Ingersoll Rand QP1T05S1TD Pistol Grip Air Screwdriver | 500 RPM | 2.7 - 47.8 (In-lbs) Torque Range | Adjustable Shut-Off Clutch

For production fastening applications that require higher torque capability with controlled automatic shut-off, the Ingersoll Rand QP1T05S1TD Pistol Grip Air Screwdriver combines 500 RPM free speed with a 2.7 to 47.8 in-lb torque range and an adjustable shut-off clutch. The clutch stops the fastening cycle when the preset torque point is reached, helping limit overtightening and supporting more consistent results during repetitive assembly work.

The Ingersoll Rand QP1T05S1TD pairs its slower 500 RPM speed with a broader torque range for compatible joints that require more turning force than higher-speed screwdriver configurations. Its pistol-grip layout supports controlled handling during horizontal, angled, and bench-level fastening tasks, while automatic clutch shut-off reduces reliance on the operator to manually determine the end of each tightening cycle. The result is a practical pneumatic fastening solution for production processes where torque control takes priority over maximum rundown speed.

Type: Pistol Grip Air Screwdriver | Model: QP1T05S1TD | Configuration: Pistol Grip | Free Speed: 500 RPM | Torque Range: 2.7 - 47.8 in-lbs | Clutch Type: Adjustable Shut-Off

Features: Adjustable shut-off clutch automatically stops the tool when the preset torque point is reached during fastening. 500 RPM free speed provides controlled screw rundown for compatible joints requiring increased torque capability. 2.7 to 47.8 in-lb torque range allows tool output to be adjusted for different fastening requirements within the specified range. Pistol-grip configuration provides practical handling for horizontal, angled, and general bench assembly positions. Automatic clutch shut-off helps reduce overtightening and supports more repeatable fastening across production cycles. Lower-speed configuration prioritizes torque capability and controlled rundown over rapid fastener installation. Pneumatic operation supports repeated fastening cycles when supplied with properly conditioned compressed air. Made in USA:

Applications:

• Appliance assembly — tightening compatible fasteners in housings, frames, brackets, panels, and mechanical subassemblies.
• Automotive component production — completing controlled fastening operations on parts and assemblies within the specified torque range.
• Electrical equipment manufacturing — installing screws in enclosures, cabinets, controls, and related equipment assemblies.
• General production assembly — handling repetitive fastening where automatic clutch shut-off helps maintain process consistency.
• Bench-level fastening — supporting horizontal and angled screwdriving tasks where pistol-grip handling and controlled rundown suit the workstation.

FAQs:

• Q: How does the adjustable shut-off clutch work on the QP1T05S1TD?
  A: The clutch is adjusted for the required fastening torque within the tool's specified range. When the preset torque point is reached, the screwdriver automatically shuts off, helping support repeatable fastening and reduce overtightening.
• Q: What types of fastening applications suit the 500 RPM speed?
  A: The slower speed is suited to compatible assembly joints where controlled rundown and increased torque capability are more important than achieving the fastest possible screw installation time.
• Q: What is the torque range of the Ingersoll Rand QP1T05S1TD?
  A: The specified range is 2.7 to 47.8 in-lbs. The correct setting should be established according to the fastener, joint characteristics, component material, and assembly requirements.
• Q: Why choose a pistol-grip screwdriver for assembly work?
  A: A pistol-grip configuration can provide practical hand positioning for horizontal, angled, and bench-level fastening tasks. The preferred tool style depends on fastener orientation, workstation layout, and operator access.
• Q: Does automatic shut-off eliminate the need to verify production torque?
  A: No. Joint characteristics, fastener condition, component materials, driver-bit fit, and air-supply conditions can affect final results. Establish the clutch setting on the actual production joint and verify completed fasteners using the required quality-control procedure.
