Coxreels TSHL-N-450-BBX DEF Supreme Duty Spring Rewind Hose Reel | DEF-T Series | 1/2" Hose Diameter | 50' Hose Length | 300 Max PSI | Less Hose

When you need a bare reel platform for Diesel Exhaust Fluid dispensing, the Coxreels TSHL-N-450-BBX DEF Supreme Duty spring rewind hose reel provides controlled hose storage for custom DEF transfer setups. This DEF-T Series reel is sized for 1/2" I.D. hose with up to 50 ft of capacity, giving fleet shops, DEF storage systems, service trucks, and dispensing stations a cleaner way to manage hose reach between fill points. The 300 PSI maximum pressure rating supports low-pressure DEF handling applications, while the stainless steel 90° full-flow NPT swivel and Viton seals are selected for Diesel Exhaust Fluid compatibility.

The T Series Supreme Duty frame uses Coxreels’ Super Hub dual axle support system, which adds stability to the drum during payout and rewind. Its lubricated, enclosed cartridge-style spring motor supports serviceable rewind performance, while CNC spun ribbed discs with rolled edges help protect the hose path and add structural strength. With a compact 9-3/8" W x 21-1/4" H x 19-1/2" L footprint and 55 lb ship weight, this less-hose reel is suited to installations where buyers need to specify their own compatible DEF hose assembly.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind DEF Hose Reel | Series: DEF-T Series | Model: TSHL-N-450-BBX | Configuration: Less Hose | Hose I.D.: 1/2" | Hose O.D.: 3/4" | Hose Capacity: 50 ft | Max Pressure: 300 PSI | Ship Weight: 55 lbs | Overall Dimensions: 9-3/8" W x 21-1/4" H x 19-1/2" L | Mounting Pattern: 7" M x 8" N | Base: 8" X x 9" Y | Swivel: Stainless Steel 90° Full-Flow NPT | Seal Material: Viton

Features:

• Stainless steel 90° full-flow NPT swivel supports Diesel Exhaust Fluid dispensing applications and provides service access for seal maintenance.
• Viton seals provide chemical resistance for DEF handling requirements.
• Super Hub dual axle support system increases reel stability during operation, reduces vibration, and strengthens the reel structure.
• Lubricated and enclosed cartridge-style spring motor is removable for safe and convenient maintenance.
• CNC robotically spun and ribbed discs with rolled edges add strength while helping protect the hose during payout and rewind.
• Multi-position lock ratchet mechanism secures the hose at the desired working length during dispensing.
• Professional grade steel construction supports stationary and rugged mobile installations.
• CPC powder coat finish helps protect the reel frame in shop, fleet, and service environments.

Made in USA:

2 Year Warranty

Applications:

• Fleet maintenance shops - organizing DEF dispensing hose for trucks, buses, delivery vehicles, and off-road equipment.
• DEF tote and bulk storage systems - adding spring rewind hose storage to fixed dispensing points.
• Mobile lube and service trucks - keeping DEF hose contained on vehicles where storage space and fast access both matter.
• Transportation yards - supporting routine Diesel Exhaust Fluid fills while reducing loose hose across service lanes.
• Equipment maintenance pads - managing low-pressure DEF transfer hose near agricultural, construction, and municipal equipment.

FAQs:

• Q: What does less hose mean for the TSHL-N-450-BBX?
  A: It means this reel is supplied without hose installed. The buyer must provide a compatible 1/2" I.D. DEF dispensing hose separately.
• Q: Is this reel built for Diesel Exhaust Fluid?
  A: Yes. The DEF-T Series uses a stainless steel 90° full-flow NPT swivel and Viton® seals for DEF dispensing applications. Hose, fittings, nozzles, and other system parts should also be verified for DEF compatibility.
• Q: What hose size should be used with this reel?
  A: This model is listed for 1/2" I.D. hose with a 7/8" O.D. and 50 ft capacity. Do not exceed the listed hose outside diameter if you need the reel to hold the full stated length.
• Q: Can this reel be used on a service truck?
  A: Yes, Coxreels lists DEF Series reels for stationary and rugged mobile applications. Confirm mounting surface strength, clearance, fastener selection, and hose routing before installing the reel on a vehicle.
• Q: What is the maximum pressure rating?
  A: The TSHL-N-450-BBX is rated for 300 PSI maximum pressure. Use it only within the listed pressure rating and with compatible DEF hose and fittings.
