For high-pressure hose stations that need powered rewind from a 24V DC electrical system, the Coxreels HP1125-5-50-EF provides a compact motorized reel platform with the capacity and pressure rating needed for controlled hose handling. This HP1125 Series reel is configured for 3/4" hose I.D., 50 ft hose capacity, and 4500 PSI maximum pressure, making it suitable for hydraulic, grease, pressure washing, washdown, and other high-pressure fluid service applications where hose storage and retrieval need to be consistent and organized.
The 24V DC 1/3 HP reversible electric motor rewind helps retrieve hose without manual cranking, while the direct gear drive design provides smooth rotation without a chain drive. Coxreels' all-welded steel "A" frame, electroless nickel-plated steel 90° full-flow NPT swivel inlet, AFLAS swivel seals, low-profile outlet riser, and open drum slot help support high-pressure service while promoting a flatter, smoother hose wrap on the reel.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
Type: Electric Motor Rewind Hose Reel | Series: HP1125 Series | Model: HP1125-5-50-EF | Configuration: Less Hose | Motor: 24V DC 1/3 HP Reversible Electric | Hose I.D.: 3/4" | Hose O.D.: 1-1/4" | Hose Capacity: 50 ft | Max Pressure: 4500 PSI | Ship Weight: 51 lb | Overall Dimensions: 20" W x 19.25" H x 17.63" L | Mounting Pattern: 9.44" M x 10" N | Base: 11.38" X x 16" Y
Features:
- 24V DC 1/3 HP reversible electric motor rewind supports powered hose retrieval from compatible DC electrical systems.
- Reliable direct gear drive provides smooth, quiet rotation with no chain drive to adjust or maintain.
- All-welded steel "A" frame construction provides a rigid reel base for repeated high-pressure hose handling.
- Electroless nickel-plated steel 90° full-flow NPT swivel inlet supports the external fluid path through the reel.
- AFLAS swivel seals are supplied for the high-pressure HP Series configuration.
- Exclusive low-profile outlet riser and open drum slot design help create a non-crimping, flat, smooth hose wrap.
- Permanently lubricated, self-aligning pillow block bearings support smooth drum rotation.
- Adjustable tension brake helps control reel movement and reduce free-wheeling during payout or rewind.
Made in USA:
Applications:
- Mobile service trucks and utility equipment using 24V DC power for motorized hose rewind.
- Hydraulic and grease service stations where high-pressure hose must be stored neatly between use cycles.
- Pressure washing and washdown areas that need controlled hose payout with powered retrieval.
- Industrial MRO bays where hose organization helps reduce clutter and protect hose assemblies.
- Shop-mounted fluid handling systems where a compact 3/4" hose reel footprint is preferred.
FAQs:
- Q: What does "less hose" mean on the HP1125-5-50-EF?
A: It means the reel is supplied without hose installed. The buyer must provide compatible 3/4" I.D. hose separately and confirm the hose pressure rating, outside diameter, fittings, and media compatibility before installation. - Q: What does the "EF" suffix identify?
A: The EF motor option identifies a 24V DC, 1/3 HP, reversible electric motor rewind configuration. It is used when the reel needs powered hose retrieval from a compatible 24V DC electrical source. - Q: Can this reel be used for hydraulic service?
A: Yes, when the selected hose, fittings, fluid, and system pressure match the reel's 5000 PSI maximum pressure rating. Always verify compatibility between the media, hose assembly, fittings, and swivel seals before use. - Q: Does this model include hose stops, roller guides, or mounting hardware?
A: The supplied source data confirms the reel configuration but does not confirm included accessories. Hose stops, roller brackets, pivoting guides, and mounting hardware should be verified separately based on the installation layout. - Q: Why does hose O.D. matter for this reel?
A: Hose outside diameter determines how much hose will fit on the drum and how well it wraps. This model is listed for 50 ft of 3/4" I.D. hose with a 1-1/4" hose O.D.; larger hose may reduce usable capacity.
| LESS HOSE | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required |
INLET SWIVEL & OUTLET RISER |
PSI | SKU | HP PSI | APRX. LBS. |
SIZE INDEX |
||||
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | |||||||
| 1125-5-50 | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50 | 4,500 | 38 | 6 |
| 1125-5-50-A | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-A | 4,500 | 38 | 6 |
| 1125-5-50-AB | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-AB | 4,500 | 38 | 6 |
| 1125-5-50-C | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-C | 4,500 | 38 | 6 |
| 1125-5-50-E | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-E | 4,500 | 38 | 6 |
| 1125-5-50-EA | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-EA | 4,500 | 38 | 6 |
| 1125-5-50-EB | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-EB | 4,500 | 38 | 6 |
| 1125-5-50-ED | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-ED | 4,500 | 38 | 6 |
| 1125-5-50-EF | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-EF | 4,500 | 38 | 6 |
| 1125-5-50-H | 3/4" | 1 1/4" | 50 | 1/2" | 7/8" | 100 | 3/4" F NPT | 3,000 | HP1125-5-50-H | 4,500 | 38 | 6 |
