Cleco 19TCA03Q T-Handle Pneumatic Screwdriver | 19 Series | Push and Trigger Start | 1,900 RPM | 0.4 - 2.1 (ft-lbs) Torque Range

For light assembly work that needs more torque than the fastest 19 Series T-handle model, the Cleco 19TCA03Q T-Handle Pneumatic Screwdriver delivers a 1,900 RPM free speed with a 0.4 - 2.1 ft-lbs torque range. This balance of speed and control makes it useful for small to medium screws, light threaded fasteners, and repetitive production jobs where operators need fast run-down without exceeding the torque limits of the assembly.

The 19 Series T-handle / pistol-grip body gives the operator a familiar hand position for bench, line-side, and fixture-based fastening. Its push and trigger start operation allows the tool to be activated either by forward pressure on the fastener or by the trigger, giving operators flexibility across different work positions. The Clecomatic shut-off clutch stops the screwdriver when the set torque is reached, helping support more consistent fastening on repeated cycles. A 1/4" hex quick change drive accepts common screwdriver bits for fast bit changes during mixed assembly work.

Type: Pneumatic Screwdriver | Brand: Cleco | Model: 19TCA03Q | Series: 19 Series | Handle Style: T-Handle / Pistol Grip | Start Type: Push and Trigger Start | Clutch Type: Clecomatic Shut-Off | Drive Size: 1/4" Hex Quick Change | Free Speed: 1,900 RPM | Torque Range: 0.4 - 2.1 ft-lbs | Torque Range: 5 - 25 in-lbs | Torque Range: 0.6 - 2.8 Nm | Air Inlet: 1/4" NPT | Min. Hose Size: 3/8" | Air Consumption: 11 SCFM | Overall Length: 8.0" | Tool Weight: 1.44 lb | Operation: Reversible

Features:

• Clecomatic shut-off clutch helps maintain repeatable torque control on light fastening tasks.
• Push and trigger start operation lets operators choose the start method that best fits the work position.
• 1,900 RPM free speed provides fast screw run-down while retaining added torque capacity over lower-torque models.
• 1/4" hex quick change drive supports fast bit changes when switching between fastener styles.
• T-handle / pistol-grip layout gives a familiar grip for production benches, fixtures, and repair stations.
• Reversible operation allows both installation and removal during assembly, inspection, and rework.
• Low-to-mid torque range helps reduce the risk of over-tightening small screws, plastic parts, and light threaded components.

Applications:

• Electronics and instrument assembly: fastening small screws in housings, brackets, panels, and light component assemblies.
• Appliance and consumer product production: driving screws into sheet metal, molded housings, trim parts, and subassemblies.
• Automotive interior and trim assembly: installing clips, covers, access panels, light brackets, and small threaded fasteners.
• Light manufacturing cells: repeated screwdriving where controlled shut-off torque is needed across many cycles.
• Repair and rework benches: removing and reinstalling fasteners during inspection, troubleshooting, and component replacement.

FAQs:

• Q: How does the 19TCA03Q compare to the 19TCA02Q?
  A: The 19TCA03Q runs at 1,900 RPM and offers a higher 0.4 - 2.1 ft-lbs torque range. It trades some speed for added torque capacity, making it better for fasteners that need slightly more tightening force.
• Q: What does push and trigger start mean on this screwdriver?
  A: Push and trigger start means the operator can activate the screwdriver by pushing into the fastener or by using the trigger. This can help when moving between bench work, fixture work, and different fastening angles.
• Q: What bit style does the Cleco 19TCA03Q use?
  A: This model uses a 1/4" hex quick change drive. Select compatible 1/4" hex bits that match the screw head style and the torque requirements of the job.
• Q: Why choose a shut-off clutch screwdriver instead of a basic air screwdriver?
  A: A shut-off clutch stops the tool when the selected torque is reached. That makes it a better option for repeated assembly work where consistent tightening is important.
• Q: What air supply should be used with the 19TCA03Q?
  A: Use a clean, regulated air supply with a 3/8" minimum hose size and enough capacity to support the listed 11 SCFM air consumption. A properly sized FRL helps condition the air and lubricate the tool.
