Built for large-diameter hose storage with smoother manual winding, the Coxreels 1185-2028-C beveled gear hand crank hose reel provides 1-1/2" I.D. x 125 ft hose capacity with a 1500 PSI maximum pressure rating. The 1185 Series is made for long lengths of large hose used in increased-volume delivery applications, giving industrial maintenance teams, fleet shops, utility crews, and mobile service operators a strong reel platform for heavier hose setups.
This model is supplied less hose, allowing the buyer to install a compatible 1-1/2" hose matched to the application's fluid, pressure, temperature, and fitting requirements. The beveled gear hand crank with removable handle gives the operator a geared manual rewind option for controlled hose retrieval, while Coxreels' low profile outlet riser and open drum slot help guide hose into a flatter, smoother wrap. The all-welded steel 'A' frame supports heavier hose loads for shop, truck, and field installations.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
Type: Beveled Gear Hand Crank Hose Reel | Series: 1185 Series | Model: 1185-2028-C | Configuration: Less Hose | Hose I.D.: 1-1/2" | Hose O.D.: 2-1/16" | Hose Capacity: 125 ft | Hose Included: No | Max Pressure: 1500 PSI | Ship Weight: 112 lbs | Overall Dimensions: 33.5" W x 30" H x 28" L | Mounting Pattern: 23.25" M x 18.5" N | Base: 25.5" X x 24.5" Y
Features:
- Beveled gear hand crank with removable handle provides a geared manual rewind option for controlled large-hose retrieval.
- 1185 Series design handles long lengths of large diameter hose for increased volume delivery applications.
- 1-1/2" x 125 ft hose capacity supports large hose installations where smaller reels do not provide enough diameter or storage capacity.
- All welded steel 'A' frame construction provides strength for heavier hose loads and mobile applications.
- Exclusive low profile outlet riser and open drum slot design provide a non-crimping, flat, smooth hose wrap.
- External fluid path with full-flow NPT swivel inlet supports efficient flow through the reel and simplifies seal access.
- Lubricated horizontal surface mount bearings support smooth drum rotation during payout and rewind.
- Adjustable tension brake helps prevent free-wheeling during operation.
- Rolled edges and ribbed discs provide strength, hose protection, and safer handling around the reel drum.
- CPC powder coat finish helps resist chips and rust in industrial, fleet, utility, and service environments.
Made in USA:
Applications:
- Industrial fluid transfer stations requiring 125 ft of large 1-1/2" hose capacity from a fixed reel location.
- Fleet and heavy equipment service areas where large-diameter hose needs to be stored neatly after maintenance, fueling support, or utility work.
- Plant maintenance and MRO departments handling high-volume air, water, oil, or compatible fluid transfer through customer-supplied hose.
- Construction, utility, and field service operations that need a rugged 'A' frame reel platform for long hose storage.
- Mobile service trucks and trailers where a geared manual crank is preferred over air motor or electric rewind systems.
FAQs:
- Q: Does the Coxreels 1185-2028-C include hose?
A: No. This model is supplied less hose. The buyer must install a compatible 1-1/2" I.D. hose that matches the application's pressure, temperature, fluid, and fitting requirements. - Q: What is a beveled gear hand crank?
A: A beveled gear hand crank uses a gear arrangement to assist manual rewind instead of relying on a direct crank alone. It gives the operator controlled hose retrieval without requiring compressed air or electric power at the reel location. - Q: What hose size will this reel hold?
A: This reel is listed for 1-1/2" I.D. hose with a 2-1/16" O.D. and 125 ft capacity. Hose outside diameter is important because a larger O.D. hose can reduce the amount of hose the reel can safely store. - Q: Can this reel be used at 1500 PSI?
A: The reel is rated to 1500 PSI, but the final system pressure must not exceed the lowest-rated component in the hose assembly. Confirm the installed hose, fittings, swivel, and system requirements before pressurizing. - Q: Why choose the 1185-2028-C instead of the standard 1185-2028 hand crank reel?
A: Both models support the same 1-1/2" x 125 ft hose capacity and 1500 PSI rating, but the '-C' version adds the beveled gear hand crank with removable handle. It is a better fit when the user wants geared manual rewind control while avoiding powered rewind components.
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required | INLET SWIVEL & OUTLET RISER | PSI | APRX. LBS. | SIZE INDEX | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | ||||||
|
1185 SERIES - IN-LINE SWIVEL
|
|||||||||||
| 1185-2028 | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-A | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-AB | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-C | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-E | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-EA | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-ED | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
| 1185-2028-EF | 1-1/2" | 2-1/16" | 125 | 1-1/4" | 1-13/16" | 180 | 1-1/2" F NPT | 1,500 | 109 | 5 | |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
