs | Speed: 60 RPM | Output Drive: 1" Sq. Drive | Weight: 11.8 kg / 26.0 lb | Length: 659 mm / 25.9 in | Side to Center: 42 mm / 1.65 in

Features:

• Repeatability and accuracy with 2.0 Cm/Cmk at +/- 7% for controlled fastening on quality-critical joints.
• High torque NeoTek 70 Series platform covers demanding assembly applications up to 4000 Nm within the product family.
• Configurable LED light rings provide visual status feedback for operators during fastening cycles.
• Digital communication between tool and controller supports reliable signal transfer in Cleco assembly systems.
• 60% speed increase over current legacy series tools helps reduce rundown time compared with older Cleco high torque platforms.
• Right angle head supports access to large fasteners where straight inline tools may not have working clearance.
• 1" square drive output is suited for compatible high-torque industrial sockets and production fastening fixtures.
• 70 Series tools require a 220/230 power supply to the controller.

Made in USA:

Applications:

• Heavy equipment assembly: Tightening large structural fasteners on machinery frames, housings, brackets, and welded assemblies.
• Heavy truck and trailer production: Controlled bolting on suspension, frame, axle, and chassis-related joints requiring high torque output.
• Rail and transportation equipment: Fastening large components where repeatable torque and documented assembly results support quality control.
• Energy and industrial manufacturing: Assembly of large fabricated components, support structures, gearbox housings, and bolted flanges.
• Production tooling departments: Integration into Cleco NeoTek fastening stations, reaction-arm setups, and controller-based assembly systems.

FAQs:

• Q: What is the torque range of the Cleco 70EAN1500TA8MT?
  A: The tool is specified at 375 - 1500 Nm, which equals approximately 277 - 1106 ft-lbs. Use this range for high-torque fastening applications that require controlled tightening rather than impact wrench breakaway force.
• Q: Is this model a right angle or inline nutrunner?
  A: The 70EAN1500TA8MT is a right angle corded electric nutrunner. A right angle head places the output drive at 90 degrees to the tool body, helping access fasteners close to frames, plates, and other structures.
• Q: Does this nutrunner use compressed air?
  A: No. This is a corded electric NeoTek nutrunner used with a compatible Cleco controller. It does not require an air compressor or FRL setup.
• Q: What power supply is required for the controller?
  A: Cleco notes that 70 Series tools require a 220/230 power supply to the controller. Confirm the controller model, plant voltage, regional electrical requirements, and cable setup before installation.
• Q: What sockets should be used with the 1" square drive?
  A: Pair the tool with compatible 1" drive impact-rated sockets and any required reaction tooling. For high-torque production fastening, socket fit, reaction management, and joint access should be reviewed before setup.

Looking for more information about Cleco Electric Nutrunner? Click here to view the Catalog

Need help selecting the correct Cleco Electric Nutrunners for your application? Please call (800) 608-5210 or email info@intlairtool.com
