Ingersoll Rand M004RHR011AR3 Multi-Vane Non-Reversible Air Motor is engineered to provide dependable pneumatic rotary power for equipment that requires consistent one-direction operation. Rated at 0.44 HP with a free speed of 1,490 RPM, this multi-vane air motor is well suited for OEM machinery, automation systems, conveyors, and industrial equipment where compressed air is the preferred power source. Its non-reversible configuration simplifies integration into applications that do not require reverse rotation while delivering reliable rotary performance.
This model develops 3.92 lb-ft of starting torque, providing the rotational force needed to begin moving a connected load, and 5.22 lb-ft of stall torque, which represents the maximum torque generated when the output shaft is prevented from turning. These published performance values allow engineers and maintenance professionals to properly match the motor to the speed and load requirements of compatible equipment.
Type: Multi-Vane Air Motor | Model: M004RHR011AR3 | Rotation: Non-Reversible | Power: 0.44 HP | Speed: 1,490 RPM | Starting Torque: 3.92 lb-ft | Stall Torque: 5.22 lb-ft
Features:
- Multi-vane pneumatic motor converts compressed air into dependable rotary motion.
- Non-reversible design is intended for machinery requiring continuous operation in one rotational direction.
- 0.44 HP output provides reliable pneumatic drive power for compatible industrial equipment.
- 1,490 RPM operating speed balances rotational speed with increased torque output.
- 3.92 lb-ft starting torque assists in overcoming initial load resistance during startup.
- 5.22 lb-ft stall torque serves as a reference for evaluating maximum load conditions.
Made in USA:
Applications:
- OEM machinery requiring dependable single-direction pneumatic drive power.
- Industrial automation and assembly equipment.
- Conveyor and material handling systems compatible with the specified speed and torque.
- Packaging and processing equipment utilizing compressed-air-powered rotary motion.
- Maintenance replacement applications where the published performance ratings match the existing motor.
FAQs:
- Q: Can the M004RHR011AR3 operate in reverse?
A: No. This model is manufactured as a non-reversible air motor for applications requiring rotation in only one direction. - Q: What is the rated operating speed?
A: The catalog specifies a free speed of 1,490 RPM. - Q: What does starting torque indicate?
A: Starting torque is the amount of torque available when the motor begins rotating the connected load. This model is rated at 3.92 lb-ft. - Q: What is stall torque?
A: Stall torque is the maximum torque developed when the output shaft is prevented from rotating. The M004RHR011AR3 has a published stall torque of 5.22 lb-ft. - Q: What should be verified before replacing an existing air motor?
A: Confirm horsepower, operating speed, torque ratings, rotation direction, shaft dimensions, mounting configuration, and pneumatic specifications using the manufacturer catalog before installation.
| SKU | Max. Power | Speed at Max. Power | Free Speed | Starting Torque | Stall Torque | Air Consumption at Max. Power | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| hp | kw | rpm | rpm | lb-ft | Nm | lb-ft | Nm | scfm | m³/m | lb | kg | |
| Non-Reversible — Direction of rotation is counterclockwise when facing the shaft | ||||||||||||
| M004RHR000AR3 | 0.50 | 0.37 | 10,000 | 18,000 | 0.40 | 0.54 | 0.53 | 0.72 | 20.0 | 0.57 | 2 1/16 | 0.95 |
| M004RHR004AR3 | 0.47 | 0.35 | 2,470 | 4,450 | 1.46 | 1.98 | 1.94 | 2.63 | 19.5 | 0.55 | 2 3/16 | 1.00 |
| M004RHR006AR3 | 0.47 | 0.35 | 1,490 | 2,680 | 2.42 | 3.28 | 3.22 | 4.37 | 19.5 | 0.55 | 2 3/16 | 1.00 |
| M004RHR011AR3 | 0.44 | 0.33 | 825 | 1,490 | 3.92 | 5.32 | 5.22 | 7.08 | 19.0 | 0.54 | 2 3/8 | 1.09 |
| M004RHR015AR3 | 0.44 | 0.33 | 610 | 1,095 | 5.32 | 7.21 | 7.10 | 9.63 | 19.0 | 0.54 | 2 3/8 | 1.09 |
| M004RHR023AR3 | 0.44 | 0.33 | 395 | 715 | 8.10 | 11.0 | 10.8 | 14.6 | 19.0 | 0.54 | 2 3/8 | 1.09 |
| M004RHR033AR3 | 0.44 | 0.33 | 280 | 505 | 11.5 | 15.6 | 15.4 | 20.8 | 19.0 | 0.54 | 2 3/8 | 1.09 |
| M004RHR050AR3 | 0.41 | 0.31 | 175 | 315 | *16.5 | *22.4 | *22.1 | *30.0 | 18.5 | 0.52 | 2 11/16 | 1.22 |
| M004RHR083AR3 | 0.41 | 0.31 | 106 | 190 | *27.5 | *37.3 | *36.7 | *49.7 | 18.5 | 0.52 | 2 11/16 | 1.22 |
| M004RHR167AR3 | 0.41 | 0.31 | 53 | 95 | *55.0 | *74.5 | *73.3 | *99.4 | 18.5 | 0.52 | 2 11/16 | 1.22 |
| Reversible | ||||||||||||
| M004RVR000AR3 | 0.40 | 0.30 | 8,000 | 16,000 | 0.32 | 0.43 | 0.42 | 0.57 | 19.0 | 0.54 | 2 1/16 | 0.95 |
| M004RVR004AR3 | 0.37 | 0.28 | 1,975 | 3,955 | 1.13 | 1.53 | 1.51 | 2.05 | 18.5 | 0.52 | 2 3/16 | 1.00 |
| M004RVR006AR3 | 0.37 | 0.28 | 1,190 | 2,380 | 1.88 | 2.55 | 2.51 | 3.40 | 18.5 | 0.52 | 2 3/16 | 1.00 |
| M004RVR011AR3 | 0.34 | 0.25 | 660 | 1,325 | 3.00 | 4.07 | 4.00 | 5.42 | 18.0 | 0.51 | 2 3/8 | 1.09 |
| M004RVR015AR3 | 0.34 | 0.25 | 485 | 975 | 4.07 | 5.52 | 5.43 | 7.36 | 18.0 | 0.51 | 2 3/8 | 1.09 |
| M004RVR023AR3 | 0.34 | 0.25 | 315 | 635 | 6.23 | 8.45 | 8.30 | 11.2 | 18.0 | 0.51 | 2 3/8 | 1.09 |
| M004RVR033AR3 | 0.34 | 0.25 | 225 | 450 | 8.85 | 12.0 | 11.8 | 16.0 | 18.0 | 0.51 | 2 3/8 | 1.09 |
| M004RVR050AR3 | 0.31 | 0.23 | 140 | 280 | *12.3 | *16.7 | *16.5 | *22.4 | 17.5 | 0.50 | 2 11/16 | 1.22 |
| M004RVR083AR3 | 0.31 | 0.23 | 84 | 169 | *20.6 | *27.9 | *27.5 | *37.3 | 17.5 | 0.50 | 2 11/16 | 1.22 |
| M004RVR167AR3 | 0.31 | 0.23 | 42 | 85 | *41.3 | *56.0 | *55.0 | *74.5 | 17.5 | 0.50 | 2 11/16 | 1.22 |
