Ingersoll Rand 182G Swan Neck Grip Chisel Scaler is a pneumatic surface preparation tool designed for industrial maintenance, repair, and construction applications requiring controlled chisel impact. Featuring a 4,000 blows per minute rate, a 1.06" stroke length, and a 0.88" bore, the 182G delivers efficient material removal from metal surfaces, weld areas, and fabricated components.
The swan-neck grip design provides ergonomic handling and improved control during extended use, allowing operators to position the chisel for maximum contact with the work surface. Its 4,000 BPM impact rate ensures repeated striking action for breaking away corrosion, scale, coatings, and other surface contaminants, while the 1.06" stroke length delivers sufficient chisel travel for efficient surface cleaning.
Type: Swan Neck Grip Chisel Scaler | Model: 182G | Blows Per Minute: 4,000 BPM | Stroke Length: 1.06" | Bore Size: 0.88"
Features:
- Swan-neck grip design provides ergonomic control and comfortable handling during extended surface preparation tasks.
- 4,000 blows per minute delivers consistent and repeated impact action for material removal.
- 1.06" stroke length allows sufficient chisel movement for effective cleaning of metal surfaces and weld areas.
- 0.88" bore supports the pneumatic operating mechanism of the scaler.
- Chisel-style tooling focuses impact on the surface to remove corrosion, scale, and coatings efficiently.
- Pneumatic operation provides reliable performance in industrial repair, maintenance, and fabrication applications.
Made in USA:
Applications:
- Industrial maintenance: removing rust, scale, and coatings from machinery and metal assemblies.
- Weld cleaning: preparing weld areas and removing slag or surface buildup from fabricated components.
- Construction equipment maintenance: cleaning and preparing metal surfaces on heavy equipment and structural components.
- Fabrication operations: assisting with surface conditioning before welding, coating, or repair work.
- General surface preparation: providing controlled pneumatic chisel action for cleaning and material removal.
FAQs:
- Q: What is the Ingersoll Rand 182G used for?
A: The 182G is a swan-neck grip pneumatic chisel scaler used for removing rust, scale, coatings, and surface buildup from metal surfaces. - Q: What is the impact rate of the 182G?
A: The manufacturer specification lists the tool at 4,000 blows per minute. - Q: What does the 1.06" stroke length indicate?
A: Stroke length refers to the distance the chisel travels during each impact cycle. The 182G has a listed stroke length of 1.06". - Q: How does the swan-neck grip benefit operation?
A: The swan-neck grip provides better ergonomics and control, especially during extended surface preparation tasks or when reaching difficult angles. - Q: What should be checked before using the 182G?
A: Ensure the compressed-air supply is appropriate for the tool and select the correct chisel accessory for the application.
| SKU | Handle Description | Stroke in (mm) | Bore in (mm) | Weight lb (kg) | Length in (mm) | bpm | cfm | Inlet Size NPT in | Recommended Hose Size in (mm) |
|---|---|---|---|---|---|---|---|---|---|
| NEEDLE SCALERS | |||||||||
| 172LNA1 | In-line | 0.56" (14) | 0.88" (24) | 5.25 (2.38) | 13.75" (349) | 5,500 | 12 | 1/4" | 5/16" (8) |
| 182LNA1 | In-line | 1.06" (27) | 0.88" (24) | 5.75 (2.61) | 15" (381) | 4,000 | 13 | 1/4" | 5/16" (8) |
| 170PG | Pistol grip | 1.4" (35.6) | 0.925" (23.5) | 6.62 (3.00) | 12.4" (315) | 3,000 | 5.5 | 1/4" | 5/16" (8) |
| 180PG | Pistol grip | 1.54" (39.1) | 1.125" (28.6) | 8.88 (4.03) | 13.5" (343) | 2,200 | 8 | 1/4" | 5/16" (8) |
| CHISEL SCALERS | |||||||||
| 172L | In-line | 0.56" (14) | 0.88" (24) | 3.69 (1.69) | 7.63" (194) | 5,500 | 12 | 1/4" | 5/16" (8) |
| 182G | Swan neck | 1.06" (27) | 0.88" (24) | 5.31 (2.41) | 12.81" (325) | 4,000 | 13 | 1/4" | 5/16" (8) |
| 182L | In-line | 1.06" (27) | 0.88" (24) | 4.06 (1.84) | 9" (229) | 4,000 | 13 | 1/4" | 5/16" (8) |
| 170PG-CS | Pistol grip | 1.4" (35) | 0.93" (23) | 5.32 (2.4) | 12.4" (314) | 3,000 | 5.5 | 1/4" | 5/16" (8) |
| 180PG-CS* | Pistol grip | 1.54" (39) | 1.13" (28) | 6.81 (3.1) | 12.4" (314) | 2,200 | 8 | 1/4" | 5/16" (8) |
Looking for more information about Ingersoll Rand Tool? Click here to view the Catalog.
For help selecting the correct Ingersoll Rand Chisel Scalers for your assembly application, call (800) 608-5210 or email info@intlairtool.com
