Coxreels 1125PCL-8410M-EB Electric 24V DC 1/2HP Motor Rewind Cord Reel | 1125PCL Series | 175' (10/4) Capacity | 40 Amps | 600 Volts | Less Cord

For jobs where long electrical cord runs need powered retrieval instead of hand cranking, the Coxreels 1125PCL-8410M-EB provides a motorized cord reel platform with 175 ft of 10/4 cord capacity, a 40 Amp slip ring rating, and 600 Volt electrical capacity. The 1125PCL Series uses a drum-located slip ring assembly, which maintains electrical continuity while the reel rotates, with an easy-access cover for routine inspection and service. The 24V DC, 1/2 HP explosion proof motor rewind supports powered cord take-up where manual rewind is inefficient or impractical.

This less-cord configuration gives maintenance teams, fleet upfitters, and facility installers the flexibility to add compatible cord for the application. Its all-welded steel 'A' frame, permanently lubricated self-aligning pillow block bearings, direct gear drive, adjustable tension brake, and long-handled locking pin help keep cord storage controlled during payout, rewind, transport, and storage. The narrow reel profile also helps when mounting space is limited on service vehicles, shop walls, workstations, or equipment skids.

Type: Electric Motor Rewind Cord Reel | Series: 1125PCL Series | Model: 1125PCL-8410M-EB | Configuration: Less Cord | Cord Capacity: 175 ft of 10/4 Cord | Max Amps: 40 Amps | Voltage Rating: 600 Volts | Motor: 24V DC, 1/2 HP Explosion Proof | Rewind: Motor Driven | Frame: All Welded Steel 'A' Frame | Drive: Direct Gear Drive, No Chain

Features:

• Drum-located slip ring assembly with easy-to-access cover supports simple routine maintenance without removing the reel from its mount.
• 40 Amp, 600 Volt slip ring capacity supports compatible electrical cord applications when properly installed to code.
• 24V DC, 1/2 HP explosion proof motor rewind provides powered retrieval for long cord lengths.
• All welded steel 'A' frame construction strengthens the reel structure for shop, vehicle, and facility installations.
• Narrow width helps the reel fit into restricted mounting spaces.
• Permanently lubricated self-aligning pillow block bearings promote smooth drum rotation during payout and rewind.
• 'Cable Keeper' helps prevent the lead cable from whipping or twisting during reel operation.
• Adjustable tension brake helps reduce free-wheeling, while the long-handled locking pin secures the reel from rotation during transport or storage.
• Reliable direct gear drive on motor driven models eliminates chain-driven rewind components.

Made in USA:

2 Year Warranty

Applications:

• Fleet and utility vehicles where 24V DC powered rewind can help manage long electrical cord runs in the field.
• Industrial maintenance shops needing organized cord storage for powered tools, lighting, or service equipment.
• Manufacturing and MRO work areas where controlled payout and rewind help keep cord off the floor and ready for repeat use.
• Construction support operations requiring a motorized cord reel for mobile or semi-permanent power access.
• Railroad, service bay, and equipment support settings where reel locking, tension control, and cord management matter during transport or storage.

FAQs:

• Q: Does the Coxreels 1125PCL-8410M-EB come with cord installed?
  A: No. This is a less-cord reel, meaning the reel is supplied without cord. The buyer must supply compatible 10/4 cord separately and confirm the cord outside diameter, amperage, voltage, and installation requirements before use.
• Q: What does the 24V DC motor rewind do?
  A: The 24V DC motor powers reel rewind so the operator does not have to manually crank the cord back onto the drum. This is helpful when retrieving long cord lengths or when the reel is installed where hand cranking would be inconvenient.
• Q: What is the purpose of the slip ring assembly?
  A: The slip ring assembly allows electrical current to pass through the reel while the drum rotates. On the 1125PCL Series, the slip ring is drum-located and has an access cover for easier routine maintenance.
• Q: Can this reel be mounted on a service truck?
  A: Yes, this type of motor rewind cord reel is commonly selected for vehicle and field-service installations when the electrical system, mounting structure, cord type, and local code requirements are compatible.
• Q: Who should install the cord and electrical connections?
  A: Cord selection and electrical wiring should be completed by a qualified person familiar with the application and applicable electrical codes. The reel rating must match the cord, load, voltage, and operating environment.
