Coxreels 1125PCL-8410M-A Air Motor Rewind Cord Reel | 1125PC Series | 175' (10/4) Capacity | 40 Amps | 600 Volts | Less Cord

When a fixed-length extension cord creates trip hazards or slows down setup, the Coxreels 1125PCL-8410M-A provides organized storage and controlled payout for long power cord runs in shops, service vehicles, manufacturing areas, and utility work environments. This 1125PC Series air motor rewind cord reel is configured for 175 ft of 10/4 SOOW cord capacity, a 600 volt slip ring rating, and 40 amp 4-pole service for applications that require multi-conductor power cord management. The air motor rewind uses a 4-vane aluminum body air motor to retract cord without manual cranking, helping crews manage longer cord lengths more efficiently in mounted installations.

The 1125PCL Series uses a drum-located slip ring assembly, which keeps electrical transfer components accessible through a cover for routine service. Its all-welded steel 'A' frame, narrow mounting width, permanently lubricated self-aligning pillow block bearings, adjustable tension brake, and long-handled locking pin support reliable cord handling in restricted spaces, mobile service setups, and facility maintenance areas where cord control and safe storage matter.

Type: Air Motor Rewind Cord Reel | Series: 1125PC Series / 1125PCL Series | Model: 1125PCL-8410M-A | Configuration: Less Cord | Cord Capacity: 175 ft of 10/4 SOOW cord | Cord O.D.: .72" | Cord Grip Range: .63" - .75" | Slip Ring Rating: 600 Volts | Slip Ring Amps: 40 Amps | Slip Ring Poles: 4 | Motor Option: Air - 4 Vane Aluminum Body Air Motor | Base Reel Approx. Weight: 35 lbs | Air Motor Add-On Approx. Weight: 8 lbs | Size Index: 1

Features:

• Air motor rewind configuration helps retract long cord runs without hand cranking, useful for mounted reels on vehicles, platforms, and shop equipment stations.
• Drum-located slip ring assembly includes an easy-access cover, allowing routine maintenance without removing the reel from its mount.
• Available 4-pole, 40 amp slip ring configuration rated at 600 volts for compatible multi-conductor cord applications.
• All-welded steel 'A' frame construction strengthens the reel structure and provides a stable mounting base.
• Narrow width supports installation in restricted spaces where full-size cord storage equipment may be difficult to fit.
• Permanently lubricated self-aligning pillow block bearings support smooth drum rotation during payout and rewind.
• 'Cable Keeper' helps prevent the lead cable from whipping or twisting during operation.
• Adjustable tension brake helps reduce free-wheeling, while the long-handled locking pin secures the reel during transport or storage.

Made in USA:

2 Year Warranty

Applications:

• Power tool stations where long power cord runs need to be stored, extended, and retracted from a fixed reel location.
• Manufacturing plants and facility maintenance areas using cord-fed equipment in work cells, bays, or service zones.
• Service, mechanic, and utility vehicles where controlled cord storage helps reduce clutter and protect cord from damage during transport.
• Construction, mining, and railroad support operations where mounted cord reels help manage temporary power access around equipment.
• General industrial work areas that require organized storage for compatible 3- or 4-conductor 600V power cord.

FAQs:

• Q: Does the Coxreels 1125PCL-8410M-A include cord?
  A: No. This reel is supplied less cord. The buyer must provide compatible cord that matches the reel capacity, cord grip range, electrical rating, and applicable code requirements.
• Q: What does 10/4 cord capacity mean?
  A: 10/4 refers to 10 gauge, 4 conductor cord. This model is listed for up to 175 ft of 10/4 SOOW cord with a .72" outside diameter.
• Q: What does the 4-pole slip ring rating mean?
  A: A 4-pole slip ring provides four electrical transfer paths through the rotating reel drum. For this model, the slip ring is rated at 600 volts and 40 amps, with the manufacturer noting that the rating must be de-rated by 20% if more than 3 poles are energized.
• Q: Can this reel be used while the cord is still wound on the drum?
  A: The manufacturer cautions that cord should be completely unspooled when energized unless NEC ampacity derating factors are followed. End users are responsible for confirming the cord, load, and installation comply with national and local electrical codes.
• Q: What does the 'A' suffix indicate on this model?
  A: The 'A' suffix identifies the motor option as an air-powered 4-vane aluminum body air motor, adding approximately 8 lbs to the base reel weight.
