Ingersoll Rand 170PG Pneumatic Needle Scaler is designed for heavy-duty surface preparation applications where efficient removal of rust, scale, paint, and other surface contaminants is required. Featuring 3,000 blows per minute, a 1.4" stroke length, and a 0.925" bore, this pneumatic needle scaler delivers powerful impact action for industrial maintenance, repair, fabrication, and construction surface-cleaning tasks.
The 170PG uses a pistol-grip configuration that provides a comfortable operating position for extended surface preparation work. Its 1.4" stroke length allows substantial needle travel during each impact cycle, while the 3,000 BPM impact rate provides repeated striking action to help remove stubborn buildup from metal surfaces, weld areas, and equipment components.
Type: Pneumatic Needle Scaler | Model: 170PG | Configuration: Pistol Grip | Blows Per Minute: 3,000 BPM | Stroke Length: 1.4" | Bore Size: 0.925"
Features:
- Pistol-grip configuration provides a controlled operating position for surface preparation applications.
- 3,000 blows per minute delivers repeated impact action for removing rust, scale, coatings, and surface buildup.
- 1.4" stroke length provides extended needle movement during each impact cycle.
- 0.925" bore supports the pneumatic impact mechanism of the tool.
- Needle-style cutters conform to irregular surfaces and help clean around welds, edges, and complex metal contours.
- Pneumatic operation provides consistent impact performance for demanding maintenance and repair environments.
Made in USA:
Applications:
- Industrial maintenance: removing corrosion, scale, and coatings from machinery, equipment, and metal components.
- Weld preparation and cleaning: cleaning weld areas and removing slag or surface residue from fabricated parts.
- Construction equipment maintenance: preparing metal surfaces on heavy equipment and structural components.
- Fabrication work: assisting with surface conditioning before welding, coating, or repair operations.
- Marine and repair applications: supporting corrosion removal and metal surface preparation tasks.
FAQs:
- Q: What is the Ingersoll Rand 170PG used for?
A: The 170PG is a pneumatic needle scaler designed for removing rust, scale, coatings, and other surface contaminants from metal surfaces. - Q: What is the impact rate of the 170PG needle scaler?
A: The manufacturer specification lists the tool at 3,000 blows per minute. - Q: What does the 1.4" stroke length indicate?
A: Stroke length refers to the distance the needles travel during each impact cycle. The 170PG has a listed stroke length of 1.4". - Q: What is the benefit of a pneumatic needle scaler?
A: A pneumatic needle scaler uses repeated impact action to help remove surface buildup more efficiently than manual scraping or chipping methods. - Q: What should be checked before using the 170PG?
A: Confirm that the compressed-air supply is suitable for the tool and select the correct surface preparation method for the material and application.
| SKU | Handle Description | Stroke in (mm) | Bore in (mm) | Weight lb (kg) | Length in (mm) | bpm | cfm | Inlet Size NPT in | Recommended Hose Size in (mm) |
|---|---|---|---|---|---|---|---|---|---|
| NEEDLE SCALERS | |||||||||
| 172LNA1 | In-line | 0.56" (14) | 0.88" (24) | 5.25 (2.38) | 13.75" (349) | 5,500 | 12 | 1/4" | 5/16" (8) |
| 182LNA1 | In-line | 1.06" (27) | 0.88" (24) | 5.75 (2.61) | 15" (381) | 4,000 | 13 | 1/4" | 5/16" (8) |
| 170PG | Pistol grip | 1.4" (35.6) | 0.925" (23.5) | 6.62 (3.00) | 12.4" (315) | 3,000 | 5.5 | 1/4" | 5/16" (8) |
| 180PG | Pistol grip | 1.54" (39.1) | 1.125" (28.6) | 8.88 (4.03) | 13.5" (343) | 2,200 | 8 | 1/4" | 5/16" (8) |
| CHISEL SCALERS | |||||||||
| 172L | In-line | 0.56" (14) | 0.88" (24) | 3.69 (1.69) | 7.63" (194) | 5,500 | 12 | 1/4" | 5/16" (8) |
| 182G | Swan neck | 1.06" (27) | 0.88" (24) | 5.31 (2.41) | 12.81" (325) | 4,000 | 13 | 1/4" | 5/16" (8) |
| 182L | In-line | 1.06" (27) | 0.88" (24) | 4.06 (1.84) | 9" (229) | 4,000 | 13 | 1/4" | 5/16" (8) |
| 170PG-CS | Pistol grip | 1.4" (35) | 0.93" (23) | 5.32 (2.4) | 12.4" (314) | 3,000 | 5.5 | 1/4" | 5/16" (8) |
| 180PG-CS* | Pistol grip | 1.54" (39) | 1.13" (28) | 6.81 (3.1) | 12.4" (314) | 2,200 | 8 | 1/4" | 5/16" (8) |
Looking for more information about Ingersoll Rand Tool? Click here to view the Catalog.
For help selecting the correct Ingersoll Rand Needle Scalers for your assembly application, call (800) 608-5210 or email info@intlairtool.com
