Ingersoll Rand M007RVR188BR6 Multi-Vane Reversible Air Motor | Planetary Gear | 0.61 HP | 94 RPM | 76.5 (ft-lbs) Starting Torque | 102 (ft-lbs) Stall Torque

Ingersoll Rand M007RVR188BR6 Multi-Vane Reversible Air Motor is engineered to deliver dependable pneumatic rotary power for industrial applications requiring bidirectional operation with very high torque at extremely low operating speeds. Built with a multi-vane design and planetary gearing, this air motor produces 0.61 HP while operating at a free speed of 94 RPM. Its reversible configuration enables both clockwise and counterclockwise shaft rotation, making it well suited for OEM machinery, automated production equipment, heavy-duty positioning systems, indexing mechanisms, material handling equipment, and other industrial applications requiring controlled directional movement.

The M007RVR188BR6 develops a 76.5 lb-ft starting torque, providing exceptional load-starting capability for demanding industrial applications, and delivers a 102 lb-ft stall torque, representing the maximum torque generated when the output shaft is prevented from rotating. The planetary gear system efficiently multiplies output torque while maintaining a compact motor assembly, making this model an excellent solution where substantial rotary force and compact installation dimensions are required.

Type: Multi-Vane Air Motor | Model: M007RVR188BR6 | Rotation: Reversible | Gear Type: Planetary Gear | Power: 0.61 HP | Free Speed: 94 RPM | Starting Torque: 76.5 lb-ft | Stall Torque: 102 lb-ft

Features:

• Multi-vane air motor delivers smooth and dependable rotary power using compressed air.
• Reversible configuration supports clockwise and counterclockwise shaft rotation for bidirectional industrial applications.
• Planetary gear system efficiently multiplies output torque while maintaining a compact motor footprint.
• 0.61 HP output supports demanding pneumatic drive applications.
• 94 RPM free speed is ideal for equipment requiring slow, controlled, high-torque rotary motion.
• 76.5 lb-ft starting torque provides exceptional load-starting capability for heavy-duty operating conditions.
• 102 lb-ft stall torque provides a manufacturer-published reference for evaluating maximum torque capacity.

Made in USA:

Applications:

• OEM machinery requiring reversible pneumatic rotary power.
• Automated manufacturing and assembly equipment.
• Industrial positioning, indexing, and transfer mechanisms.
• Material handling and conveying systems.
• Replacement applications where the published motor specifications match the original equipment.

FAQs:

• Q: Is the Ingersoll Rand M007RVR188BR6 reversible?
  A: Yes. This model is designed to operate in both clockwise and counterclockwise directions for applications requiring bidirectional rotation.
• Q: What is the advantage of the planetary gear system?
  A: The planetary gear arrangement efficiently transfers power while increasing output torque in a compact motor package, making it suitable for industrial equipment requiring very high torque at extremely low operating speeds.
• Q: What is the rated free speed?
  A: The manufacturer specifies a free speed of 94 RPM.
• Q: What is the difference between starting torque and stall torque?
  A: Starting torque is the torque available when the motor begins rotating from rest, while stall torque is the maximum torque produced when the output shaft is prevented from rotating.
• Q: What should be verified before installation?
  A: Confirm horsepower, free speed, rotation direction, gear configuration, shaft dimensions, mounting arrangement, and compressed-air requirements using the Ingersoll Rand Air Motor Catalog before installation.

Looking for more information about Ingersoll Rand Air Motor? Click here to view the Catalog

For help selecting the correct Ingersoll Rand Air Motors for your assembly application, call (800) 608-5210 or email info@intlairtool.com
