Coxreels C-L350-5012-4 is a dual purpose electric/air spring rewind reel from the C Series, designed to combine retractable air hose and retractable power cord storage in one compact assembly. This model includes a 50 ft hose length with 3/8" hose I.D., a 300 PSI maximum pressure rating, and a 50 ft 12/4 SJO cord rated for 13 amps at 115 volts, making it a space-saving solution for workstations that need both compressed air and electrical access from the same mounted reel location.
Built for indoor air/electric applications, the C-L350-5012-4 operates as two independent self-retracting assemblies: one for hose and one for cord. This helps keep air lines and power cords off the floor, reduces clutter around service bays and workstations, and provides one shared mounting pattern instead of installing two separate reels. The -4 configuration is supplied with hose and cord but less accessory, allowing the buyer to select the compatible end accessory or outlet setup required for the application.
Type: Dual Purpose Electric/Air Spring Rewind Reel | Series: C Series | Model: C-L350-5012-4 | Configuration: With Hose, With Cord, Less Accessory | Hose I.D.: 3/8" | Hose O.D.: 5/8" | Hose Length: 50 ft | Max Pressure: 300 PSI | Cord Size: 12/4 AWG | Cord Type: SJO | Cord Length: 50 ft | Amps: 13 | Volts: 115 | Electrical Rating: 60 Hz Single Phase | Use: Indoor Use Only | Approx. Ship Weight: 86 lbs
Features:
- Dual purpose air/electric reel combines one retractable air hose reel and one retractable power cord reel in a compact two-reel assembly.
- Each reel operates independently, allowing users to pull out only the air hose, only the power cord, or both as needed for the task.
- 50 ft of 3/8" I.D. hose provides practical compressed-air reach for service bays, benches, maintenance areas, and workstation use.
- 300 PSI pressure rating supports compatible air service when the system pressure, hose, fittings, and connected pneumatic equipment match the reel rating.
- 50 ft of 12/4 SJO cord provides electrical reach for compatible 115 volt applications while allowing the buyer to add the required end accessory separately.
- Less accessory configuration is supplied with hose and cord but without the final cord-end accessory, giving users flexibility to match the connection style to the installation.
- Single mounting pattern helps reduce installation time compared with mounting two separate reels at the same station.
- External fluid path with machined solid brass 90° full-flow NPT swivel inlet supports air delivery and routine service access.
- External CPC powder coated steel component cover allows simpler routine maintenance access to the electrical slip ring area.
- Guide arm adjusts to wall, floor, and overhead mounting positions for flexible installation and hose or cord payout direction.
- Enclosed factory-tuned cartridge-style spring motors retract the hose and cord after use.
- Multi-position lock ratchet mechanisms secure the hose and cord at the desired working lengths during operation.
Made in USA:
Applications:
- Automotive, fleet, and equipment service bays where technicians need compressed air and 115 volt power from the same workstation.
- Maintenance shops and MRO areas where one mounted reel station can help manage both pneumatic hose and electrical cord.
- Manufacturing, assembly, and repair workstations that need organized point-of-use air and power access.
- Garages, warehouses, and indoor industrial work areas where retractable hose and cord storage helps reduce clutter around floors and benches.
- Service areas where space is limited and one dual purpose reel may be preferred over two separately mounted reels.
FAQs:
- Q: Does the Coxreels C-L350-5012-4 include both hose and cord?
A: Yes. This model is listed as with hose and with cord, but less accessory. The final cord-end accessory or outlet setup must be selected separately to match the installation. - Q: What does less accessory mean on this model?
A: It means the reel includes the hose and cord but does not include the final cord-end accessory. This allows the buyer to choose a compatible accessory or connection style for the application. - Q: Do the hose reel and cord reel operate together?
A: No. The C Series air/electric reel uses two independent self-retracting assemblies, so the hose and cord can be pulled out and retracted separately. - Q: What air hose size and pressure rating does this reel provide?
A: The C-L350-5012-4 includes 50 ft of 3/8" I.D. hose with a 300 PSI maximum pressure rating. Confirm the air system, fittings, and connected tools are compatible before use. - Q: What electrical rating does this reel have?
A: This model is listed with 50 ft of 12/4 SJO cord and a 13 amp, 115 volt, 60 Hz single phase electrical rating. The connected equipment and selected accessory must stay within the reel rating. - Q: Can this dual purpose reel be used outdoors?
A: No. Coxreels lists C Series air/electric reels for indoor use only. - Q: When should I choose a dual air/electric reel instead of two separate reels?
A: Choose a dual purpose reel when the workstation needs both compressed air and electrical access from one location and a single mounting base is preferred to save space and simplify installation.
| HOSE & CORD | SIZE INDEX |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SKU | ACCESSORY | INLET OUTLET |
AWG / NO COND. |
CORD FT. |
TYPE | AMPS. | I.D. | O.D. | FT. | PSI | APRX. LBS. |
|
|
FOR INDOOR USE ONLY!Coxreels electric and pneumatic hose reels operate as two independent, self-retracting 50 foot trouble-free assemblies. All Models rated: 115 volts, 3*conductors, 60hz single phase.
|
||||||||||||
| C-L350-5016-A | Single Industrial Receptacle† |
16 / 3 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 | |
| C-L350-5012-A | Single Industrial Receptacle† |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 84 | 1 | |
| C-L350-5012-B | Quad “4 Plug” Industrial Receptacle† |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 85 | 1 | |
| C-L350-5016-F | Duplex G.F.C.I. Metal Industrial Receptacle† |
16 / 3 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 | |
| C-L350-5012-F | Duplex G.F.C.I. Metal Industrial Receptacle† |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 84 | 1 | |
| C-L350-5016-E | Caged Drop Light with Tool Tap Plug† |
16 / 3 | 50 | SJTO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 | |
| C-L350-5016-H | Industrial Duty LED Light† |
16 / 3 | 50 | SJTO | .17 | 3/8" | 5/8" | 50 | 300 | 79 | 1 | |
| C-L350-5016-K | Super-Bright LED Light with Tool Tap on Handle |
16 / 3 | 50 | SJTO | 13 | 3/8" | 5/8" | 50 | 300 | 79 | 1 | |
| C-L350-5016-M | Compact Super-Bright LED Light |
16 / 3 | 50 | SJTO | .17 | 3/8" | 5/8" | 50 | 300 | 79 | 1 | |
| C-L350-5016-X | With Hose, With Cord, Less Accessory |
16 / 3 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 78 | 1 | |
| C-L350-5012-X | With Hose, With Cord, Less Accessory |
12 / 3 | 50 | SJO | 20 | 3/8" | 5/8" | 50 | 300 | 83 | 1 | |
| C-L350-5012-4 | With Hose, With Cord, Less Accessory |
12 / 4 | 50 | SJO | 13 | 3/8" | 5/8" | 50 | 300 | 86 | ||
| C-L350L-5016L-X | Less Hose, Less Cord, Less Accessory |
16 / 3 | 50 | N/A | 25 | 3/8" | 5/8" | 50 | 300 | 71 | 1 | |
| C-L350L-5012L-X | Less Hose, Less Cord, Less Accessory |
12 / 3 | 50 | N/A | 25 | 3/8" | 5/8" | 50 | 300 | 71 | 1 | |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
