Chicago Pneumatic Electronic Torque Wrench | CP8911TC | 5-99 (ft-lbs) Torque Range | 3/8" Square Drive

Built for mid-range torque-and-angle verification with connected reporting, the Chicago Pneumatic CP8911TC Electronic Torque & Angle Wrench gives technicians a digital 5-99 ft-lbs / 7-135 Nm torque range in a 3/8" square drive format. The TC, or Torque Check, version adds angle measurement, Bluetooth communication, P-Sets, sequencing, torque check, re-hit detection, and reporting through the CPLinQ application, helping service and quality teams document fastening results on smaller-to-medium fasteners.

The CP8911TC fits between the compact 1/4" drive CP8906TC and the higher-capacity 1/2" drive CP8916TC, making it useful for applications that need more range than a low-torque assembly wrench but do not require a larger 1/2" drive tool. Its acoustic buzzer, strong vibration motor, and 12 LED progressive light display help guide the operator as the target torque or angle value is approached. With ±3% torque accuracy, ±2° angle accuracy, and onboard memory for up to 2,000 results, this 3/8" drive Torque Check wrench supports controlled tightening and traceability in service, maintenance, and inspection workflows.

Type: Electronic Torque & Angle Wrench | Model: CP8911TC | SKU: 8941189111 | Series: CP89 eTorque | Version: Torque Check | Drive Size: 3/8" | Drive Type: Square | Torque Range: 5-99 ft-lbs / 7-135 Nm | Max Torque: 135 Nm | Min Torque: 7 Nm | Torque Accuracy: ±3% | Angle Measurement: Yes | Angle Accuracy: ±2° | Tightening Direction: CW Only | Overload Torque: 10% / 148 Nm | Feedback Type: Acoustic Buzzer and 2x6 LEDs | Communication Type: Bluetooth | Wireless Communication: Yes | Results Memory Capacity: 2000 | Unit Measurement Supported: Nm, ft/lb | Quality Strategies: Yes | Compliance: ISO 6789:2017 | Type Class: Type I, Class 3 | Battery Type: AA Batteries | Autonomy: 8 hr | Lever Arm Length: 16.26" / 413 mm | Overall Length: 16.26" / 413 mm | Width: 1.73" / 44 mm | Height: 1.77" / 45 mm | Weight: 1.83 lb / 0.83 kg | Operating Temperature: -10°C to 40°C / 14°F to 104°F

Features:

• Torque Check configuration adds torque and angle measurement, P-Sets, sequencing, torque check, re-hit detection, and reporting through the CPLinQ application.
• 5-99 ft-lbs / 7-135 Nm torque range covers smaller-to-medium fastening tasks where a 3/8" drive wrench is preferred.
• 3/8" square drive accepts compatible 3/8" drive sockets commonly used in automotive, MRO, powersports, and mechanical service work.
• Bluetooth communication and wireless capability support connected result management and reporting workflows.
• 12 LED progressive light display gives visual feedback as the target torque or angle value is approached.
• Acoustic buzzer and strong vibration motor provide audible and tactile alerts during torque application.
• Robust gear system is rated by Chicago Pneumatic for accuracy up to 25,000 cycles.
• Soft grip, non-slip handle helps maintain control during repeated torque checks and final tightening tasks.

Included Items:

• CP89 eTorque electronic torque wrench.
• USB connection cable.
• Calibration certificate.
• Molded plastic case.
• Removable foam insert.

Applications:

• Automotive service - torque-and-angle checks on brake components, engine covers, chassis hardware, brackets, and accessory fasteners within the tool's rated range.
• Fleet and equipment maintenance - controlled tightening on smaller mechanical assemblies, service covers, guards, brackets, and shop-repair components.
• Industrial MRO - documented torque verification on pumps, panels, fixtures, light machinery, and maintenance hardware.
• Powersports and small vehicle repair - fastening work on motorcycles, ATVs, utility vehicles, and compact mechanical assemblies.
• Inspection and quality checks - recording 3/8" drive torque-and-angle results where traceability is useful for service or process documentation.

FAQs:

• Q: What makes the CP8911TC different from the CP8911?
  A: The CP8911TC is the Torque Check version. Compared with the standalone CP8911, it adds torque and angle measurement, Bluetooth communication, P-Sets, sequencing, torque check, re-hit detection, and reporting through the CPLinQ application.
• Q: What torque range does the CP8911TC cover?
  A: The CP8911TC covers 5-99 ft-lbs / 7-135 Nm. This makes it a mid-range 3/8" drive option in the CP89 eTorque family.
• Q: Does the CP8911TC measure angle?
  A: Yes. The CP8911TC includes angle measurement with ±2° angle accuracy, making it useful for procedures that require both torque and angle confirmation.
• Q: Does this wrench store tightening results?
  A: Yes. Manufacturer data lists a results memory capacity of 2,000 results. Bluetooth communication and CPLinQ compatibility support connected reporting and result management workflows.
• Q: Is the CP8911TC an air tool?
  A: No. The CP8911TC is an electronic manual torque-and-angle wrench. AA batteries power the display, measurement, alert, memory, and communication functions, while torque is applied manually by the operator.

Looking for more information about Chicago Pneumatic Electronic Torque Wrench? Click here to view the Catalog.

For help selecting the correct Chicago Pneumatic Electronic Torque Wrenches for your assembly application, call (800) 608-5210 or email info@intlairtool.com
