Coxreels 1125PCL-8M Hand Crank Cord Reel | 1125PC Series | 200' (10/3) / 175' (8/3) Capacity | 30 Amps | 600 Volts | Less Cord

When shop, service vehicle, or facility layouts require long portable power runs without loose cord across the floor, the Coxreels 1125PCL-8M hand crank cord reel provides organized cord storage for 200 ft of 10/3 cord or 175 ft of 8/3 cord. Part of the 1125PC Series, this reel uses a drum-located slip ring assembly, which transfers electrical current through the rotating reel while keeping the connection accessible for routine service. The 600 volt rating supports demanding power distribution applications when matched to the correct cord, plug, and electrical service.

Built with an all-welded steel 'A' frame and permanently lubricated self-aligning pillow block bearings, the 1125PCL-8M is made for smooth manual rotation and stable cord management in industrial, construction, railroad, manufacturing, and utility vehicle environments. Its 45 amp, 3-pole slip ring configuration is suited for three-conductor power cord applications where reel capacity, voltage rating, and electrical code compliance must be checked before installation.

Type: Hand Crank Cord Reel | Series: 1125PC Series / 1125PCL Series | Configuration: Less Cord | Model: 1125PCL-8M | Cord Capacity: 200 ft of 10/3 or 175 ft of 8/3 | Cord O.D. Range: .63"–.75" | Voltage Rating: 600V | Slip Ring Amps: 45 Amps | Slip Ring Poles: 3 | Approx. Weight: 35 lbs | Size Index: 1

Features:

• Drum-located slip ring assembly with an easy-access cover supports routine inspection and service without disassembling the reel frame.
• 45 amp, 600 volt, 3-pole slip ring configuration supports compatible three-conductor power cord installations.
• All welded steel 'A' frame construction helps strengthen the reel structure for shop, vehicle, and facility mounting.
• Narrow reel width supports installation in restricted spaces where wall, bench, truck, or equipment clearance is limited.
• Permanently lubricated self-aligning pillow block bearings help the drum rotate smoothly during cord payout and rewind.
• 3/4" trade size single gang outlet box provides external access to lead connections.
• 'Cable Keeper' helps prevent the lead cable from whipping or twisting during use.
• Adjustable tension brake helps prevent free-wheeling, while the long-handled locking pin secures the reel from rotation during transport or storage.
• Solid steel direct hand crank with smooth round handle provides simple manual rewind without a motor drive system.

Made in USA:

2 Year Warranty

Applications:

• Manufacturing plants and facilities managing portable power cords for tools, lighting, and equipment connection points.
• Service, mechanic, and utility vehicles where loose cord storage can create tangles, abrasion, and wasted setup time.
• General industrial maintenance areas that need controlled payout and rewind for long 10/3 or 8/3 power cord runs.
• Construction and railroad operations using cord reels to keep electrical service more organized around temporary work zones.
• Shop and maintenance bays where a hand crank reel is preferred over spring rewind or powered rewind systems.

FAQs:

• Q: Does the Coxreels 1125PCL-8M include cord?
  A: No. The 1125PCL-8M is supplied less cord, meaning the reel is sold without cord installed. The buyer must provide compatible cord separately.
• Q: What cord sizes fit this reel?
  A: This model is rated to store up to 200 ft of 10/3 cord or 175 ft of 8/3 cord, based on the manufacturer's listed cord outside diameter range of .63" to .75". Always verify the actual cord outside diameter before installation.
• Q: What does the slip ring do on a cord reel?
  A: A slip ring allows electrical current to pass through the rotating drum while the reel pays out or rewinds cord. On this reel, the slip ring assembly is mounted at the drum for easier access during service.
• Q: Can the cord stay wound on the reel while energized?
  A: Coxreels cautions that the cord should be completely unspooled when energized unless proper NEC ampacity derating factors are applied. Cord gauge, length, insulation rating, number of conductors, and electrical service must be evaluated for the installation.
• Q: Is this a hand crank or motorized reel?
  A: This copy is written for a hand crank configuration. Coxreels lists motor options for the 1125PC Series, but the product title and buyer-facing configuration identify this SKU as a hand crank cord reel.
