Coxreels 1125PCL-8-H Hydraulic Rewind Cord Reel | 1125PCL Series | 200' (10/3) / 175' (8/3) Capacity | 30 Amps | 600 Volts | Less Cord

When a mobile hydraulic system is already available for reel operation, the Coxreels 1125PCL-8-H provides powered rewind for long electrical cord runs without relying on hand cranking or an onboard electric rewind motor. Part of the 1125PCL Series, this hydraulic rewind cord reel is built for storing compatible 3-conductor power cord while maintaining electrical continuity through the reel's drum-located slip ring assembly (the rotating electrical connection that lets current pass through the reel as the drum turns). With 30 amps, 600 volts, and a 3-pole slip ring, it gives buyers a high-capacity cord management platform for equipment, service vehicles, plants, and field operations where cord length, amperage, and voltage rating must be selected carefully.

The 1125PCL-8-H stores up to 200 ft of 10/3 cord or 175 ft of 8/3 cord, allowing the installer to choose the cord gauge that matches load requirements, distance, voltage drop, and applicable electrical codes. Its hydraulic rewind configuration is especially useful on trucks, utility bodies, mining support equipment, and service platforms that already have hydraulic power available. The all-welded steel 'A' frame, narrow profile, pillow block bearings, adjustable tension brake, Cable Keeper, and long-handled locking pin support controlled payout, secure transport, and organized cord storage in fixed or mobile work environments.

*Note: This Coxreels model is supplied less cord. Power cord must be selected and installed separately based on the electrical load, cord gauge, insulation rating, service type, and applicable local or national electrical codes.

Type: Hydraulic Rewind Cord Reel | Series: 1125PCL Series | Model: 1125PCL-8-H | Configuration: Less Cord | Cord Capacity: 200 ft of 10/3 or 175 ft of 8/3 | Cord Grip Range: .63"-.75" | Voltage Rating: 600V | Slip Ring Amps: 30 Amps | Slip Ring Poles: 3 | Rewind Type: Hydraulic Motor | Approx. Ship Weight: 41 lbs

Features:

• Hydraulic rewind operation supports powered retrieval where a hydraulic power source is already available on service trucks, mobile equipment, or plant machinery.
• Drum-located slip ring assembly includes an easy-access cover for routine service without removing the reel from its mounted position.
• 30 amp, 600 volt, 3-pole slip ring configuration supports compatible 3-conductor cord applications.
• All welded steel 'A' frame construction strengthens the reel structure for fixed installation and mobile use.
• Narrow reel width helps simplify installation in restricted spaces, compartments, truck bodies, and equipment bays.
• Permanently lubricated, self-aligning pillow block bearings promote smooth drum rotation during payout and rewind.
• Cable Keeper helps prevent the lead cable from whipping or twisting as the reel operates.
• Adjustable tension brake helps prevent free-wheeling, while the long-handled locking pin secures the drum during transport or storage.

Made in USA:

2 Year Warranty

Applications:

• Utility and fleet service trucks - storing long power cord runs on vehicles where hydraulic power is already available for reel rewind.
• Mining, construction, and railroad operations - managing cord on field equipment, service platforms, and support vehicles in rugged work areas.
• Industrial maintenance and MRO - keeping electrical cord organized around repair bays, plant equipment, and temporary power access points.
• Mobile equipment and OEM installations - integrating powered cord storage into machinery packages, truck bodies, and hydraulic service systems.
• Facility shops and garages - organizing long electrical cord runs where a hydraulic rewind reel is preferred over hand crank operation.

FAQs:

• Q: Does the Coxreels 1125PCL-8-H come with cord installed?
  A: No. This is a less-cord reel, so compatible cord must be supplied separately and installed before use. The reel capacity is 200 ft of 10/3 cord or 175 ft of 8/3 cord.
• Q: What does hydraulic rewind mean on this cord reel?
  A: Hydraulic rewind means the drum is powered by a hydraulic motor instead of a hand crank, spring rewind, air motor, or electric motor. It is a practical choice when the installation already has hydraulic power available.
• Q: What does the slip ring rating mean?
  A: The slip ring is the rotating electrical connection inside the reel. This model is rated for 30 amps, 600 volts, and 3 poles, so the installed cord and connected equipment must stay within those electrical limits.
• Q: Can the reel be used with the cord partially wound on the drum?
  A: Coxreels cautions that cord should be completely unspooled when energized unless proper ampacity derating is applied. Cord size, length, insulation type, load, heat buildup, and electrical code requirements should be reviewed before operation.
• Q: How is this different from the 1125PCL-8-E or 1125PCL-8-EF?
  A: The 1125PCL-8-H uses hydraulic rewind. The 1125PCL-8-E uses 12V DC electric rewind, while the 1125PCL-8-EF uses 24V DC electric rewind.
