Coxreels P-LPL-325-AL Spring Rewind Hose Reel | Alumi-Pro Series | 3/8" Hose Diameter | 25' Hose Length | 300 Max PSI | Less Hose

When a steel reel is more weight than the job calls for and a plastic reel is not preferred, the Coxreels P-LPL-325-AL Alumi-Pro Series spring rewind hose reel provides a compact, corrosion-resistant aluminum option for low-pressure air and water hose management. This reel is supplied less hose, giving maintenance shops, service trucks, and mobile equipment installers the flexibility to add a compatible 3/8" I.D. hose up to 25 ft long for systems rated up to 300 PSI.

The Alumi-Pro Series is modeled after Coxreels' P Series platform and built with aluminum construction for applications that need professional-grade strength without unnecessary reel weight. Its spring rewind mechanism retracts the hose after use, while the adjustable guide arm supports wall, floor, vehicle, and overhead mounting layouts where installation space and hose pull direction vary by work area.

*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.

Type: Spring Rewind Hose Reel | Series: Alumi-Pro Series | Configuration: Less Hose | Hose I.D.: 3/8" | Hose O.D.: 5/8" | Hose Capacity: 25 ft | Max Pressure: 300 PSI | Hose Included: No | Approx. Weight: 16 lbs | Overall Dimensions: 6-1/2" W x 14-7/8" H x 13-1/2" L | Base: 5" x 6" | Mounting Pattern: 3" x 5" | Swivel Seals: Nitrile

Features:

• Alumi-Pro aluminum construction provides a lighter reel body for service trucks, mounted workstations, and applications where reel weight matters.
• Spring rewind operation helps keep hose stored off the floor after use, reducing clutter around benches, bays, and mobile work areas.
• Machined solid brass 90° full-flow NPT swivel inlet supports smooth fluid path routing and simplifies seal access during service.
• Nitrile swivel seals are used for the reel's low-pressure air and water service configuration.
• Adjustable guide arm supports wall, floor, vehicle, and overhead mounting positions to match the hose pull direction at the installation point.
• Single pedestal reel layout is suited for applications that need professional-grade strength without the added weight of comparable steel reel construction.
• CPC powder coated aluminum construction helps resist corrosion and supports use in shop, fleet, and mobile service environments.
• 1" solid steel axle with lubricated precision bearings supports smooth reel rotation during hose payout and rewind.

Made in USA:

2 Year Warranty

Applications:

• Automotive and fleet service bays managing low-pressure air or water hose in tire service, detailing, and general shop maintenance areas.
• Service and mechanic trucks where a lighter aluminum reel helps reduce mounted equipment weight without switching to a plastic reel.
• Industrial MRO workstations that need organized hose storage near benches, assembly points, and maintenance cells.
• Washdown and water service areas where the reel's 300 PSI rating and corrosion-resistant aluminum construction suit low-pressure hose handling.
• Garage and workshop installations where a compact spring rewind reel keeps compatible hose stored and accessible between tasks.

FAQs:

• Q: What does less hose mean on the P-LPL-325-AL?
  A: It means the reel is supplied without hose installed. The buyer must provide a compatible 3/8" I.D. hose separately, up to the reel's 25 ft capacity and within the 300 PSI pressure rating.
• Q: What is the difference between the P-LP-325-AL and P-LPL-325-AL?
  A: The P-LP-325-AL includes hose, while the P-LPL-325-AL is the less-hose version. Choose the P-LPL model when you already have a preferred hose type or need to match a specific shop standard.
• Q: Can this reel be mounted on a service truck?
  A: Yes, the adjustable guide arm supports vehicle mounting along with wall, floor, and overhead positions. Always verify the mounting surface, bolt pattern, and hose routing before installation.
• Q: Is this reel for high-pressure hydraulic service?
  A: No. This is a low-pressure reel rated to 300 PSI. For hydraulic applications, choose a reel specifically rated for the hydraulic system pressure and fluid requirements.
• Q: Why choose the Alumi-Pro Series instead of a standard steel reel?
  A: The Alumi-Pro Series is built for applications where aluminum construction, reduced reel weight, and corrosion resistance are preferred while still maintaining a professional spring rewind reel format.
