For indoor workstations where the hose, cord, and electrical accessory need to be selected separately, the Coxreels C-L350L-5012L-X Dual Purpose Electric/Air spring rewind reel provides reel-only air and electric cord management in the C Air-Electric Series platform. This less-hose configuration is sized for 3/8" I.D. hose with a 50 ft hose capacity, is rated for 300 PSI, and is built for a 12/3 AWG, 50 ft cord capacity with a 25 amp reel rating.
The C-L350L-5012L-X uses spring rewind, a spring-powered retraction system that returns the hose and cord after use when compatible hose and cord are installed. Coxreels C Series combination reels operate as two independent self-retracting assemblies in one compact unit, helping reduce mounting space compared with installing separate air and electric reels. The single expanded steel mounting base provides one mounting pattern, while the multi-position lock ratchet, enclosed cartridge-style spring motor, adjustable guide arm, solid brass full-flow NPT swivel, nitrile swivel seals, 1" solid steel axle, and CPC powder coat finish help support organized air and electrical access in shop, repair, maintenance, and service environments.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
*Additional note: This model is also a less-cord and less-accessory configuration. Compatible electrical cord and end accessory must be supplied separately and installed according to applicable electrical requirements.
Type: Dual Purpose Electric/Air Spring Rewind Reel | Series: C Air-Electric Series | SKU: C-L350L-5012L-X | Configuration: Less Hose, Less Cord, Less Accessory | Hose Included: No | Cord Included: No | Electrical Accessory: Less Accessory | Hose I.D.: 3/8" | Hose O.D.: 5/8" | Hose Capacity: 50 ft | Max Pressure: 300 PSI | Cord Capacity: 50 ft | Cord Gauge Capacity: 12/3 AWG | Electrical Rating: 115 V, 25 Amps, 60 Hz Single Phase | Service: Air, Electric | Rewind Type: Spring Rewind | Ship Weight: 71 lb | Overall Dimensions: 16" W x 18.63" H x 17" L | Mounting Pattern: 7" M x 8" N | Base: 8" X x 9" Y
Features:
- Dual purpose C Air-Electric Series design combines air hose and electrical cord management in one compact reel assembly.
- Less-hose, less-cord, less-accessory configuration allows the buyer to install hose, cord, and electrical end accessory selected for the workstation requirements.
- Independent spring rewind assemblies allow the air hose and electric cord to be pulled out and retracted separately after compatible hose and cord are installed.
- Single expanded 1/4" steel mounting base adds stability and reduces installation time compared with mounting two separate reels.
- Multi-position lock ratchet mechanism secures the installed hose or cord at the desired working length during use.
- Enclosed factory tuned cartridge-style spring motor is designed for controlled rewind operation and service accessibility.
- External air path uses a machined solid brass 90° full-flow NPT swivel inlet with nitrile swivel seals.
- Less-cord configuration does not include the 5 ft lead cable and grounding plug supplied with standard cord-included models.
- Guide arm adjusts for wall, floor, and overhead mounting positions.
- CPC powder coat finish, rolled ribbed discs, 1" solid steel axle, and lubricated precision bearings support smooth rotation and routine indoor shop use.
Made in USA:
Applications:
- Indoor repair bays and service stations where buyers want one mounted reel assembly for separately selected air hose and electrical cord.
- Fleet maintenance garages where a single reel base helps organize air and power access at a shared service point.
- Production benches, maintenance cells, and assembly areas where hose and cord specifications need to match site standards.
- Automotive, equipment, and facility maintenance areas requiring 50 ft capacity for compatible 3/8" low-pressure air hose.
- Installations where the electrical cord and end accessory will be supplied separately to match circuit, plug, receptacle, or jobsite requirements.
- Wall, floor, bench, or overhead mounting locations where one combined spring rewind reel is preferred over two separate reel assemblies.
FAQs:
- Q: Does the Coxreels C-L350L-5012L-X include hose?
A: No. This is a less-hose model, so it is supplied without hose installed. The reel is sized for up to 50 ft of 3/8" I.D. hose with a 5/8" hose O.D. - Q: Does this model include an electrical cord?
A: No. The C-L350L-5012L-X is a less-cord configuration. It is built for 50 ft of 12/3 AWG cord capacity, but the cord must be supplied separately. - Q: What does less accessory mean?
A: It means the reel is supplied without a listed electrical end accessory such as a receptacle, light, or other cord-end device. The accessory should be selected and installed according to the application and applicable electrical requirements. - Q: How is the C-L350L-5012L-X different from the C-L350-5012-X?
A: The C-L350-5012-X includes hose and cord but is supplied less accessory. The C-L350L-5012L-X is supplied less hose, less cord, and less accessory for buyers who need to supply those items separately. - Q: Is this reel for indoor or outdoor use?
A: The manufacturer catalog identifies the C Series air/electric models for indoor use only. Installation should follow applicable national and local electrical codes. - Q: Can this reel be used for pressure washing?
A: No. The air side is rated for 300 PSI low-pressure service. Pressure washing requires a reel, hose, fittings, and accessories rated for the pressure washer's operating pressure.
| HOSE & CORD | SIZE INDEX |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SKU | ACCESSORY | AWG / NO COND. |
CORD FT. |
TYPE | AMPS. | I.D. | O.D. | FT. | PSI | APRX. LBS. |
|
|
FOR INDOOR USE ONLY!Coxreels electric and pneumatic hose reels operate as two independent, self-retracting 50 foot trouble-free assemblies. All Models rated: 115 volts, 3*conductors, 60hz single phase.
|
|||||||||||
| C-L350-5016-A | Single Industrial Receptacle† |
16 / 3 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 |
| C-L350-5012-A | Single Industrial Receptacle† |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 84 | 1 |
| C-L350-5012-B | Quad “4 Plug” Industrial Receptacle† |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 85 | 1 |
| C-L350-5016-F | Duplex G.F.C.I. Metal Industrial Receptacle† |
16 / 3 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 |
| C-L350-5012-F | Duplex G.F.C.I. Metal Industrial Receptacle† |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 84 | 1 |
| C-L350-5016-E | Caged Drop Light with Tool Tap Plug† |
16 / 3 | 50 | SJTO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 |
| C-L350-5016-H | Industrial Duty LED Light† |
16 / 3 | 50 | SJTO | .17 | 3/8" | 5/8" | 50 | 300 | 79 | 1 |
| C-L350-5016-K | Super-Bright LED Light with Tool Tap on Handle |
16 / 3 | 50 | SJTO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 |
| C-L350-5016-M | Compact Super-Bright LED Light |
16 / 3 | 50 | SJTO | .17 | 3/8" | 5/8" | 50 | 300 | 79 | 1 |
| C-L350-5016-X | With Hose, With Cord, Less Accessory |
16 / 3 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 78 | 1 |
| C-L350-5012-X | With Hose, With Cord, Less Accessory |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 83 | 1 |
| C-L350-5012-4 | With Hose, With Cord, Less Accessory |
12 / 4 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 86 | |
| C-L350L-5016L-X | Less Hose, Less Cord, Less Accessory |
16 / 3 | 50 | N/A | 25 | 3/8" | 5/8" | 50 | 300 | 71 | 1 |
| C-L350L-5012L-X | Less Hose, Less Cord, Less Accessory |
12 / 3 | 50 | N/A | 25 | 3/8" | 5/8" | 50 | 300 | 71 | 1 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
