Built for paired hose handling where hydraulic power is preferred for rewind, the Coxreels 1275-4-200-H is a 1275 Series dual hose hydraulic motor rewind reel with capacity for 200 ft of 1/2" I.D. hose and a 3000 PSI maximum pressure rating. The dual hose layout keeps two compatible hose runs on one reel, helping maintenance crews manage hydraulic service lines, dual product delivery hoses, and twin-agent hose sets without using two separate reels.
This model is supplied less hose, giving the buyer flexibility to install hose assemblies matched to the required fluid, fitting style, pressure rating, and routing layout. The H hydraulic motor rewind configuration is useful on service trucks, mobile equipment skids, and hydraulic-powered work platforms where powered rewind can be tied into a compatible hydraulic system rather than an electric or air motor source.
Type: Dual Hose Hydraulic Motor Rewind Reel | Series: 1275 Series | Model: 1275-4-200-H | Configuration: Less Hose | Rewind Type: Hydraulic Motor Rewind | Hose I.D.: 1/2" | Hose O.D.: 7/8" | Hose Capacity: 200 ft | Hose Included: No | Max Pressure: 3000 PSI | Ship Weight: 83 lbs | Overall Dimensions: 35.88" W x 19.13" H x 17.63" L | Mounting Pattern: 27.44" M x 10" N | Base: 29.38" X x 16" Y
Features:
- Dual plumbing with two swivel inlets and two low profile outlet risers supports two separate hose paths on one reel.
- Hydraulic motor rewind configuration provides powered hose retrieval where a compatible hydraulic power source is available.
- Two machined-from-solid-brass 90° full-flow NPT swivels support fluid flow while simplifying seal maintenance and hose installation.
- Low profile outlet risers and open drum slot design help create a flatter hose wrap and reduce hose crimping during rewind.
- One-piece all welded steel 'A' frame construction adds mounting rigidity for service vehicles, skids, benches, and fixed workstations.
- CNC robotically spun and ribbed discs with rolled edges add drum strength while helping protect hose during storage.
- Permanently lubricated, self-aligning pillow block bearings support smooth drum rotation with reduced routine bearing service.
- Reliable direct gear drive on motor driven models eliminates chain drive components for controlled rewind operation.
- Chip-resistant and rust-inhibiting CPC powder coat finish helps protect the reel frame and drum in shop and field environments.
Made in USA:
Applications:
- Hydraulic service trucks - managing paired hose runs where the rewind system can be supplied by a compatible hydraulic circuit.
- Mobile equipment maintenance - organizing dual hose assemblies around construction, mining, agricultural, and heavy fleet equipment.
- Industrial hydraulic workstations - keeping long high-pressure hose assemblies stored together near presses, power units, or maintenance bays.
- Twin-agent and dual product delivery systems - storing two related hose paths on one reel for cleaner deployment and rewind.
- Offshore, shipyard, and port operations - reducing loose hose clutter where paired service lines must be routed around large equipment.
- Plant MRO departments - improving hose storage for facilities that need long, paired 1/2" hose runs in fixed service areas.
FAQs:
- Q: What does 'less hose' mean on the 1275-4-200-H?
A: It means the reel is supplied without hose installed. The buyer must provide compatible 1/2" I.D. hose separately and verify hose pressure rating, outside diameter, fittings, and media compatibility before operation. - Q: What does the H suffix indicate?
A: H identifies the hydraulic motor rewind configuration. Instead of using an electric or air motor, this reel is set up for hydraulic-powered rewind when connected to a compatible hydraulic power source. - Q: Is this reel suitable for hydraulic hose service?
A: Yes, when the complete hose assembly, fittings, seals, and fluid compatibility match the hydraulic system. The reel is rated for 3000 PSI maximum pressure, but the installed hoses must also be rated for the application. - Q: Does the reel include the hydraulic controls needed to operate the motor?
A: The source data identifies this model as a hydraulic motor rewind reel, but does not list separate hydraulic control valves, hoses, or installation hardware as included. Confirm the required control components before installation. - Q: Why use a dual hose reel instead of two individual reels?
A: A dual hose reel keeps related hose runs together on one drum, reducing mounting footprint and helping operators deploy and rewind both lines in a more organized layout.
| LESS HOSE | SIZE INDEX |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required |
INLET SWIVEL & OUTLET RISER |
PSI | APRX. LBS. |
|||||
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | |||||
| 1275-4-200-A | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-C | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-E | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EA | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EB | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-ED | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EF | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EJ | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-H | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
