Cleco 19TTA03Q T-Handle Pneumatic Screwdriver | 19 Series | Trigger Start | 1,900 RPM | 0.4 - 2.1 (ft-lbs) Torque Range

When a fastening station needs more torque capacity than the fastest 19 Series models but still needs quick screw rundown, the Cleco 19TTA03Q T-Handle Pneumatic Screwdriver delivers a balanced combination of 1,900 RPM speed and a 0.4 - 2.1 ft-lbs torque range. This trigger-start screwdriver is suited for controlled assembly of machine screws, brackets, housings, panels, and light production fasteners where repeatability matters more than raw driving force. The 1/4" quick change output supports fast bit changes, helping operators move between compatible hex bits without slowing the work cell.

The 19TTA03Q uses Cleco’s CLECOMATIC clutch, a torque shut-off clutch that stops the tool when the preset torque is reached, helping reduce over-tightening and improve fastening consistency. Its T-handle layout provides operators with a secure grip in bench, fixture, and vertical fastening positions. At the same time, the trigger start provides familiar throttle control for assembly teams working in high-volume production, repair, and subassembly environments.

Type: Pneumatic Screwdriver | Brand: Cleco | Model: 19TTA03Q | Series: 19 Series | Handle Style: T-Handle | Start Type: Trigger Start | Clutch Type: CLECOMATIC Clutch | Output: 1/4" Quick Change | Torque Range: 0.4 - 2.1 ft-lbs / 5 - 26 in-lbs / 0.6 - 2.9 Nm | Torque Range with Standard Spring: 5 - 19 in-lbs / 0.6 - 2.1 Nm | Free Speed: 1,900 RPM | Overall Length: 8.1" / 204 mm | Weight: 1.54 lbs / 0.7 kg | Air Inlet: 1/4" NPT | Minimum Hose I.D.: 3/8" | Air Consumption: 11 SCFM

Features:

• Durable CLECOMATIC clutch supports torque repeatability and controlled shut-off during production fastening.
• 1,900 RPM free speed balances fast rundown with added torque capacity compared with higher-speed, lower-torque models.
• Trigger start operation gives operators direct throttle control for bench assembly and station-based fastening.
• T-handle configuration is balanced for machine screw assembly in production cells and line work.
• The reverse lever can be rotated to accommodate left- or right-handed operators.
• 1/4" quick change output accepts compatible hex bits for fast bit changes between assembly tasks.
• Two grip sizes available within the 19 Series for matching the tool configuration to operator preference and application needs.

Made in USA:

Applications:

• High-volume assembly cells — controlled installation of machine screws, covers, light brackets, and production hardware.
• Aerospace subassembly — fastening smaller components where controlled torque helps protect parts and threaded inserts.
• Electronics and enclosure assembly — installing panels, housings, terminal covers, and low-torque fasteners.
• Appliance and equipment manufacturing — repetitive fastening on cabinets, frames, panels, and internal assemblies.
• Automotive interior and light component work — running screws into trim pieces, brackets, plastic components, and subassemblies.

FAQs:

• Q: What is the torque range of the Cleco 19TTA03Q?
  A: The full tool torque range is 5 - 26 in-lbs, equal to 0.4 - 2.1 ft-lbs or 0.6 - 2.9 Nm. With the standard spring, the listed torque range is 5 - 19 in-lbs or 0.6 - 2.1 Nm.
• Q: What does the CLECOMATIC clutch do?
  A: The CLECOMATIC clutch shuts the tool off when the preset torque is reached. This helps improve consistency on repetitive fastening jobs and reduces the chance of over-tightening small screws.
• Q: What type of bits does this screwdriver use?
  A: The 19TTA03Q uses a 1/4" quick change output for compatible 1/4" hex screwdriver bits. Select the correct bit profile and size for the fastener to avoid cam-out or fastener damage.
• Q: How is the 19TTA03Q different from the 19TTA02Q?
  A: The 19TTA03Q runs at 1,900 RPM and has a higher maximum tool torque range of 5 - 26 in-lbs. The 19TTA02Q runs faster at 2,800 RPM but is listed with a lower 5 - 19 in-lbs torque range.
• Q: Is this the right tool for construction screws or wood screws?
  A: No. This is a controlled pneumatic assembly screwdriver for machine screws and production fastening. For wood screws, deck screws, or construction fastening, use a tool built for those higher-load driving conditions.

Looking for more information about Cleco Screwdriver? Click here to view the Catalog.

Need help selecting the correct Cleco Screwdrivers for your application? Please call (800) 608-5210 or email info@intlairtool.com
