Ingersoll Rand 8230-4A Non-Reversible Air Power Motor is designed to provide dependable pneumatic rotary power for industrial equipment requiring higher torque at controlled operating speeds. Featuring a planetary gear drive with single gear reduction, this air power motor is rated at 0.60 HP and operates at a free speed of 2,800 RPM. Its non-reversible configuration makes it an excellent choice for OEM machinery, automated manufacturing systems, processing equipment, and replacement applications where continuous rotation in one direction is required.
The 8230-4A develops 4.50 lb-ft of stall torque, representing the maximum torque generated when the output shaft is prevented from rotating. The combination of planetary gearing and reduced output speed provides increased available torque compared to higher-speed models, making this motor suitable for applications requiring greater rotational force while maintaining compact pneumatic power transmission.
Type: Air Power Motor | Model: 8230-4A | Rotation: Non-Reversible | Gear Type: Planetary Gear | Gear Reduction: Single | Power: 0.60 HP | Speed: 2,800 RPM | Stall Torque: 4.50 lb-ft
Features:
- Air-powered motor converts compressed air into reliable rotary power for industrial machinery.
- Non-reversible configuration is intended for applications requiring continuous operation in one rotational direction.
- Planetary gear system provides efficient power transmission in a compact assembly.
- Single gear reduction increases output torque while maintaining dependable operating performance.
- 0.60 HP output provides consistent pneumatic power for compatible industrial equipment.
- 2,800 RPM free speed is well suited for applications requiring increased torque at moderate operating speeds.
- 4.50 lb-ft stall torque provides a manufacturer-published reference for evaluating maximum load capability.
Made in USA:
Applications:
- OEM machinery requiring one-direction pneumatic rotary power.
- Industrial automation and manufacturing equipment.
- Material handling and processing systems utilizing planetary geared air motors.
- Compressed-air-powered machinery requiring moderate speed and increased output torque.
- Replacement installations where the published specifications match the original equipment.
FAQs:
- Q: Is the Ingersoll Rand 8230-4A reversible?
A: No. This model is a non-reversible air power motor designed for continuous operation in one rotational direction. - Q: What type of gearing does this motor use?
A: The 8230-4A features a planetary gear design with single gear reduction. - Q: What is the rated operating speed?
A: The manufacturer specifies a free speed of 2,800 RPM. - Q: What does the 4.50 lb-ft stall torque represent?
A: Stall torque is the maximum torque produced when the output shaft is prevented from rotating. It serves as a selection reference and should not be considered a continuous operating value. - Q: What should be confirmed before installing this motor?
A: Verify horsepower, operating speed, rotation direction, gear configuration, shaft dimensions, mounting arrangement, and compressed-air requirements using the manufacturer catalog before installation.
| SKU | Spindle | R.P.M. | Torque | Air Consumption at Free Speed | Sound Level at Free Speed | Weight | Gear Reduction | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Free Speed | Load Speed at Max. Hp | Stall | Output at Max. Hp | ||||||||||
