Chicago Pneumatic Rectangle Jitterbug Sander | CP7266CVE | 10000 RPM | 3 - 1/4 x 5" Pad Capacity

Built for automotive body-shop sanding, finishing, and surface preparation, the Chicago Pneumatic CP7266CVE Rectangle Jitterbug Sander combines a 10,000 RPM free speed with a 3-1/4" x 5" (80 x 130 mm) pad capacity for working on compact rectangular surfaces. Its 3/32" (2.5 mm) jitterbug orbit provides the specified sanding motion for applications ranging from body filler to paint primer, while the 0.3 HP (210 W) motor supports vertical and horizontal sanding. The central-vacuum configuration allows connection to a compatible dust-extraction system for sanding operations where vacuum collection is required.

The CP7266CVE uses a Hook & Loop foam pad with four pad holes and a palm-shaped soft grip for tool control. Its 18 CFM air consumption, 1.57 lb net weight, and 7.7 m/s² vibration level provide defined operating characteristics for body-shop environments. The aluminum and composite over-sleeve construction, rear exhaust, and lever starting system follow the manufacturer's specified configuration.

Type: Rectangle Jitterbug Sander | Model: CP7266CVE | Part Number: 8941172660 | Free Speed: 10,000 RPM | Power: 0.3 HP (210 W) | Pad Capacity: 3-1/4" x 5" (80 x 130 mm) | Pad Type: Foam | Pad Attachment: Hook & Loop | Pad Holes: 4 | Orbit Size: 3/32" (2.5 mm) | Orbit Type: Jitterbug | Vacuum: Central Vacuum | Air Consumption @ Free Speed: 18 CFM | Air Consumption @ Load: 18 CFM | Net Weight: 1.57 lb (0.71 kg) | Air Inlet: 1/4" NPT | Min. Hose Size: 3/8" (10 mm)

Features:

• 3-1/4" x 5" (80 x 130 mm) rectangular pad provides a compact sanding surface for body-shop work.
• 3/32" (2.5 mm) jitterbug orbit provides the specified sanding motion for surface preparation from body filler to paint primer.
• 10,000 RPM free speed provides the specified operating speed for sanding and finishing applications.
• 0.3 HP (210 W) motor supports vertical and horizontal applications.
• Central vacuum allows connection to a compatible central dust-extraction system.
• Hook & Loop pad attachment secures compatible abrasives to the foam sanding pad.
• Four pad holes provide the specified pad configuration.
• Palm-shaped soft grip supports control during sanding operations.
• Aluminum and composite over-sleeve construction provides the specified main material configuration.
• Rear exhaust and lever starting system follow the manufacturer's specified design.

Applications:

• Automotive body shops — final sanding, finishing, and pre-polishing during vehicle refinishing.
• Body filler preparation — sanding compatible filler before subsequent primer or paint work.
• Paint primer preparation — preparing compatible surfaces for subsequent finishing operations.
• Surface preparation — rectangular sanding tasks requiring a 3/32" jitterbug orbit.
• Central-vacuum sanding — applications where connection to a compatible shop dust-extraction system is preferred.

FAQs:

• Q: What pad size does the CP7266CVE use?
  A: The CP7266CVE uses a 3-1/4" x 5" (80 x 130 mm) rectangular pad.
• Q: What is the difference between CP7266CVE and CP7266E?
  A: Both models use the same 3-1/4" x 5" pad, 10,000 RPM free speed, 3/32" orbit, and 0.3 HP motor. CP7266CVE is the central-vacuum version, while CP7266E is the non-vacuum version.
• Q: What does “Jitterbug” mean?
  A: Jitterbug identifies the specified orbit type. The CP7266CVE uses a 3/32" (2.5 mm) orbit for surface preparation and finishing work.
• Q: What type of pad attachment does the CP7266CVE use?
  A: It uses a Hook & Loop attachment with a foam pad.
• Q: How many holes does the pad have?
  A: The manufacturer specifies four pad holes for the CP7266CVE.
• Q: Does the CP7266CVE have a vacuum system?
  A: Yes. CP7266CVE is configured for central vacuum, allowing connection to a compatible central dust-extraction system.
• Q: How much air does the CP7266CVE consume?
  A: The manufacturer specifies 18 CFM at free speed and 18 CFM at load.
• Q: What is the minimum hose size?
  A: The specified minimum hose internal diameter is 3/8" (10 mm), with the air specifications referenced at 90 PSI (6.3 bar).

Looking for more information about Chicago Pneumatic Jitterbug Sander? Click here to view the Catalog.

For help selecting the correct Chicago Pneumatic Jitterbug Sanders for your assembly application, call (800) 608-5210 or email info@intlairtool.com
