Ingersoll Rand 7803-1B Non-Reversible Air Power Motor is engineered to deliver dependable pneumatic rotary power for industrial equipment requiring increased output torque at controlled operating speeds. Producing 0.85 HP with a free speed of 1,200 RPM, this air motor incorporates a double gear reduction that substantially increases available torque while reducing output speed. It is well suited for OEM machinery, automated production equipment, material handling systems, industrial processing machinery, and other compressed-air powered applications requiring reliable single-direction operation.
The 7803-1B develops a 16.00 lb-ft stall torque, representing the maximum torque produced when the output shaft is prevented from rotating. Its non-reversible configuration provides consistent operation in one direction, while the double-stage gear reduction delivers enhanced rotary force for demanding applications that require greater torque than single-stage gear motors.
Type: Air Power Motor | Model: 7803-1B | Rotation: Non-Reversible | Gear Reduction: Double Gear Reduction | Power: 0.85 HP | Free Speed: 1,200 RPM | Stall Torque: 16.00 lb-ft
Features:
- Non-reversible air motor provides dependable single-direction pneumatic rotary power.
- Double gear reduction significantly increases output torque while reducing operating speed.
- 0.85 HP output supports demanding pneumatic drive applications.
- 1,200 RPM free speed is well suited for equipment requiring controlled rotary performance.
- 16.00 lb-ft stall torque provides a manufacturer-published reference for evaluating maximum torque capability.
- Compact pneumatic motor design integrates easily into OEM machinery and industrial equipment.
- Compressed-air operation eliminates the need for electrical power at the motor, making it suitable for facilities utilizing centralized pneumatic systems.
Made in USA:
Applications:
- OEM machinery requiring dependable single-direction pneumatic rotary power.
- Automated manufacturing and production equipment.
- Industrial processing and assembly systems.
- Material handling, conveyor, and drive applications requiring increased output torque.
- Replacement applications where the published motor specifications match the original equipment.
FAQs:
- Q: Is the Ingersoll Rand 7803-1B reversible?
A: No. This model is a non-reversible air motor designed for continuous rotation in one direction. - Q: What is the advantage of double gear reduction?
A: Double gear reduction uses two reduction stages to significantly decrease output speed while increasing available torque, making it suitable for demanding industrial applications. - Q: What is the rated free speed?
A: The manufacturer specifies a free speed of 1,200 RPM. - Q: What does the stall torque rating represent?
A: Stall torque is the maximum torque the motor develops when the output shaft is prevented from rotating under load. - Q: What should be verified before installation?
A: Confirm horsepower, free speed, rotation direction, gear reduction, shaft dimensions, mounting arrangement, and compressed-air requirements using the Ingersoll Rand Air Motor Catalog before installation.
| SKU | Spindle | R.P.M. | Torque | Air Consumption at Free Speed | Sound Level at Free Speed | Weight | Gear Reduction | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Free Speed | Load Speed at Max. Hp | Stall | Output | SCFM | L/s | lbs | kg | ||||||
| (ft-lbs) | Nm | (ft-lbs) | Nm | dB(A) | |||||||||
| Non-Reversible - 0.85 HP | |||||||||||||
| 7800-1B | 1/2" Keyed | 18,000 | 9,000 | 1.00 | 1.4 | 0.50 | 0.68 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7801-1B | 1/2" Keyed | 4,600 | 2,400 | 4.00 | 5.5 | 1.86 | 2.5 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7802-1B | 1/2" Keyed | 2,500 | 1,300 | 7.50 | 10.3 | 3.43 | 4.7 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7803-1B | 1/2" Keyed | 1,200 | 600 | 16.00 | 21.9 | 7.44 | 10.2 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7804-1B | 1/2" Keyed | 650 | 320 | 30.00 | 41.2 | 13.95 | 19.1 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7805-1B | 1/2" Keyed | 350 | 170 | 55.00 | 75.5 | 26.25 | 36.0 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7812-1B | 1/2"-20 Th’d. | 350 | 170 | 55.00 | 75.5 | 26.25 | 36.0 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7813-1B | 1/2"-20 Th’d. | 650 | 320 | 30.00 | 41.2 | 13.95 | 19.1 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7814-1B | 1/2"-20 Th’d. | 18,000 | 9,000 | 1.00 | 1.4 | 0.50 | 0.68 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7815-1B | 1/2"-20 Th’d. | 1,200 | 600 | 16.00 | 21.9 | 7.44 | 10.2 | 41.7 | 19.7 | 78 | 5.17 | 2.33 | Double |
| 7816-1B | 1/2"-20 Th’d. | 4,600 | 2,400 | 4.00 | 5.5 | 1.86 | 2.5 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| 7817-1B | 1/2"-20 Th’d. | 2,500 | 1,300 | 7.50 | 10.3 | 3.43 | 4.7 | 41.7 | 19.7 | 78 | 4.24 | 1.91 | Single |
| Reversible - 0.70 HP | |||||||||||||
| 7806-1B | 1/2" Keyed | 13,500 | 7,000 | 1.00 | 1.4 | 0.52 | 0.71 | 37.3 | 17.6 | 85* | 4.36 | 1.96 | Single |
| 7807-1B | 1/2" Keyed | 3,400 | 1,800 | 4.00 | 5.5 | 2.04 | 2.8 | 37.3 | 17.6 | 85* | 4.36 | 1.96 | Single |
| 7808-1B | 1/2" Keyed | 1,800 | 1,000 | 7.40 | 10.2 | 3.67 | 5.0 | 37.3 | 17.6 | 85* | 4.36 | 1.96 | Single |
| 7809-1B | 1/2" Keyed | 850 | 450 | 15.50 | 21.3 | 8.16 | 11.2 | 37.3 | 17.6 | 85* | 5.67 | 2.55 | Double |
| 7810-1B | 1/2" Keyed | 450 | 240 | 29.00 | 39.8 | 15.30 | 21.0 | 37.3 | 17.6 | 85* | 5.67 | 2.55 | Double |
| 7811-1B | 1/2" Keyed | 250 | 130 | 54.00 | 74.0 | 28.20 | 38.7 | 37.3 | 17.6 | 85* | 5.67 | 2.55 | Double |
Looking for more information about Ingersoll Rand Air Motor? Click here to view the Catalog
For help selecting the correct Ingersoll Rand Air Motors for your assembly application, call (800) 608-5210 or email info@intlairtool.com
