Built for large-diameter hose storage with a shorter 70 ft capacity than the larger 125 ft 1185 configurations, the Coxreels 1185-2020 hand crank hose reel provides 1-1/2" I.D. x 70 ft hose capacity with a 1500 PSI maximum pressure rating. The 1185 Series is made for increased-volume delivery applications where industrial maintenance teams, fleet shops, utility crews, and mobile service operators need a strong reel platform for heavier hose without oversizing the hose capacity.
This model is supplied less hose, allowing the buyer to install a compatible 1-1/2" hose matched to the application's fluid, pressure, temperature, and fitting requirements. The hand crank rewind gives operators direct manual control over hose retrieval, while Coxreels' all-welded steel 'A' frame supports the added weight of large-diameter hose. The low profile outlet riser and open drum slot help guide hose into a flatter, smoother wrap, and the adjustable tension brake helps reduce free-wheeling during payout or rewind.
*Note: The above product image is for illustration purposes only. This product is a reel and does not include any hose. Please note this before ordering.
Type: Hand Crank Hose Reel | Series: 1185 Series | Model: 1185-2020 | Configuration: Less Hose | Hose I.D.: 1-1/2" | Hose O.D.: 2-1/16" | Hose Capacity: 70 ft | Hose Included: No | Max Pressure: 1500 PSI | Ship Weight: 91 lbs | Overall Dimensions: 33.5" W x 30" H x 20" L | Mounting Pattern: 23.25" M x 18.5" N | Base: 25.5" X x 24.5" Y
Features:
- Hand crank rewind provides direct manual control for winding large-diameter hose back onto the reel.
- 1185 Series design handles long lengths of large diameter hose for increased volume delivery applications.
- 1-1/2" x 70 ft hose capacity supports large hose installations where a shorter capacity is preferred over the larger 125 ft configuration.
- All welded steel 'A' frame construction provides strength for heavier hose loads and mobile applications.
- Exclusive low profile outlet riser and open drum slot design provide a non-crimping, flat, smooth hose wrap.
- External fluid path with full-flow NPT swivel inlet supports efficient flow through the reel and simplifies seal access.
- Lubricated horizontal surface mount bearings support smooth drum rotation during payout and rewind.
- Adjustable tension brake helps prevent free-wheeling during operation.
- Rolled edges and ribbed discs provide strength, hose protection, and safer handling around the reel drum.
- CPC powder coat finish helps resist chips and rust in industrial, fleet, utility, and service environments.
Made in USA:
Applications:
- Industrial fluid transfer stations requiring 70 ft of large 1-1/2" hose capacity from a fixed reel location.
- Fleet and heavy equipment service areas where large-diameter hose needs to be stored neatly after maintenance, utility work, or transfer tasks.
- Plant maintenance and MRO departments handling high-volume air, water, oil, or compatible fluid transfer through customer-supplied hose.
- Construction, utility, and field service operations that need a rugged 'A' frame reel platform with moderate hose capacity.
- Mobile service trucks and trailers where manual crank rewind is preferred and 70 ft of hose reach is sufficient for the job layout.
FAQs:
- Q: Does the Coxreels 1185-2020 include hose?
A: No. This model is supplied less hose. The buyer must install a compatible 1-1/2" I.D. hose that matches the applications pressure, temperature, fluid, and fitting requirements. - Q: What hose size will this reel hold?
A: This reel is listed for 1-1/2" I.D. hose with a 2-1/16" O.D. and 70 ft capacity. Hose outside diameter matters because larger O.D. hose can reduce the amount of hose the reel can safely store. - Q: Can this reel be used at 1500 PSI?
A: The reel is rated to 1500 PSI, but the final system pressure must not exceed the lowest-rated component in the hose assembly. Confirm the installed hose, fittings, swivel, and system requirements before pressurizing. - Q: Why choose the 70 ft model instead of the 125 ft version?
A: The 70 ft model is a better fit when the reel is mounted closer to the work area and excess hose length is not needed. It provides the same 1-1/2" hose I.D. and 1500 PSI reel rating in a shorter hose-capacity configuration. - Q: Why choose a hand crank reel instead of a motor rewind reel?
A: A hand crank reel is practical when manual rewind is acceptable and the job does not require powered retrieval. It also avoids the need for compressed air or electrical power at the reel location.
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required | INLET SWIVEL & OUTLET RISER | PSI | APRX. LBS. | SIZE INDEX | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | ||||||
|
1185 SERIES - IN-LINE SWIVEL
|
|||||||||||
| 1185-2020 | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-A | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-AB | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-C | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-E | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-EA | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-ED | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
| 1185-2020-EF | 1-1/2" | 2-1/16" | 70 | 1-1/4" | 1-13/16" | 80 | 1-1/2" F NPT | 1,500 | 70 | 3 | |
