Ingersoll Rand QP1S05C1D Pistol Grip Air Screwdriver is a pneumatic precision fastening tool designed for assembly operations that require controlled low-speed fastening and repeatable torque output. Equipped with a 500 RPM free speed, a 2.7–47.8 in-lbs torque range, and an adjustable cushion clutch, this screwdriver provides smooth torque application for fastening tasks where accuracy is more important than maximum speed.
QP1S05C1D features a comfortable pistol grip design that promotes operator control during repetitive production work. Its adjustable cushion clutch gradually disengages as the preset torque is reached, helping improve fastening consistency across general industrial assembly applications.
Tool Type: Pistol Grip Air Screwdriver | Free Speed: 500 RPM | Torque Range: 2.7–47.8 in-lbs | Clutch Type: Adjustable Cushion Clutch
|
Features:
Made in USA: |
 |
Applications:
- General industrial assembly requiring controlled low-speed fastening.
- Electronics, appliance, and automotive component manufacturing.
- Light mechanical assembly where repeatable torque is critical.
- Production workstations performing repetitive screwdriving operations.
- Precision fastening applications benefiting from an adjustable cushion clutch.
FAQs:
- Q: What torque range does the QP1S05C1D provide?
A: This pistol grip air screwdriver offers an adjustable torque range of 2.7–47.8 in-lbs. - Q: What is the benefit of the adjustable cushion clutch?
A: The adjustable cushion clutch disengages smoothly at the preset torque to help improve fastening consistency and reduce the chance of overtightening. - Q: What is the free speed of this screwdriver?
A: The QP1S05C1D operates at a free speed of 500 RPM. - Q: Why would I choose a 500 RPM screwdriver?
A: A lower operating speed provides increased control during precision fastening applications where careful torque application is important. - Q: What applications is this tool intended for?
A: It is designed for precision assembly and repetitive production fastening operations requiring controlled torque and dependable pneumatic performance.
| SKU | Soft Joint Torque Range | Medium Joint Torque Range | Hard Joint Torque Range | Free Speed | Weight | Overall Length | Chuck Diameter | Drive Size | Air Consumption |
|---|---|---|---|---|---|---|---|---|---|
| IN-LBS (NM) | IN-LBS (NM) | IN-LBS (NM) | RPM | LBS (KG) | IN (MM) | IN (MM) | IN | CFM (L/MIN) | |
| Push-to-Start | |||||||||
| QP1P20C1D | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 22.1 (0.9 – 2.5) | – | 2,000 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| QP1P10C1D | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 22.1 (0.9 – 2.5) | 13.3 – 39.8 (1.5 – 4.5) | 1,000 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| QP1P05C1D | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 28.3 (0.9 – 3.2) | 13.3 – 47.8 (1.5 – 5.4) | 500 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| Trigger Start | |||||||||
| QP1S10C1D | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 22.1 (0.9 – 2.5) | 13.3 – 39.8 (1.5 – 4.5) | 1,000 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| QP1S10C1TD* | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 22.1 (0.9 – 2.5) | 13.3 – 39.8 (1.5 – 4.5) | 1,000 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| QP1S05C1D | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 28.3 (0.9 – 3.2) | 13.3 – 47.8 (1.5 – 5.4) | 500 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| QP1S05C1TD* | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 28.3 (0.9 – 3.2) | 13.3 – 47.8 (1.5 – 5.4) | 500 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| QP1S02C1TD* | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 28.3 (0.9 – 3.2) | 13.3 – 47.8 (1.5 – 5.4) | 250 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
| Trigger + Push-to-Start | |||||||||
| QP1T10C1D | 2.7 – 9.7 (0.3 – 1.1) | 8.0 – 22.1 (0.9 – 2.5) | 13.3 – 39.8 (1.5 – 4.5) | 1,000 | 1.9 (0.8) | 8.8" (223) | 0.6" (15) | 1/4" | 16 (450) |
Looking for more information about Ingersoll Rand Screwdriver? Click here to view the Catalog
For help choosing the correct Ingersoll Rand Screwdrivers for your application, please call (800) 608-5210 or email info@intlairtool.com
- Type
- Screwdriver
- Grip Style
- Pistol
- Actuation
- Trigger Start
- Torque Range (in-lbs)
- 2.7 - 47.8
- RPM
- 500
- Length (in.)
- 8.8
- Side to Center (in.)
- 0.6
- Drive Size (in.)
- 1/4
- Drive Type
- Hex Quick Change
- Sound Level (dbA)
- 75
- Air Inlet
- 1/4" NPT
- Hose Size (in.)
- 1/4