| lb-ft | Nm | lb-ft | Nm | SCFM | L/s | dB(A) | lbs | kg | |||||
| NON-REVERSIBLE - 0.60 HP | |||||||||||||
| 8230-1A | 3/8" Keyed | 19,000 | 9,800 | 0.70 | 0.9 | 0.32 | 0.4 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8230-2A | 3/8" Keyed | 5,700 | 2,900 | 2.5 | 2.9 | 1.10 | 1.5 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8230-3A | 3/8" Keyed | 3,500 | 1,750 | 3.50 | 4.7 | 1.80 | 2.4 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8230-4A | 3/8" Keyed | 2,800 | 1,400 | 4.50 | 6.1 | 2.20 | 3.0 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8230-5A | 3/8" Keyed | 1,650 | 840 | 7.50 | 10.2 | 3.80 | 5.1 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8230-6A | 3/8" Keyed | 1,000 | 500 | 12.00 | 16.3 | 6.20 | 8.4 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8230-7A | 3/8" Keyed | 800 | 390 | 14.80 | 20.0 | 8.00 | 10.8 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8230-8A | 3/8" Keyed | 600 | 315 | 19.60 | 26.5 | 10.00 | 13.5 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8230-9A | 3/8" Keyed | 500 | 250 | 24.00 | 32.5 | 12.50 | 16.9 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8229-1A | 3/8"-24 Th’d. | 19,000 | 9,800 | .70 | 0.9 | 0.32 | 0.4 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8229-2A | 3/8"-24 Th’d. | 5,700 | 2,900 | 2.15 | 2.9 | 1.10 | 1.5 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8229-3A | 3/8"-24 Th’d. | 3,500 | 1,750 | 3.50 | 4.7 | 1.80 | 2.4 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8229-4A | 3/8"-24 Th’d. | 2,800 | 1,400 | 4.50 | 6.1 | 2.20 | 3.0 | 41 | 19.3 | 80 | 2.45 | 1.10 | Single |
| 8229-5A | 3/8"-24 Th’d. | 1,650 | 840 | 7.50 | 10.2 | 3.80 | 5.1 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8229-6A | 3/8"-24 Th’d. | 1,000 | 500 | 12.00 | 16.3 | 6.20 | 8.4 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8229-7A | 3/8"-24 Th’d. | 800 | 390 | 14.80 | 20.0 | 8.00 | 10.8 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8229-8A | 3/8"-24 Th’d. | 600 | 315 | 19.60 | 26.5 | 10.00 | 13.5 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| 8229-9A | 3/8"-24 Th’d. | 500 | 250 | 24.00 | 32.5 | 12.50 | 16.9 | 41 | 19.3 | 80 | 2.98 | 1.34 | Double |
| REVERSIBLE - 0.50 HP | |||||||||||||
| 8231-1B | 3/8" Keyed | 18,000 | 9,200 | 0.52 | 0.7 | 0.28 | 0.4 | 32 | 15.1 | 80* | 2.45 | 1.10 | Single |
| 8231-2B | 3/8" Keyed | 5,300 | 2,600 | 1.70 | 2.3 | 1.00 | 1.3 | 32 | 15.1 | 80* | 2.45 | 1.10 | Single |
| 8231-3B | 3/8" Keyed | 3,200 | 1,550 | 2.90 | 3.9 | 1.70 | 2.3 | 32 | 15.1 | 80* | 2.45 | 1.10 | Single |
| 8231-4B | 3/8" Keyed | 2,600 | 1,300 | 3.50 | 4.7 | 2.00 | 2.7 | 32 | 15.1 | 80* | 2.45 | 1.10 | Single |
| 8231-5B | 3/8" Keyed | 1,500 | 780 | 5.90 | 8.0 | 3.50 | 4.7 | 32 | 15.1 | 80* | 2.98 | 1.34 | Double |
| 8231-6B | 3/8" Keyed | 950 | 480 | 9.50 | 12.9 | 5.50 | 7.4 | 32 | 15.1 | 80* | 2.98 | 1.34 | Double |
| 8231-7B | 3/8" Keyed | 750 | 380 | 11.80 | 16.0 | 7.00 | 9.5 | 32 | 15.1 | 80* | 2.98 | 1.34 | Double |
| 8231-8B | 3/8" Keyed | 575 | 290 | 15.50 | 21.0 | 9.00 | 12.2 | 32 | 15.1 | 80* | 2.98 | 1.34 | Double |
| 8231-9B | 3/8" Keyed | 475 | 240 | 19.40 | 26.2 | 11.00 | 14.9 | 32 | 15.1 | 80* | 2.98 | 1.34 | Double |
Looking for more information about Ingersoll Rand Air Motor? Click here to view the Catalog
For help selecting the correct Ingersoll Rand Air Motors for your assembly application, call (800) 608-5210 or email info@intlairtool.com
