When a wet, corrosive, or cleanliness-sensitive work area needs more hose reach, the Coxreels P-LPL-350-SS stainless steel spring rewind hose reel stores up to 50 feet of 3/8-inch I.D. hose. Its 300 PSI maximum pressure rating supports compatible low-pressure fluid applications, while the narrow single-pedestal frame helps conserve mounting space in food and chemical processing facilities, marinas, washdown areas, and other locations where rust and contamination are ongoing concerns.
The P-SS Series combines electro-polished stainless steel construction with a stainless steel external fluid path for clean, non-corrosive operation. A machined stainless steel 90-degree full-flow NPT swivel inlet helps maintain fluid flow through the reel connection, and the nitrile swivel seals use non-toxic food-grade grease. The enclosed cartridge-style spring motor automatically retracts the hose after use, while the multi-position lock ratchet secures it at the working length selected by the operator.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
Type: Stainless Steel Spring Rewind Hose Reel | Series: P-SS Series | Model: P-LPL-350-SS | Configuration: Less Hose | Hose I.D.: 3/8" | Hose O.D.: 5/8" | Hose Capacity: 50 ft | Maximum Pressure: 300 PSI | Overall Dimensions: 6.75" W x 18.63" H x 17.13" L | Mounting Pattern: 4" M x 5" N | Base Dimensions: 6" X x 6" Y
Features:
- Electro-polished stainless steel construction and stainless steel fluid paths provide clean, non-corrosive performance.
- Machined stainless steel 90-degree full-flow NPT swivel inlet supports an unrestricted external fluid path.
- Nitrile swivel seals are lubricated with non-toxic food-grade grease.
- Single-pedestal, space-saving configuration helps organize hose in compact mounting areas.
- Solid one-piece 1/4-inch stainless steel base and support post provide stability without welded base construction.
- Electro-polished stainless steel, lubricated, enclosed cartridge-style spring motor can be removed for maintenance.
- Multi-position lock ratchet mechanism secures the hose at the desired working length.
- Stainless steel guide arm adjusts for wall, floor, ceiling, and vehicle mounting positions.
Made in USA:
Applications:
- Food and beverage processing areas requiring corrosion-resistant hose storage around production or washdown equipment.
- Chemical processing facilities using compatible low-pressure fluid lines in wet or contamination-sensitive locations.
- Marinas, docks, boat-service facilities, and coastal work areas exposed to moisture or salt air.
- Bottling and packaging operations where cleanable stainless steel equipment is preferred.
- Industrial maintenance departments needing 50 feet of hose reach across larger service or cleanup areas.
- Mobile service vehicles and compact work bays where a narrow single-pedestal reel simplifies installation.
FAQs:
- Q: Does the Coxreels P-LPL-350-SS include hose?
A: No. This is a less-hose reel supplied without hose installed. A compatible 3/8-inch I.D. hose must be purchased separately, and Coxreels states that hose stops are not supplied with less-hose reels. - Q: What hose outside diameter can this reel accommodate?
A: The listed 50-foot capacity applies to hose with a maximum outside diameter of 5/8 inch. A hose with a larger outside diameter may reduce the amount that can be stored on the drum. - Q: Can this reel be mounted overhead or on a wall?
A: Yes. The adjustable stainless steel guide arm supports wall, floor, ceiling, and vehicle mounting positions. The mounting surface and hardware must support the reel, installed hose, fittings, and operating forces. - Q: What is the advantage of the single-pedestal frame?
A: The single-pedestal design keeps the reel width to 6.75 inches, helping it fit into restricted mounting areas. Its solid one-piece base and support post provide a stable platform for the reel drum. - Q: Is the P-LPL-350-SS suitable for food-processing environments?
A: Its electro-polished stainless steel construction, stainless steel fluid path, and nitrile seals lubricated with non-toxic food-grade grease support use where cleanliness and corrosion resistance matter. The separately selected hose and fittings must also meet the facility's sanitation and fluid-compatibility requirements.
| LESS HOSE | SIZE INDEX |
|||||
|---|---|---|---|---|---|---|
| LESS HOSE SKU | I.D. | O.D. | FT. | PSI | APRX. LBS. | |
|
P SERIES
|
||||||
| P-LPL-335-SS | 3/8" | 1/2" | 35 | 300 | 34 | 1 |
| P-LPL-350-SS | 3/8" | 5/8" | 50 | 300 | 39 | 1 |
| P-LPL-425-SS | 1/2" | 3/4" | 25 | 300 | 39 | 2 |
|
SH & MP SERIES
|
||||||
| SHL-N-350-SS | 3/8" | 5/8" | 50 | 300 | 44 | 3 |
| SHL-N-450-SS | 1/2" | 3/4" | 50 | 300 | 46 | 3 |
| SHL-N-525-SS | 3/4" | 1-1/16" | 25 | 300 | 45 | 4 |
| MPL-N-350-SS | 3/8" | 1-1/16" | 50 | 3,000 | 53 | 3 |
| MPL-N-450-SS | 1/2" | 1-3/16" | 50 | 2,500 | 53 | 3 |
|
T SERIES
|
||||||
| TSHL-N-350-SS | 3/8" | 5/8" | 50 | 300 | 55 | 5 |
| TSHL-N-375-SS | 3/8" | 5/8" | 75 | 300 | 73 | 6 |
| TSHL-N-3100-SS | 3/8" | 5/8" | 100 | 300 | 74 | 6 |
| TSHL-N-450-SS | 1/2" | 3/4" | 50 | 300 | 55 | 5 |
| TSHL-N-475-SS | 1/2" | 3/4" | 75 | 300 | 71 | 6 |
| TSHL-N-4100-SS | 1/2" | 3/4" | 100 | 300 | 80 | 6 |
| TSHL-N-550-SS | 3/4" | 1-1/16" | 50 | 300 | 70 | 7 |
| TMPL-N-3100-SS | 3/8" | 1-1/16" | 100 | 3,000 | 82 | 6 |
| TMPL-N-4100-SS | 1/2" | 1-3/16" | 100 | 3,000 | 80 | 6 |
|
EN SERIES
|
||||||
| ENL-N-335-SS | 3/8" | 5/8" | 35 | 300 | 46 | 8 |
| ENL-N-350-SS | 3/8" | 5/8" | 50 | 300 | 58 | 9 |
| ENL-N-425-SS | 1/2" | 3/4" | 25 | 300 | 63 | 8 |
| ENL-N-450-SS | 1/2" | 3/4" | 50 | 300 | 61 | 9 |
| ENML-N-335-SS | 3/8" | 1-1/16" | 35 | 3,000 | 64 | 8 |
| ENML-N-350-SS | 3/8" | 1-1/16" | 50 | 3,000 | 80 | 9 |
| ENML-N-425-SS | 1/2" | 1-3/16" | 25 | 2,500 | 61 | 8 |
| ENML-N-450-SS | 1/2" | 1-3/16" | 50 | 2,500 | 82 | 9 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
- Type
- Spring Rewind Hose Reel
- Series
- P-SS Series
- Hose Inside Diameter (in.)
- 3/8
- Hose Outside Diameter (in.)
- 5/8
- Hose Length (ft.)
- 50
- Hose Included
- No
- Maximum Working Pressure (PSI)
- 300
- Width (in.)
- 6.75
- Height (in.)
- 18.63
- Length (in.)
- 17.13
- Mounting Pattern (in.)
- 4M
- Mounting Pattern (in.)
- 5N
- Base (in.)
- 6X
- Base (in.)
- 6Y
