When paired hose lines need to be stored, deployed, and rewound from a single mounted reel, the Coxreels 1275-4-200-ED gives service crews a dual-hose solution with powered retraction. This 1275 Series reel is configured for 1/2" I.D. hose with up to 200 ft. capacity and a 3000 PSI maximum pressure rating, making it a practical fit for medium-pressure dual hydraulic, dual product delivery, and twin-line fluid handling applications. The 12V DC explosion proof motor rewind supports powered hose retrieval where compatible low-voltage DC power is available and where an explosion proof motor option is required by the installation environment.
The 1275 Series uses dual plumbing with two swivel inlets and two low profile outlet risers, giving each hose path its own connection point while helping the hose wrap flat across the drum. For buyers planning service truck builds, shop installations, or field maintenance systems, the all-welded steel “A” frame, direct gear drive rewind, open drum slot, and permanently lubricated pillow block bearings help simplify reel placement, hose routing, and long-term operation.
Type: Dual Hose Electric DC Explosion Proof Motor Rewind Hose Reel | Series: 1275 Series | Model: 1275-4-200-ED | Configuration: Less Hose | Rewind Type: 12V DC Explosion Proof Motor Rewind | Hose I.D.: 1/2" | Hose O.D.: 7/8" | Hose Capacity: 200 ft | Max Pressure: 3000 PSI | Hose Included: No | Ship Weight: 98 lbs | Overall Dimensions: 38.63" W x 19.13" H x 17.63" L | Mounting Pattern: 27.44" M x 10" N | Base: 29.38" X x 16" Y
Features:
- Dual plumbing layout provides two external fluid paths with one swivel inlet on each side of the reel.
- Two low profile outlet risers and open drum slot design support dual hose applications while helping create a non-crimping, flat hose wrap.
- Machined from solid brass 90° full-flow NPT swivel inlets allow seal maintenance and hose installation without removing the reel from its mount.
- NITRILE swivel seals with O-ring seals supported by Teflon spacers help support reliable fluid path sealing.
- One piece, all CNC robotically welded 12 gauge steel “A” frame base provides a rigid mounting structure and is not bolted together.
- CNC robotically spun and ribbed discs with rolled edges add strength while helping protect hose during payout and rewind.
- Permanently lubricated, self-aligning pillow block bearings support smooth rotation with reduced bearing maintenance.
- Reliable direct gear drive rewind on motor driven models eliminates chain drive components for smooth, quiet reel operation.
Made in USA:
Applications:
- Dual hydraulic systems: Managing two hydraulic hose lines from one reel where paired supply and return lines need organized payout and rewind.
- Service trucks and mobile maintenance: Storing long hose runs on field service vehicles where 12V DC power is commonly available.
- Petroleum and fluid handling: Supporting dual product delivery or twin-line transfer setups when the hose, fittings, and full system match the reel pressure rating.
- Mining and construction support: Keeping medium-pressure hose lines controlled on equipment service skids, maintenance trailers, or fixed work stations.
- Industrial MRO: Reducing loose hose clutter in shops and maintenance bays where two hose paths are used repeatedly during service work.
FAQs:
- Q: What does “less hose” mean for the 1275-4-200-ED?
A: It means the reel is supplied without hose installed. The buyer must provide compatible hose separately and should confirm the hose I.D., O.D., pressure rating, fitting size, and fluid compatibility before installation. - Q: Is this a 12V or 24V DC explosion proof motor rewind reel?
A: The ED motor option is the 12V DC explosion proof reversible motor option. For the 24V DC explosion proof version, confirm the correct suffix before ordering. - Q: Why use one dual hose reel instead of two separate reels?
A: A dual hose reel keeps two hose paths on one frame, which can reduce mounting space, simplify hose routing, and keep paired lines organized during payout and rewind. - Q: Can this reel be used at the full 3000 PSI rating with any 1/2" hose?
A: No. The complete system must be rated for the intended pressure, including the hose, fittings, fluid path, and installation. The reel rating does not increase the rating of lower-pressure components. - Q: What should be checked before mounting this reel on a truck or skid?
A: Verify the mounting pattern, base footprint, reel weight, hose weight, electrical requirements, and clearance for hose payout. The mounting surface must support the reel and operating loads during use.
| LESS HOSE | SIZE INDEX |
|||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| SKU | STANDARD CAP | OPTIONAL CAP. Reducer required |
INLET SWIVEL & OUTLET RISER |
PSI | APRX. LBS. |
|||||
| I.D. | O.D. | FT. | I.D. | O.D. | FT. | |||||
| 1275-4-200-A | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-C | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-E | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EA | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EB | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-ED | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EF | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-EJ | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
| 1275-4-200-H | 1/2" | 7/8" | 2/200 | 3/8" | 3/4" | 2/300 | 1/2" F NPT | 3,000 | 56 | 4 |
