Ingersoll Rand Q70PQ1 Pistol Grip Air Pulse Tool is designed for repetitive production fastening where operator comfort, rapid bit changes, and smooth power delivery are essential. Featuring a pistol grip configuration, a non-shut-off clutch, 7,000 RPM free speed, and a 1/4" quick change drive, this pneumatic pulse tool utilizes an oil pulse mechanism to help reduce torque reaction while providing controlled fastening performance. The pistol grip design offers a familiar, ergonomic handling position for a wide range of industrial assembly tasks.
The Q70PQ1 is well suited for production environments where operators control the fastening cycle and require the flexibility to change bits quickly between applications. Its high operating speed and quick change drive make it an excellent choice for assembly lines that demand efficient workflow and dependable fastening performance.
Type: Pistol Grip Pneumatic Pulse Tool | Model: Q70PQ1 | Clutch Type: Non-Shut-Off | Configuration: Pistol Grip | Free Speed: 7,000 RPM | Drive Type: 1/4" Quick Change
Features:
- Pistol grip configuration provides comfortable handling during repetitive fastening operations.
- Oil pulse mechanism helps reduce torque reaction, improving operator comfort compared to conventional impact tools.
- Non-shut-off operation allows the operator to control the fastening cycle according to application requirements.
- 1/4-inch quick change drive enables fast bit replacement, helping reduce downtime during production.
- 7,000 RPM free speed supports efficient fastening cycles in high-volume manufacturing environments.
- Designed for industrial assembly applications requiring smooth fastening performance and quick tooling changes.
Tech Tip: To increase tool performance, extend tool life and lessen repair costs use it with a Filter-Regulator-Lubricator (FRLs)
Made in USA:
Applications:
- Electronics and electrical equipment assembly.
- Automotive component and subassembly production.
- Appliance manufacturing and general industrial assembly.
- Production lines where frequent bit changes improve operational efficiency.
- Repetitive fastening applications where reduced torque reaction enhances operator comfort.
FAQs:
- Q: What is the advantage of the pistol grip design?
A: The pistol grip configuration provides a comfortable, familiar grip that can improve control during repetitive fastening operations. - Q: What does non-shut-off mean?
A: A non-shut-off pulse tool does not automatically stop at a preset torque. The operator controls the fastening cycle based on the application requirements. - Q: What is the benefit of the 1/4-inch quick change drive?
A: It allows compatible bits to be exchanged quickly without additional tools, helping improve productivity in assembly applications. - Q: Does this tool operate at high speed?
A: Yes. The catalog specifies a free speed of 7,000 RPM for efficient production fastening. - Q: Does the catalog specify the torque range, weight, air consumption, air inlet size, or operating pressure?
A: No. Those specifications were not confirmed in the provided source and have therefore been omitted.
| SKU | Fastener Size | Torque | Free Speed | Weight | Overall Length | Side to Center | Drive Size and Type | Air Consumption |
|---|---|---|---|---|---|---|---|---|
| ft-lbs (Nm) | rpm | lbs (kg) | in (mm) | in (mm) | in | cfm | ||
| Pistol | ||||||||
| 100PQ1 | M4 - M5 | 5.5 - 8 (7.5 - 11) | 9300 | 1.6 (0.7) | 5.6 (142) | 0.7 (18) | 1/4" Hex Quick-Change Drive | 12 |
| Q60P3 | M6 | 10 - 16 (13 - 22) | 4000 | 1.8 (0.8) | 5.1 (130) | 0.9 (22) | 3/8" Square Drive | 11 |
| Q60PQ1 | M6 | 8 - 15 (11 - 20) | 4000 | 1.8 (0.8) | 5.1 (130) | 0.9 (22) | 1/4" Hex Quick-Change Drive | 11 |
| Q70P3 | M6 - M8 | 18 - 25 (24 - 35) | 7000 | 1.8 (0.8) | 5.2 (131) | 0.9 (22) | 3/8" Square Drive | 11 |
| Q70PQ1 | M6 - M8 | 15 - 20 (20 - 28) | 7000 | 1.8 (0.8) | 5.2 (131) | 0.9 (22) | 1/4" Hex Quick-Change Drive | 12 |
| Q80PQ1 | M8 | 18 - 25 (24 - 35) | 7000 | 1.9 (0.9) | 5.4 (138) | 0.9 (22) | 1/4" Hex Quick-Change Drive | 12 |
| Q80P3 | M8 | 24 - 37 (34 - 50) | 7000 | 1.9 (0.9) | 5.4 (138) | 0.9 (22) | 3/8" Square Drive | 12 |
| Q90P3 | M8 - M10 | 35 - 48 (47 - 65) | 6500 | 2.1 (1.0) | 5.8 (148) | 0.9 (23) | 3/8" Square Drive | 14 |
| Q110P4 | M10 - M12 | 44 - 70 (60 - 95) | 5500 | 3.0 (1.4) | 6.5 (164) | 1.1 (27) | 1/2" Square Drive | 20 |
| Q120P4 | M12 | 70 - 95 (95 - 130) | 6600 | 3.7 (1.7) | 6.9 (175) | 1.3 (29) | 1/2" Square Drive | 20 |
| Q140P4 | M14 | 95 - 118 (130 - 160) | 5400 | 4.9 (2.2) | 7.5 (190) | 1.3 (33) | 1/2" Square Drive | 30 |
| 140P6 | M16 | 118 - 199 (160 - 270) | 3200 | 6.8 (3.1) | 8.9 (226) | 1.4 (36) | 3/4" Square Drive | 26 |
| 3000P | M16 - M18 | 170 - 258 (230 - 350) | 4700 | 10.1 (4.6) | 9.7 (246) | 1.6 (40) | 3/4" Square Drive | 10 |
| Inline | ||||||||
| 180SQ1 | M4 - M6 | 11 - 18 (15 - 24) | 9000 | 20 (0.9) | 8.7 (221) | 0.9 (22) | 1/4" Hex Quick-Change Drive | 9 |
| 280SQ1 | M6 - M8 | 15 - 23 (20 - 31) | 8000 | 21 (10) | 9.0 (229) | 0.9 (22) | 1/4" Hex Quick-Change Drive | 11 |
| 380SQ1 | M8 | 21 - 30 (29 - 40) | 8500 | 26 (1.2) | 9.1 (231) | 1.0 (25) | 1/4" Hex Quick-Change Drive | 11 |
| Angle | ||||||||
| 500A | M6 - M8 | 21 - 29 (29 - 39) | 7000 | 3.3 (1.5) | 10.5 (267) | 1.1 (27) | 3/8" Square Drive | 11 |
Looking for more information about Ingersoll Rand Pulse Tool? Click here to view the Catalog
For help selecting the correct Ingersoll Rand Pulse Tools for your assembly application, call (800) 608-5210 or email info@intlairtool.com
