Cleco 19TTA06Q T-Handle Pneumatic Screwdriver | 19 Series | Trigger Start | 260 RPM | 0.8 - 3.7 (ft-lbs) Torque Range

When a lower rundown speed is preferred for controlled screw installation, the Cleco 19TTA06Q T-handle pneumatic screwdriver provides a 260 RPM free speed with a 10–45 in-lb torque range for light assembly fastening. The slower speed gives operators more control as screws seat into plastic housings, sheet metal clips, electronics panels, appliance parts, and other assemblies where over-driving a fastener can damage the component. Its CLECOmatic clutch (an automatic shut-off clutch that stops the tool when the preset torque is reached) helps maintain repeatable torque from fastener to fastener.

Part of the Cleco 19 Series, this trigger-start model uses a 1/4" quick-change drive for common hex screwdriver bits and a T-handle pistol configuration that works well when the operator primarily guides the tool on pre-threaded fasteners. The 1.54 lb body supports repetitive bench and line-station use, while the top air inlet helps keep the hose routed away from the operator’s hand and work area. Use the 19TTA06Q where repeatable torque control, deliberate rundown speed, and pneumatic simplicity are more important than maximum fastening speed.

Type: Pneumatic Screwdriver | Series: Cleco 19 Series | Model: 19TTA06Q | Handle Style: T-Handle Pistol | Start Type: Trigger Start | Clutch Type: CLECOmatic Shut-Off Clutch | Drive: 1/4" Quick Change | Torque Range: 10–45 in-lb / 1.1–5.1 Nm / 0.8–3.7 ft-lbs | Torque Range with Standard Spring: 10–38 in-lb / 1.1–4.3 Nm | Free Speed: 260 RPM | Overall Length: 8.3" / 210 mm | Weight: 1.54 lbs / 0.7 kg | Air Inlet: 1/4" NPT | Minimum Hose I.D.: 3/8" | Air Consumption: 11 SCFM | Recommended Air Pressure: 90 PSI

Features:

• CLECOmatic shut-off clutch provides repeatable torque control for production screwdriving and light assembly fastening.
• 260 RPM free speed supports more deliberate fastener rundown where control is more important than high-speed cycling.
• Trigger-start throttle lets the operator decide exactly when the tool runs, which is useful for positioning bits on small screws.
• T-handle pistol layout is suited to pre-threaded applications where the grip is used to guide the tool during final tightening.
• 1/4" quick-change drive allows fast bit changes when switching between screw styles or assembly stations.
• Thumb-operated reverse lever supports one-hand forward/reverse changes and can be configured for left- or right-handed users.
• Top air inlet helps manage hose routing on benches, fixtures, and assembly lines.
• Includes the springs needed to cover the published torque range, plus a suspension bail for hanging the tool at a workstation.

Applications:

• Electronics assembly: Installing small screws into housings, brackets, covers, and component assemblies where controlled torque helps prevent thread damage.
• Appliance manufacturing: Fastening panels, clips, guards, and light hardware at bench or conveyor workstations.
• Automotive interior assembly: Running screws into trim components, light brackets, dashboards, and plastic or sheet metal subassemblies.
• Aerospace and precision production: Supporting low-torque fastening tasks where a slower tool speed can help operators maintain control.
• Maintenance benches and repair cells: Repetitive screw installation on small equipment, instruments, enclosures, and serviceable assemblies.

FAQs:

• Q: Why choose the 260 RPM 19TTA06Q instead of a faster 19 Series model?
  A: The 260 RPM speed is useful when operators need a slower, more controlled rundown. It can be a better fit for delicate assemblies, short fasteners, plastic components, or applications where the fastener needs to seat carefully.
• Q: What does the CLECOmatic clutch do?
  A: The CLECOmatic clutch automatically shuts the tool off when the preset torque is reached. This helps improve repeatability compared with manual feathering and helps reduce the risk of over-tightening small screws.
• Q: Is this screwdriver for threaded fasteners or self-drilling screws?
  A: This T-handle model is best matched to pre-threaded or controlled assembly fastening within the published torque range. For drilling or self-drilling applications, verify the fastener type, material, and required torque before selecting the tool.
• Q: What bits fit the Cleco 19TTA06Q?
  A: The tool uses a 1/4" quick-change drive for compatible hex screwdriver bits. Match the bit tip style, length, and quality to the fastener to prevent cam-out and premature bit wear.
• Q: What air setup should be used with this screwdriver?
  A: Use clean, regulated air at 90 PSI with a 1/4" NPT connection and a 3/8" minimum hose I.D. A properly sized FRL helps maintain consistent torque output and protects the pneumatic motor.

Looking for more information about Cleco Screwdriver? Click here to view the Catalog.

Need help selecting the correct Cleco Screwdrivers for your application? Please call (800) 608-5210 or email info@intlairtool.com
