For service bays and equipment stations needing dual hose management on low-voltage DC, the Coxreels 1275-4-50-EB offers powered retrieval for paired lines while meeting explosion-proof electrical requirements. This 1275 Series reel accommodates 1/2" I.D. hoses up to 50 ft with a 3000 PSI maximum rating, helping prevent floor clutter and improve fluid handling safety. The 24V DC explosion proof motor rewind supports controlled hose retraction in mobile or low-voltage DC environments where AC power is unavailable or restricted.
The dual-hose design features separate fluid paths with swivel inlets, Teflon-spaced O-ring seals, and low-profile outlets for a flat hose wrap. Its welded steel frame, ribbed discs, and direct gear drive ensure reliable performance during repeated hose payout and rewind in fleet maintenance, plant MRO, and industrial service settings.
Type: Dual Hose Electric Motor Rewind Reel | Series: 1275 Series | Model: 1275-4-50-EB | Configuration: Less Hose | Motor: 24V DC Explosion Proof | Hose I.D.: 1/2" | Hose O.D.: 7/8" | Hose Capacity: 50 ft | Hose Included: No | Max Pressure: 3000 PSI | Ship Weight: 77 lbs | Overall Dimensions: 22.63" W x 19.13" H x 17.63" L | Mounting Pattern: 11.44" M x 10" N | Base: 13.38" X x 16" Y
Features:
- Dual hose reel configuration stores and retrieves two hoses simultaneously, maintaining organized and efficient fluid management.
- 24V DC explosion proof motor rewind delivers powered hose retraction where AC power is not available or in low-voltage applications.
- Dual external fluid paths with machined solid brass 90° full-flow swivel inlets for consistent flow and simplified hose installation.
- O-ring seals supported with Teflon spacers to maintain leak resistance and support swivel movement during rotation.
- Low-profile outlet risers keep hoses flat on the drum, reducing crimping and wear during rewind.
- One-piece welded 12 gauge steel 'A' frame provides structural integrity and stability for repeated operation.
- Permanently lubricated pillow block bearings allow smooth drum rotation and lower maintenance requirements.
- CPC powder-coated finish and direct gear drive ensure corrosion resistance and reliable powered rewind performance.
Made in USA:
Applications:
- Fleet and truck service areas where paired hoses need controlled storage and easy access without clutter.
- Plant maintenance and MRO where 24V DC motor operation is required for mobile or low-voltage installations.
- Industrial service bays that handle medium-pressure fluids and require precise hose retraction.
- Equipment repair shops where two hose lines must operate together for supply and return circuits.
- Facilities assessing explosion-proof motor options with proper DC classification and compliance confirmation.
FAQs:
- Q: What does 'less hose' mean on the 1275-4-50-EB?
A: The reel is sold without hose. Buyers must supply 1/2" I.D. hose that matches pressure, fittings, and media requirements. - Q: How does the dual hose configuration work?
A: Two separate hoses are routed on the reel simultaneously, useful for paired supply/return or multiple fluid lines from a single reel location. - Q: Can this reel be used at full 3000 PSI?
A: Yes, the reel rating is 3000 PSI, but total system pressure is limited by hose, swivel, and fittings. Always verify compatibility before use. - Q: What does 24V DC explosion proof motor mean?
A: The motor is designed for low-voltage DC operation in potentially hazardous areas. Site safety classification must be verified before installation. - Q: What mounting dimensions should I check?
A: Overall size is 22.63" W x 19.13" H x 17.63" L; mounting pattern 11.44" x 10", base 13.38" x 16". Ensure the surface supports these dimensions.
| LESS HOSE | SIZE INDEX |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required |
INLET SWIVEL & OUTLET RISER |
PSI | APRX. LBS. |
|||||
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | |||||
| 1275-4-50-A | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-C | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-E | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EA | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EB | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-ED | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EF | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EJ | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-H | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
