Coxreels 1125PCL-8410M-H Hydraulic Rewind Cord Reel | 1125PCL Series | 175' (10/4) Capacity | 40 Amps | 600 Volts | Less Cord

For operations that need powered cable retrieval without relying on an electric rewind motor, the Coxreels 1125PCL-8410M-H provides a hydraulic rewind cord reel platform for organized storage of long electrical cord runs. This 1125PCL Series reel is listed with 175 ft of 10/4 cord capacity, a 40 amp slip ring rating, and 600 volt service capability, making it suitable for properly matched 4-conductor cord installations where controlled payout, rewind, and storage are required.

Because this model is supplied less cord, the buyer can select the correct cord construction for the working environment while staying within the reel's capacity and electrical ratings. The hydraulic rewind configuration helps retrieve cord on service trucks, mobile equipment, utility vehicles, and industrial installations where hydraulic power is already available. A drum-located slip ring assembly, welded steel 'A' frame, permanently lubricated self-aligning pillow block bearings, adjustable tension brake, and long-handled locking pin support dependable cord management in shop, field, and vehicle-mounted applications.

Type: Hydraulic Rewind Cord Reel | Series: 1125PCL Series | Model: 1125PCL-8410M-H | Configuration: Less Cord | Cord Capacity: 175 ft of 10/4 Cord | Amperage Rating: 40 Amps | Voltage Rating: 600 Volts | Rewind Type: Hydraulic Rewind | Application: Electric Cord

Features:

• Hydraulic rewind configuration supports powered cord retrieval where hydraulic power is available on service vehicles, mobile equipment, or industrial systems.
• Drum-located slip ring assembly includes an easy-access cover for routine maintenance without removing the reel from its mount.
• 40 amp, 600 volt electrical rating supports properly matched cord and load requirements within the reel's listed capacity.
• All-welded steel 'A' frame construction strengthens the reel base for fixed, mobile, and equipment-mounted installation points.
• Permanently lubricated self-aligning pillow block bearings help the drum rotate smoothly during payout and rewind.
• Integrated 'Cable Keeper' helps prevent the lead cable from whipping or twisting during reel operation.
• Adjustable tension brake helps prevent free-wheeling, giving the operator better control during payout and rewind.
• Long-handled locking pin secures the reel from rotation during transport, storage, or equipment movement.

Made in USA:

2 Year Warranty

Applications:

• Utility and fleet service vehicles - managing long electrical cord runs on trucks equipped with hydraulic power systems.
• Industrial maintenance and MRO - storing cord for portable equipment, work lights, and temporary electrical access around plant service areas.
• Construction and field service - retrieving cord from mobile work platforms, trailers, and service bodies where manual rewind is not preferred.
• Manufacturing and equipment support - keeping cord organized near work cells, machinery service points, and production maintenance areas.
• Mobile repair and fabrication setups - reducing loose cable on vehicle-mounted workstations and jobsite support equipment.

FAQs:

• Q: Does the Coxreels 1125PCL-8410M-H include cord?
  A: No. This is a less-cord reel, meaning cord is not supplied or installed. The buyer must provide compatible cord that matches the reel capacity, electrical rating, cord grip requirements, and jobsite conditions.
• Q: What does hydraulic rewind mean on this cord reel?
  A: Hydraulic rewind means the reel uses hydraulic power to retrieve the cord rather than a spring, hand crank, air motor, or electric motor. This is useful on service trucks, utility equipment, and mobile machinery where hydraulic power is already available.
• Q: Can this reel be used for 600 volt service?
  A: The reel is listed with a 600 volt rating. The installed cord, connections, load, overcurrent protection, and installation method must also be suitable for the actual electrical service.
• Q: Can the cord remain coiled while energized?
  A: Cord reels can trap heat when energized while wound. Coxreels cautions that cord should be fully unspooled during use unless proper NEC ampacity derating factors and safe electrical practices are applied.
• Q: What is the advantage of a drum-located slip ring assembly?
  A: The slip ring assembly maintains electrical continuity between the stationary connection and the rotating reel drum. Locating it at the drum with an access cover makes inspection and routine maintenance more convenient.
