Ingersoll Rand QA8ASLS115NF41S08 Inline Air Nutrunner is configured for repetitive production fastening where direct fastener access and increased torque capability are required. Featuring a 1/2" drive, 51.6–84.8 ft-lbs torque range, 205–215 RPM operating speed, and lever start, this model provides controlled fastening at a measured rundown speed for assembly operations within its specified torque range.
Ingersoll Rand QA8ASLS115NF41S08 uses an inline configuration that keeps the tool body aligned with the fastening axis for workstations where a straight approach to the fastener is available. Its 1/2" square drive accepts compatible sockets, while lever-start operation provides direct operator control over tool activation during each fastening cycle.
Type: Inline Air Nutrunner | Drive Size: 1/2" | Torque Range: 51.6–84.8 ft-lbs | Speed: 205–215 RPM | Start Type: Lever Start | Series: QA8 Series
|
Features:
Made in USA: |
 |
Applications:
- Production fastening operations requiring torque within the 51.6–84.8 ft-lbs range.
- Assembly stations where fasteners can be reached through a direct, straight-line tool approach.
- Repetitive fastening of machinery components, fabricated assemblies, brackets, and similar parts using compatible 1/2" drive sockets.
- Manufacturing processes where a 205–215 RPM operating speed and lever-controlled activation suit the required fastening cycle.
FAQs:
- Q: What torque range does the QA8ASLS115NF41S08 provide?
A: This model has a specified torque range of 51.6–84.8 ft-lbs. - Q: What drive size does this inline air nutrunner use?
A: The QA8ASLS115NF41S08 uses a 1/2" square drive for compatible sockets. - Q: How is this Ingersoll Rand nutrunner activated?
A: This model uses lever-start operation, giving the operator direct control over tool activation during the fastening cycle. - Q: What operating speed is specified for this model?
A: The provided product information lists an operating speed range of 205–215 RPM. - Q: What should be verified before selecting the QA8ASLS115NF41S08?
A: Confirm that the required fastening torque falls within the 51.6–84.8 ft-lbs range and that the 1/2" drive size, inline configuration, and specified operating speed match the requirements of the assembly process.
| SKU | 90 PSI FT-LBS (NM) | 90 PSI RPM | 77 PSI FT-LBS (NM) | 77 PSI RPM | LBS (KG) | IN (MM) | IN (MM) | IN |
|---|---|---|---|---|---|---|---|---|
| LEVER START | ||||||||
| QA8ASLS040NP41S06 | 14.8 – 29.5 (20 – 40) | 600 | 14.8 – 25.8 (20 – 35) | 570 | 5.27 (2.39) | 19.7" (502) | 0.80" (20) | 3/8" |
| QA8ASLS040NP41S08 | 14.8 – 29.5 (20 – 40) | 600 | 14.8 – 25.8 (20 – 35) | 570 | 5.29 (2.40) | 19.7" (502) | 0.80" (20) | 1/2" |
| QA8ASLS055NP41S08 | 18.4 – 40.6 (25 – 55) | 470 | 18.4 – 36.1 (25 – 49) | 445 | 5.29 (2.40) | 19.7" (502) | 0.80" (20) | 1/2" |
| QA8ASLS070NP41S08 | 25.8 – 51.6 (35 – 70) | 355 | 25.8 – 45.7 (35 – 62) | 335 | 5.60 (2.54) | 19.9" (506) | 0.94" (24) | 1/2" |
| QA8ASLS090NP41S08 | 33.2 – 66.4 (45 – 90) | 255 | 33.2 – 59.0 (45 – 80) | 245 | 6.33 (2.87) | 21.3" (542) | 0.94" (24) | 1/2" |
| QA8ASLS115NF41S08 | 51.6 – 84.8 (70 – 115) | 215 | 51.6 – 75.2 (70 – 102) | 205 | 7.50 (3.40) | 21.3" (541) | 2.00" (51) | 1/2" |
| QA8ASLS150NF41S08 | 55.3 – 110.6 (75 – 150) | 165 | 55.3 – 98.1 (75 – 133) | 160 | 7.50 (3.40) | 21.3" (541) | 2.00" (51) | 1/2" |
| QA8ASLS180NF41S08 | 66.4 – 132.8 (90 – 180) | 140 | 66.4 – 118.0 (90 – 160) | 135 | 7.50 (3.40) | 21.3" (541) | 2.00" (51) | 1/2" |
Looking for more information about the Ingersoll Rand Nutrunner? Click here to view the Catalog
For help choosing the correct Ingersoll Rand Nutrunners for your application, please call (800) 608-5210 or email info@intlairtool.com
