Ingersoll Rand QA8ASLS090NP41S08 Inline Air Nutrunner is configured for repetitive production fastening where direct fastener access and higher torque capability are required. Featuring a 1/2" drive, 33.2–66.4 ft-lbs torque range, 245–255 RPM operating speed, and lever start, this model provides controlled fastening at a measured rundown speed for assembly operations within its specified torque range.
Ingersoll Rand QA8ASLS090NP41S08 uses an inline configuration that keeps the tool body aligned with the fastening axis, making it suitable for assembly stations with direct approach access. Its 1/2" square drive accepts compatible sockets, while lever-start operation allows the operator to control tool activation directly during each fastening cycle.
Type: Inline Air Nutrunner | Drive Size: 1/2" | Torque Range: 33.2–66.4 ft-lbs | Speed: 245–255 RPM | Start Type: Lever Start | Series: QA8 Series
|
Features:
Made in USA: |
 |
Applications:
- Production fastening operations requiring torque within the 33.2–66.4 ft-lbs range.
- Assembly workstations where fasteners are accessible through a direct, straight-line tool approach.
- Repetitive fastening of machinery components, fabricated assemblies, brackets, and similar parts using compatible 1/2" drive sockets.
- Manufacturing processes where lever-start activation provides direct operator control over recurring fastening cycles.
FAQs:
- Q: What torque range does the QA8ASLS090NP41S08 provide?
A: This model has a specified torque range of 33.2–66.4 ft-lbs. - Q: What drive size does this inline air nutrunner use?
A: The QA8ASLS090NP41S08 uses a 1/2" square drive for compatible sockets. - Q: How is the QA8ASLS090NP41S08 activated?
A: This model uses lever-start operation, allowing the operator to activate the tool directly during the fastening cycle. - Q: What operating speed is specified for this model?
A: The provided product information lists an operating speed range of 245–255 RPM. - Q: What should be checked before selecting this inline nutrunner?
A: Confirm that the required fastening torque falls within the 33.2–66.4 ft-lbs range and that the 1/2" drive size, inline configuration, and specified operating speed match the requirements of the assembly process.
| SKU | 90 PSI FT-LBS (NM) | 90 PSI RPM | 77 PSI FT-LBS (NM) | 77 PSI RPM | LBS (KG) | IN (MM) | IN (MM) | IN |
|---|---|---|---|---|---|---|---|---|
| LEVER START | ||||||||
| QA8ASLS040NP41S06 | 14.8 – 29.5 (20 – 40) | 600 | 14.8 – 25.8 (20 – 35) | 570 | 5.27 (2.39) | 19.7" (502) | 0.80" (20) | 3/8" |
| QA8ASLS040NP41S08 | 14.8 – 29.5 (20 – 40) | 600 | 14.8 – 25.8 (20 – 35) | 570 | 5.29 (2.40) | 19.7" (502) | 0.80" (20) | 1/2" |
| QA8ASLS055NP41S08 | 18.4 – 40.6 (25 – 55) | 470 | 18.4 – 36.1 (25 – 49) | 445 | 5.29 (2.40) | 19.7" (502) | 0.80" (20) | 1/2" |
| QA8ASLS070NP41S08 | 25.8 – 51.6 (35 – 70) | 355 | 25.8 – 45.7 (35 – 62) | 335 | 5.60 (2.54) | 19.9" (506) | 0.94" (24) | 1/2" |
| QA8ASLS090NP41S08 | 33.2 – 66.4 (45 – 90) | 255 | 33.2 – 59.0 (45 – 80) | 245 | 6.33 (2.87) | 21.3" (542) | 0.94" (24) | 1/2" |
| QA8ASLS115NF41S08 | 51.6 – 84.8 (70 – 115) | 215 | 51.6 – 75.2 (70 – 102) | 205 | 7.50 (3.40) | 21.3" (541) | 2.00" (51) | 1/2" |
| QA8ASLS150NF41S08 | 55.3 – 110.6 (75 – 150) | 165 | 55.3 – 98.1 (75 – 133) | 160 | 7.50 (3.40) | 21.3" (541) | 2.00" (51) | 1/2" |
| QA8ASLS180NF41S08 | 66.4 – 132.8 (90 – 180) | 140 | 66.4 – 118.0 (90 – 160) | 135 | 7.50 (3.40) | 21.3" (541) | 2.00" (51) | 1/2" |
Looking for more information about the Ingersoll Rand Nutrunner? Click here to view the Catalog
For help choosing the correct Ingersoll Rand Nutrunners for your application, please call (800) 608-5210 or email info@intlairtool.com
