Cleco 19PCA09Q P-Handle Pneumatic Screwdriver | 19 Series | Push and Trigger Start | 470 RPM | 1.2 - 6.5 (ft-lbs) Torque Range

Built for controlled screw fastening where added torque capacity matters, the Cleco 19PCA09Q P-handle pneumatic screwdriver combines push and trigger start operation with a 470 RPM free speed for steady, deliberate rundown. Its 15 - 79 in-lbs / 1.2 - 6.5 ft-lbs torque range gives assembly teams more fastening headroom than lower-torque 19 Series models, while the Clecomatic clutch (a torque-control clutch that shuts off at the preset torque) helps support repeatable results across production cycles.

The P-handle shape lets operators apply forward force into the fastener, which is useful for prevailing-torque screws, seated fasteners, and assembly work where a straight inline driver may not provide the preferred hand position. A 1/4" quick-change drive accepts compatible hex bits for fast bit swaps, while the 9.8" overall length, 1.65 lb weight, 1/4" NPT air inlet, and 11 SCFM air consumption make the 19PCA09Q a practical pneumatic screwdriver for workstations that need controlled torque in a compact pistol-style tool.

Type: P-Handle Pneumatic Screwdriver | Series: 19 Series | Start Type: Push and Trigger Start | Clutch Type: Clecomatic Clutch | Drive: 1/4" Quick Change | Tool Torque Range: 15 - 79 in-lbs / 1.7 - 8.9 Nm / 1.2 - 6.5 ft-lbs | Torque Range with Standard Spring: 24 - 60 in-lbs | Free Speed: 470 RPM | Overall Length: 9.8" / 248 mm | Weight: 1.65 lbs / 0.7 kg | Air Inlet: 1/4" NPT | Minimum Hose I.D.: 3/8" | Air Consumption: 11 SCFM

Features:

• Durable Clecomatic clutch supports torque repeatability and longer calibration cycles in controlled fastening operations.
• Push and trigger start configuration gives the operator controlled activation at the fastener and helps reduce unintended rundown.
• 470 RPM free speed balances production efficiency with added control for higher-torque screw fastening.
• P-handle body shape allows forward force to be applied for prevailing-torque fasteners and seated screw applications.
• 1/4" quick change drive supports fast bit changes when moving between compatible screw types or assembly steps.
• Reverse lever can be rotated to accommodate left- or right-handed operators at the workstation.
• Easy access torque verification port supports routine checks during setup, maintenance, and quality control.
• Two grip sizes are available within the 19 Series platform for added operator fit and workstation flexibility.

Made in USA:

Tech Tip: To increase tool performance, extend tool life, and lessen repair costs, use it with a Filter-Regulator-Lubricator FRL)

Applications:

• Automotive component assembly for fastening brackets, housings, covers, trim-related hardware, and light mechanical subassemblies.
• Aerospace and precision manufacturing cells where controlled pneumatic screwdriving is needed with a pistol-style grip.
• Appliance and equipment production for repeated installation of panels, molded parts, sheet metal components, and machine covers.
• Electronics and light industrial assembly where compatible 1/4" hex tooling and repeatable torque shut-off are required.
• MRO and repair benches that need a controlled air screwdriver for recurring screw installation and removal tasks.

FAQs:

• Q: What is the torque range of the Cleco 19PCA09Q?
  A: The listed tool torque range is 15 - 79 in-lbs, which corresponds to approximately 1.2 - 6.5 ft-lbs. This places the 19PCA09Q toward the higher-torque end of the 19 Series P-handle screwdriver range.
• Q: What does the Clecomatic clutch do?
  A: The Clecomatic clutch shuts the tool off when the preset torque is reached. This helps improve fastening repeatability compared with tools that rely only on operator feel or motor stall.
• Q: What bits can be used with this screwdriver?
  A: The 19PCA09Q uses a 1/4" quick change drive for compatible 1/4" hex bits and fastening accessories. Match the bit tip style to the screw recess to prevent cam-out and fastener damage.
• Q: When should I choose the 470 RPM model instead of a faster 660 RPM model?
  A: The 470 RPM speed provides more controlled rundown for applications where torque capacity and seating control are more important than maximum cycle speed. A faster model may be preferred for lower-torque screws or shorter run-down distances.
• Q: What air setup does the Cleco 19PCA09Q require?
  A: The manufacturer lists a 1/4" NPT air inlet, 3/8" minimum hose I.D., and 11 SCFM air consumption. Use clean, regulated air and verify torque after setup with your facility’s approved torque measurement process.

Looking for more information about Cleco Screwdriver? Click here to view the Catalog.

Need left-handed or right-handed Cleco Screwdrivers for your application? Please call (800) 608-5210 or email info@intlairtool.com
