When a work cell needs two hose paths managed from one reel, the Coxreels 1275-4-50-EA provides a motorized solution for large-capacity dual hose handling. This 1275 Series reel is built for 1/2" I.D. hose with up to 50 ft of capacity and a 3000 PSI maximum pressure rating, giving maintenance teams a clean way to route paired lines for medium-pressure service without loose hose on the floor. The 115V AC explosion proof motor rewind supports powered retrieval where the electrical installation and site classification require a properly specified motor option.
The dual-plumbing layout uses two external fluid paths with swivel inlets and low-profile outlets to help the hose wrap flat across the drum. Its welded steel 'A' frame, ribbed discs, and direct gear drive rewind help the reel stay stable during repeated payout and rewind cycles in shops, service bays, plant maintenance areas, and equipment support stations.
Type: Dual Hose Electric Motor Rewind Reel | Series: 1275 Series | Model: 1275-4-50-EA | Configuration: Less Hose | Motor: 115V AC Explosion Proof | Hose I.D.: 1/2" | Hose O.D.: 7/8" | Hose Capacity: 50 ft | Hose Included: No | Max Pressure: 3000 PSI | Ship Weight: 77 lbs | Overall Dimensions: 22.63" W x 19.13" H x 17.63" L | Mounting Pattern: 11.44" M x 10" N | Base: 13.38" X x 16" Y
Features:
- Dual hose reel configuration manages two hose runs from one reel body, helping organize paired supply and return lines or other compatible dual-line setups.
- 115V AC explosion proof motor rewind provides powered hose retrieval for installations that require this motor style and proper electrical classification review.
- Two external fluid paths with machined solid brass 90° full-flow NPT swivel inlets support efficient flow and simplify hose installation.
- Swivel O-ring seals are supported by Teflon spacers to help maintain sealing support during reel rotation.
- Low-profile outlet risers and an open drum slot help create a flat, non-crimping hose wrap across the drum.
- One-piece CNC robotically welded 12 gauge steel 'A' frame base adds structural rigidity without relying on a bolted frame design.
- Permanently lubricated, self-aligning pillow block bearings support smooth drum rotation during payout and rewind.
- CPC powder coat finish helps resist chips and rust, while the direct gear drive rewind provides smooth rotation without a chain drive.
Made in USA:
Applications:
- Plant maintenance and MRO areas where paired medium-pressure hoses need controlled payout and rewind from a fixed reel location.
- Hydraulic or fluid transfer support stations using compatible hose, fittings, pressure ratings, and media requirements.
- Equipment service bays where two hose paths must be routed together to reduce floor clutter and improve hose storage.
- Fleet, machinery, and industrial repair shops that require a motorized reel instead of manual hand-crank hose retrieval.
- Facilities evaluating explosion proof motor rewind options where final suitability depends on the site's electrical and hazardous-location classification.
FAQs:
- Q: What does 'less hose' mean on the Coxreels 1275-4-50-EA?
A: It means this reel is supplied without hose installed. The buyer must provide compatible 1/2" I.D. hose separately, making sure the hose outside diameter, pressure rating, fittings, and fluid compatibility match the application. - Q: What is the benefit of a dual hose reel?
A: A dual hose reel stores and retrieves two hose lines on one reel. This is useful when paired lines need to move together, such as compatible supply and return circuits or other dual-line service arrangements. - Q: Can this reel be used at the full 3000 PSI rating?
A: The reel is rated up to 3000 PSI, but the complete system is limited by the lowest-rated component. Confirm the hose, fittings, swivels, fluid, and operating temperature before placing the reel into service. - Q: What does the 115V AC explosion proof motor option mean?
A: This SKU uses a 115V AC explosion proof motor rewind configuration. Final approval for any hazardous or classified location should be reviewed by the facility's safety, electrical, or engineering team before installation. - Q: What mounting dimensions should be checked before ordering?
A: Check the overall size of 22.63" W x 19.13" H x 17.63" L, the 11.44" x 10" mounting pattern, and the 13.38" x 16" base dimensions against the planned mounting surface.
| LESS HOSE | SIZE INDEX |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required |
INLET SWIVEL & OUTLET RISER |
PSI | APRX. LBS. |
|||||
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | |||||
| 1275-4-50-A | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-C | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-E | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EA | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EB | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-ED | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EF | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-EJ | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
| 1275-4-50-H | 1/2" | 7/8" | 2/50 | 3/8" | 3/4" | 2/70 | 1/2" F NPT | 3,000 | 40 | 1 |
Looking for more information about the Coxreels Rewind Reel? Click here to view the Catalog.
For help choosing the correct Coxreels Rewind Reels, please call (800) 608-5210 or email info@intlairtool.com
