Cleco 19RAA02AM2 Pneumatic Collar Reversible Angle Nutrunner | Lever Start | 19 Series | 2,400 RPM | Clutch Shut-Off | 0.3 - 1.5 (ft-lbs) Torque Range

When light assembly work calls for controlled torque in a tight work area, the Cleco 19RAA02AM2 pneumatic collar reversible angle nutrunner delivers repeatable fastening in a compact right-angle format. This 19 Series tool uses a Clecomatic clutch shut-off system, meaning the tool automatically stops when the preset torque is reached to help reduce over-tightening and improve fastening consistency. With a 0.3 - 1.5 ft-lbs torque range, 2,400 RPM free speed, and 1/4" square drive, it is suited for smaller fasteners used in electronics, appliance, automotive, aerospace, and general assembly operations where accuracy matters more than brute force.

The angle-head configuration helps operators reach fasteners near walls, housings, brackets, and other obstructions where straight tools may not fit. A lever start provides familiar pneumatic tool control, while collar reverse allows the operator to change fastening direction without changing grip position. Rated at 90 PSI air pressure and requiring 11 SCFM, the 19RAA02AM2 is a precision assembly nutrunner for production cells, bench assembly stations, and maintenance areas that need reliable low-torque fastening.

Type: Pneumatic Collar Reversible Angle Nutrunner | Series: 19 Series | Start Type: Lever Start | Clutch Type: Clecomatic Clutch Shut-Off | Drive Size: 1/4" | Drive Type: Square | Torque Range: 0.3 - 1.5 ft-lbs | Torque Range: 0.5 - 2.1 Nm | Free Speed: 2,400 RPM | Overall Length: 11.9" | Side to Center: 0.360" | Head Height: 1.06" | Air Inlet: 1/8" NPT | Minimum Hose I.D.: 3/16" | Air Consumption: 11 SCFM | Tool Weight: 1.7 lbs

Features:

• Durable Clecomatic clutch delivers repeatable torque shut-off for controlled assembly fastening.
• Clutch shut-off stops the tool when the preset torque is reached, helping support consistent fastener results across repeated cycles.
• Right-angle head improves access to fasteners located near panels, housings, brackets, and other restricted areas.
• Collar reverse lets the operator change direction for rundown or removal without reaching for a separate control.
• Lever start provides controlled actuation for bench assembly and production fastening work.
• Lightweight handle supports repeated use in assembly environments where tool balance and access are important.
• Grip material is tested to withstand a range of industrial chemicals.
• Standard equipment includes manual and all torque springs required to meet the indicated torque specification.

Made in USA:

Tech Tip: To increase tool performance, extend tool life, and lessen repair costs, use it with a Filter-Regulator-Lubricator FRL)

Applications:

• Electronics and instrument assembly — tightening small fasteners where low torque and repeatability help prevent component damage.
• Automotive component assembly — fastening brackets, interior parts, small housings, and light-duty assemblies in production or repair cells.
• Aerospace and precision manufacturing — controlled fastening in restricted areas where a right-angle tool improves access.
• Appliance and light equipment production — repeated rundown of small nuts and bolts on panels, subassemblies, and housings.
• Maintenance and MRO benches — low-torque fastening and removal tasks where a compact pneumatic nutrunner is easier to control than a larger impact tool.

FAQs:

• Q: What does clutch shut-off mean on this Cleco nutrunner?
  A: Clutch shut-off means the tool stops automatically when the preset torque is reached. This helps improve torque repeatability and reduces the chance of over-tightening small fasteners.
• Q: Is the 19RAA02AM2 better for small fasteners or large bolts?
  A: This model is for smaller fasteners and light assembly work. Its 0.3 - 1.5 ft-lbs torque range is not intended for high-torque bolting or breakaway applications.
• Q: What is the advantage of the angle-head design?
  A: The right-angle head helps the operator reach fasteners in tight or obstructed spaces where an inline or pistol-grip tool may not line up with the fastener.
• Q: What air supply does this nutrunner require?
  A: Tool performance is rated at 90 PSI air pressure. This model lists 11 SCFM air consumption, a 1/8" NPT air inlet, and a 3/16" minimum hose I.D.
• Q: What drive style does this tool use?
  A: The 19RAA02AM2 uses a 1/4" square drive, which is intended for compatible sockets used in low-torque assembly fastening.

Looking for more information about Cleco Nutrunner? Click here to view the Catalog.

Need help selecting the correct Cleco Nutrunners for your application? Please call (800) 608-5210 or email info@intlairtool.com
