Cleco 80PTHH354 Shut-Off Model Pneumatic Pulse Tool | H-Series | 3,500 RPM | 1/2" Square Drive | 36.9 - 59 (ft-lbs) Torque Range

Built for controlled assembly fastening where repeatability matters, the Cleco 80PTHH354 H-Series shut-off pneumatic pulse tool delivers a 36.9 - 59 ft-lbs torque range for medium-torque production joints, fixture work, and general industrial bolt-up. It's 1/2" square drive accepts compatible impact-rated sockets, while the 3,500 RPM free speed helps run fasteners down quickly before final torque is reached.

The shut-off system stops the tool when the preset torque is achieved, helping reduce over-tightening and improve fastening consistency. As a pulse tool, the 80PTHH354 uses controlled pulsing action to reduce torque reaction compared with conventional impact-style fastening, making it a strong fit for automotive assembly, appliance manufacturing, heavy truck production, and MRO workstations where operators repeat the same fastening process throughout the shift.

Type: Shut-Off Pneumatic Pulse Tool | Series: H-Series | Model: 80PTHH354 | Drive Size: 1/2" | Drive Type: Square | Torque Range: 36.9 - 59 ft-lbs / 50 - 80 Nm | Free Speed: 3,500 RPM | Air Consumption: 19.40 SCFM | Air Inlet: 1/4" NPT | Recommended Hose I.D.: 3/8"

Features:

• Shut-off pulse fastening helps stop the tool at the set torque for more consistent assembly results.
• Market-leading repeatability and accuracy support production environments where fasteners must be tightened the same way from cycle to cycle.
• Inertia shut-off system provides automatic torque control without requiring the operator to manually judge final tightening.
• Efficient 3-chamber air motor supports fast rundown and steady pneumatic performance.
• External speed control allows adjustment without opening the tool housing.
• Low noise level helps reduce sound exposure in production cells and assembly stations.
• Oil-less blades and reversible torque signal port support integration into controlled fastening processes.
• Lightweight pistol grip format helps improve handling during repeated fastening tasks.

Tech Tip: To increase tool performance, extend tool life, and lessen repair costs, use it with a Filter-Regulator-Lubricator FRL)

Applications:

• Automotive assembly — tightening brackets, subassemblies, and medium-torque fasteners where repeatability is required.
• Heavy truck and trailer production — controlled fastening on chassis, body, and equipment mounting points within the tool’s torque range.
• Appliance and equipment manufacturing — repeated fastening of housings, frames, and structural components.
• Industrial MRO workstations — socket-driven bolt-up and repair tasks where a shut-off pulse tool is preferred over a standard impact wrench.
• Agriculture and off-road equipment assembly — fastening panels, guards, supports, and machine subassemblies in production or service environments.

FAQs:

• Q: What does the shut-off feature do?
  A: The shut-off mechanism stops the tool when the preset torque is reached. This helps reduce over-tightening and supports more consistent fastening across repeated assembly cycles.
• Q: What socket style does the Cleco 80PTHH354 use?
  A: This model uses a 1/2" square drive. Use compatible 1/2" drive impact-rated sockets matched to the fastener size and application.
• Q: Is this the right tool for removing stuck bolts?
  A: No. This is a controlled assembly pulse tool, not a breakaway impact wrench. It is intended for tightening within its 36.9 - 59 ft-lbs torque range.
• Q: What air setup is recommended?
  A: The tool lists 19.40 SCFM air consumption, a 1/4" NPT air inlet, and a recommended 3/8" hose I.D. Use clean, regulated air and a properly sized FRL to support consistent performance.
• Q: What is a pulse tool?
  A: A pulse tool delivers torque through controlled pulses instead of continuous hard reaction. This helps reduce torque reaction felt by the operator while maintaining productive fastening speed.

Looking for more information about Cleco Pulse Tool? Click here to view the Catalog.

Need help selecting the correct Cleco Pulse Tools for your application? Please call (800) 608-5210 or email info@intlairtool.com
