Cleco 19TTA02Q T-Handle Pneumatic Screwdriver | 19 Series | Trigger Start | 2,800 RPM | 0.4 - 1.5 (ft-lbs) Torque Range

Built for controlled fastening in light-to-medium assembly work, the Cleco 19TTA02Q T-Handle Pneumatic Screwdriver combines a compact trigger-start layout with a 2,800 RPM free speed for fast rundown on small screws before final torque is reached. Its 0.4 - 1.5 ft-lbs torque range supports repeatable fastening on electronics, appliances, automotive interior, aerospace subassembly, and general production jobs where over-torque can damage parts or threads. The 1/4" quick-change output allows fast bit changes without a separate chuck key, helping operators move between common fastening tasks with less downtime.

The 19 Series uses Cleco’s CLECOMATIC clutch, a precision shut-off clutch system that stops air power when the preset torque is reached to improve repeatability on production joints. The T-handle configuration gives the operator a balanced grip for vertical and bench assembly work, while the trigger start provides familiar throttle control for users moving from general pneumatic screwdrivers into more controlled assembly tools.

Type: Pneumatic Screwdriver | Brand: Cleco | Model: 19TTA02Q | Series: 19 Series | Handle Style: T-Handle | Start Type: Trigger Start | Output: 1/4" Quick Change | Torque Range: 0.4 - 1.5 ft-lbs / 5 - 19 in-lbs / 0.6 - 2.1 Nm | Free Speed: 2,800 RPM | Overall Length: 7.9" / 199 mm | Weight: 1.44 lbs / 0.7 kg | Air Inlet: 1/4" NPT | Minimum Hose I.D.: 3/8" | Air Consumption: 11 SCFM

Features:

• CLECOMATIC clutch provides controlled torque shut-off for repeatable fastening in assembly environments.
• 2,800 RPM free speed supports quick screw rundown on small fasteners before final torque is applied.
• Trigger start throttle gives operators familiar control for bench, fixture, and station-based fastening tasks.
• T-handle body helps balance the tool during vertical fastening and repetitive production work.
• 1/4" quick change output accepts compatible hex screwdriver bits for fast bit swaps between jobs.
• External torque adjustment helps production teams set the tool for the required fastening range.
• Includes the springs needed to cover the advertised torque range and a suspension bail for supported workstations.

Made in USA:

Applications:

• Electronics assembly — installing small machine screws, covers, brackets, and low-torque fasteners where repeatability matters.
• Appliance manufacturing — fastening panels, housings, and internal components on bench or line assembly stations.
• Automotive interior and trim assembly — running screws into light brackets, plastic components, and subassemblies.
• Aerospace subassembly — controlled fastening on small components where torque consistency helps protect parts and threads.
• General light manufacturing — repetitive screwdriving in production cells, repair benches, and fixture-based assembly work.

FAQs:

• Q: What torque range does the Cleco 19TTA02Q cover?
  A: The 19TTA02Q covers 0.4 - 1.5 ft-lbs, which is the same as 5 - 19 in-lbs or 0.6 - 2.1 Nm. This places it in the light assembly range for small screws and lower-torque production fastening.
• Q: What does a CLECOMATIC clutch do?
  A: The CLECOMATIC clutch is a torque-control clutch that shuts off when the preset torque is reached. That helps reduce over-tightening and improves repeatability compared with a basic stall-style screwdriver.
• Q: What bits fit the 19TTA02Q?
  A: This model uses a 1/4" quick change output for compatible 1/4" hex screwdriver bits. Always match the bit style and size to the fastener being driven.
• Q: Is this screwdriver used for wood screws or general construction fastening?
  A: No. This is a precision pneumatic assembly screwdriver for controlled fastening on production parts. For construction screws, wood screws, or high-torque fastening, a different screwdriver or impact driver is typically more appropriate.
• Q: What air supply does this tool require?
  A: The listed air consumption is 11 SCFM, with a 1/4" NPT air inlet and 3/8" minimum hose I.D. Use a properly sized air line and regulated supply to maintain consistent tool performance.

Looking for more information about Cleco Screwdriver? Click here to view the Catalog.

Need help selecting the correct Cleco Screwdrivers for your application? Please call (800) 608-5210 or email info@intlairtool.com
