Ingersoll Rand QS1P20C1D Inline Air Screwdriver | 2,000 RPM | 3 - 22.1 (in-lbs) Torque Range | Adjustable Cushion Clutch

Designed for high-speed precision fastening, the Ingersoll Rand QS1P20C1D Inline Air Screwdriver delivers a 3–22.1 in-lb (0.3–2.5 Nm) torque range, 2,000 RPM free speed, and features an Adjustable Cushion Clutch for smooth, repeatable fastening performance. Its ergonomic inline configuration provides excellent balance and control, making it ideal for light-duty assembly applications requiring fast cycle times and consistent torque accuracy.

Part of the proven QS Series, this pneumatic screwdriver incorporates a durable lube-free motor and lightweight composite housing to reduce maintenance while supporting continuous-duty industrial production. The externally adjustable cushion clutch minimizes fastener damage and delivers repeatable torque across precision assembly applications.

Type: Inline Air Screwdriver | Series: QS Series | Model: QS1P20C1D | SKU: QS1P20C1D | Drive Type: 1/4 in. Hex Quick Change | Clutch Type: Adjustable Cushion Clutch | Start Type: Push-to-Start | Torque Range: 3–22.1 in-lb (0.3–2.5 Nm) | Free Speed: 2,000 RPM | Weight: 1.90 lb (0.86 kg) | Length: 9.3 in. (236 mm) | Air Inlet: 1/4 in. NPT | Minimum Hose I.D.: 1/4 in. | Air Consumption: 16 CFM (453 L/min) | Sound Level: 73 dBA

Features: Inline configuration provides excellent balance and precision during repetitive fastening tasks. Push-to-start operation improves productivity for high-volume assembly applications. Externally adjustable cushion clutch delivers smooth, repeatable torque output. 2,000 RPM free speed supports rapid fastening cycles while maintaining fastening accuracy. 1/4 in. hex quick-change chuck enables fast bit replacement. Lube-free motor helps minimize routine maintenance. Ergonomic composite housing enhances operator comfort during extended production shifts. Lightweight construction helps reduce operator fatigue. Designed for continuous-duty industrial assembly environments. Suitable for precision fastening of threaded fasteners in repetitive production applications. Made in USA:

Applications:

• Electronics manufacturing.
• Medical device assembly.
• Appliance production.
• Light mechanical assembly.
• General industrial production.
• High-volume precision fastening.

FAQs:

• Q: What is the torque range of this screwdriver?
  A: This model provides an adjustable torque range of 3–22.1 in-lb (0.3–2.5 Nm).
• Q: What type of clutch does this tool use?
  A: It features an externally adjustable cushion clutch for smooth and repeatable fastening.
• Q: What start mechanism does this screwdriver use?
  A: This model utilizes a push-to-start mechanism for efficient production fastening.
• Q: Does this tool require routine motor lubrication?
  A: No. The QS Series utilizes a lube-free motor that helps minimize maintenance.
• Q: What type of bits does this screwdriver accept?
  A: It is equipped with a standard 1/4 in. hex quick-change chuck.

Looking for more information about the Ingersoll Rand Screwdriver? Click here to view the Catalog

For help choosing the correct Ingersoll Rand Screwdrivers for your application, please call (800) 608-5210 or email info@intlairtool.com
