Ingersoll Rand QA6AALD090NP43S08 Angle Air Nutrunner | 1/2" Drive Size | 66 (ft-lbs) Torque | 185 RPM | Lever Start

Ingersoll Rand QA6AALD090NP43S08 Angle Air Nutrunner is configured for production fastening applications that require higher torque output along with angled access to the fastener. Featuring a 1/2" drive size, 66 ft-lbs torque, 185 RPM operating speed, and lever start, this pneumatic nutrunner provides a controlled fastening solution for repetitive assembly processes.

Ingersoll Rand QA6AALD090NP43S08 uses an angle-head configuration to help operators position compatible sockets where frames, housings, fixtures, or neighboring components restrict straight-line tool access. Its 1/2" square drive supports compatible sockets, while the 185 RPM speed provides a measured rundown rate suited to the model's 66 ft-lbs torque specification.

Type: Angle Air Nutrunner | Drive Size: 1/2" | Torque: 66 ft-lbs | Speed: 185 RPM | Start Type: Lever Start | Series: QA6A Series

Features: 66 ft-lbs torque specification supports fastening operations requiring this level of output. 1/2" square drive accepts compatible sockets for production assembly tasks. 185 RPM operating speed provides controlled fastener rundown for repetitive fastening cycles. Lever-start configuration gives the operator direct control over tool activation during use. Angle-head design helps position the socket on fasteners where surrounding components limit straight-line access. Pneumatic operation supports use in compressed-air-powered assembly environments. Made in USA:

Applications:

• Production fastening operations requiring a 66 ft-lbs torque specification.
• Assembly work involving fasteners positioned near equipment frames, housings, or adjacent components.
• Repetitive fastening processes using compatible 1/2" drive sockets and operator-controlled lever activation.
• Machinery and fabricated-component assembly where an angle-head tool provides practical access to the fastening point.
• Compressed-air-powered workstations where a 185 RPM operating speed matches the required fastening process.

FAQs:

• Q: What torque specification does the QA6AALD090NP43S08 provide?
  A: This model is specified at 66 ft-lbs of torque. The required fastening specification should be confirmed before selecting the tool.
• Q: Which socket drive size is required for this nutrunner?
  A: The tool uses a 1/2" square drive and should be paired with compatible 1/2" drive sockets.
• Q: How is the QA6AALD090NP43S08 started?
  A: It uses a lever-start configuration, allowing the operator to activate the tool directly during the fastening cycle.
• Q: What is the rated operating speed?
  A: The QA6AALD090NP43S08 is rated at 185 RPM.
• Q: When is an angle air nutrunner useful?
  A: An angle configuration is useful when the fastener location or nearby components make straight-line positioning of an inline tool difficult.

Looking for more information about the Ingersoll Rand Nutrunner? Click here to view the Catalog

For help choosing the correct Ingersoll Rand Nutrunners for your application, please call (800) 608-5210 or email info@intlairtool.com
