When a fully loaded reel needs more retrieval leverage than a direct hand crank provides, the Coxreels 1175-6-200-C uses a front-mounted bevel geared crank to make winding long, large-diameter hose more manageable. This 1175 Series reel stores up to 200 ft of 1" I.D. hose, providing extended reach for water trucks, construction sites, fire-suppression equipment, agricultural systems, lubricant dispensing, and compatible chemical-fluid transfer.
The reel's fluid path is rated for a 3,000 PSI maximum working pressure and includes a 1" female NPT inlet swivel and outlet riser. Its larger welded steel chassis accommodates the specified hose volume, while the low-profile outlet riser and open drum slot promote flat, even wraps. Permanently lubricated self-aligning pillow block bearings support smooth drum rotation, and an adjustable tension brake helps control free-wheeling as hose is pulled from the reel.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
Type: Bevel Geared Crank Rewind Hose Reel | Series: 1175 Series | Model: 1175-6-200-C | Configuration: Less Hose | Rewind: Front-Mounted Bevel Geared Crank | Hose I.D.: 1" | Hose O.D.: 1-7/16" | Hose Capacity: 200 ft | Optional Hose Capacity: 300 ft of 3/4" I.D. hose with reducer | Inlet Swivel Assembly: 1" Female NPT, 90° | Outlet Riser: 1" Female NPT | Maximum Pressure: 3,000 PSI
Features:
- Front-mounted bevel geared crank provides mechanical advantage when retrieving long lengths of large-diameter hose.
- Larger 1175 Series chassis accommodates greater hose capacities and larger hose diameters.
- One-piece, all-welded steel 'A' frame construction provides a stable reel structure for stationary or mobile mounting.
- External fluid path incorporates a nickel-plated steel 90-degree full-flow NPT swivel inlet.
- AFLAS swivel seals support the reel's specified fluid-path configuration.
- Low-profile outlet riser and open drum slot promote flat, smooth hose wrapping around the drum.
- Permanently lubricated self-aligning pillow block bearings support smooth reel rotation.
- Adjustable tension brake helps prevent uncontrolled free-wheeling during hose payout.
- Long-handled locking pin secures the reel against rotation during transportation or storage.
- Professional-grade steel construction supports demanding stationary and mobile hose-storage applications.
- Rolled edges and ribbed discs add structural strength while reducing exposed sharp-edge contact points.
- Durable proprietary CPC powder-coat finish helps protect the steel reel structure.
Made in USA:
Applications:
- Water trucks and utility vehicles requiring organized storage for long, large-diameter hose runs.
- Construction sites where geared manual rewind is preferred over an electrical, pneumatic, or hydraulic drive.
- Fire-suppression and high-flow watering systems operating within the reel, hose, and fitting pressure limits.
- Farming and agricultural operations involving water delivery, spraying, or compatible fluid transfer.
- Lubricant dispensing systems requiring up to 200 ft of 1" hose capacity.
- Chemical-fluid transfer installations using hose, seals, fittings, and other wetted components verified for the conveyed material.
FAQs:
- Q: Does the Coxreels 1175-6-200-C include hose?
A: No. This model is supplied as a reel only. Hose must be purchased separately and selected according to the required diameter, working pressure, temperature range, bend radius, and fluid compatibility. - Q: What does the 'C' suffix mean?
A: The 'C' suffix identifies the front-mounted bevel geared crank option. This geared mechanism provides greater mechanical advantage than the standard direct hand crank when retrieving a long or fully loaded hose. - Q: How much hose can this reel hold?
A: The standard capacity is 200 ft of 1" I.D. hose with a 1-7/16" outside diameter. The reel can also accommodate up to 300 ft of 3/4" I.D. hose with a 1-1/4" outside diameter when the appropriate reducer is used. - Q: Does this reel require electricity or compressed air?
A: No. The reel is rewound manually through the bevel geared crank, so no electrical connection, compressed-air supply, or hydraulic circuit is required. - Q: What should be checked before mounting the reel?
A: Confirm that the mounting surface can support the reel, installed hose, fittings, and operating loads. Allow space for the 36-5/8" overall width and use the 23.31" × 13.75" mounting pattern when planning the installation.
| LESS HOSE | SIZE INDEX |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required |
INLET SWIVEL ASSEMBLY |
OUTLET RISER |
PSI | APRX. LBS. |
|||||
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | ||||||
| 1175-6-200 | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-A | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-AB | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-C | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-E | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-EA | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-EB | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-ED | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-EF | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-EJ | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
| 1175-6-200-H | 1" | 1 7/16" | 200 | 3/4" | 1 1/4" | 300 | 1" F NPT 90° | 1" F NPT | 3,000 | 83 | 5 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
